Page 2: Safety Warnings
To Daxom User In order to perform device’s function properly and for your safety follow the instructions mentioned in the user manual of the device during the mounting and the usage of the device. In case of an unauthorized mounting and maintenance, the device will be void from warranty cover. - Page 3 2. THE FEATURES AND THE CHARATERISTICS OF WATER HEATER With digital constant water setting function: The water temperature will remain constant in the degree you set. The fuel efficiency: As your device can operate constant setting water By the automatic water controlled on/off system: When the water tap is turn on, the water heater will automatically operate and the hot water flow will be provided.
- Page 4 warnings. In case of fault condition, it gives information about fault reason with fault code. 3. THE CONFIGURATION OF WATER HEATER...
- Page 6 3.1. Control Panel Configuration The control panel is not integrated on the water heater and provides remote control opportunity. Maximum of three control panels can be used in the same water heater.
-
Page 7: Technical Informations
4. TECHNICAL INFORMATIONS Model UKDAX-20VT UKDAX-26VT Device Type Installation Type Building Indoor Wall Gas Category II2H3 B/P LPG (G30/G31) – NG (G20) Gaz Type LPG (30 mBar) – NG (20 mBar) Gas Pressure Nominal Heat Load (Q) 39,65 kW 49,7 kW... - Page 8 provide fresh air to other units, and places that may be exposed to direct wind resistance. The open end of the air intake pipe should be at least 100 mm from the wall where it is installed. In order to prevent the backflow of the condensed water or the rain water to the heater, the part of the waste gas pipe remaining outside the environment should be placed as to make a horizontal angle of 3 degrees.
- Page 9 Flammable and explosive substances must definitely be kept away from the water heater, they must not be at the same place. After mounting, the hole opened for the waste gas pipe in the wall, should be filled with a substance resistant to burning and it should be isolated. ...
- Page 10 5.3. Installation Of Control Pannel and Connection Of Heater Do not supply electric to water heater before connecton of control pannel. Children's access to the remote control should be prevented. The installation of control pannel must not be done near heat sources and humid places.
- Page 11 5.4. Installation Of Water And Gas Connections There must be valve at the watersupply which will be connected to water inlet of the water heater. Installation of silt trap after valve is recommended for water installations which has probability of entering dirt inside of water heater from watersupply.
- Page 12 Connect the cold water inlet of water heater the cold water mains line, and the hot water outlet to the hot water line with a 3/4" flexible pipe. For preventing water leakage of connections, seals must be used. Do not never use liquid seal for water line connections. ...
- Page 13 Water temperature and failure codes can be seen at LED display Target (set) water temperature value Control pannel priority indicator Burner operation (combustion) indicator Fan operation indicator Water Flow Indicator Temperature Unit Indicator Temperature Setting Buttons Priority assignment button. On / Off Button 6.1.
- Page 14 Keep press button 2 sec “11” code will be seen at the display.. By pressing button, it can be exit by confirming matching. Even not pressed button, matching will automatically confirmed after a while. Repeat the above steps for more remote control panel matchings. "12" and "13" codes will be given for other control panels.
- Page 15 6.1.2. Operation Of Water Heater Follow following steps for operate of your heater. Turn On the water inlet valve of water heater Open fuse of water heater Open gas inlet valve of water heater. Activate the heater by pressing button.
- Page 16 priority assignment. The control panel that has not been assigned a priority cannot change the settings of the water heater. To assign the priority, the button on the control panel is pressed. “PRIORITY” warning appears on the screen. 6.2. Turn Off Heater 6.2.1.
- Page 17 anything before the gas leaves out completely. Do not forget that any flame or a spark that may occur in such a case, will lead to fire or explosion. Pipe and connection pipes must be controlled regularly. If it is suspected that there is gas leakage because of pipes apply to necessary gas distributor ...
- Page 18 LED display must be ON. In other words, be sure that the device is at operating state. Although the device has a freezing prevention system, the freezing prevention system will not operate in case of short period electric or gas cut off time in very cold and windy weather.
-
Page 19: Electrical Diagram
7. ELECTRICAL DIAGRAM 8. REPAIR AND SERVICE We have been providing service free of charge during the warranty period of the device for relevant parts and manufacturing defect. When you have a problem during using please contact our after sales service department. The unauthorized repair and the maintenance of the device will void its warranty cover. -
Page 20: Troubleshooting
9. TROUBLE SHOOTING Removing fault warning by resetting water heater must be pressed to button. Error Cause Solution Code Inlet Water NTC Error Call authorised service Control if device has got gas or not Ignition Error ... - Page 21 PROBLEM SOLUTION WAYS CAUSE ● No energy Check the electricity fuse ● Gas valve is not ON Open gas valve or make gas loading ● ● Gaz valve semi ON Open gas valve completely Turn on / Turn off until combustion ●...
- Page 22 Namık Kemal Mah. Marmara Cad. No:74 Ümraniye - İstanbul Tel. : +90 216 369 85 36-37 : +90 216 385 95 45 E-Mail : info@daxom.com Merkez Servis Namık Kemal Mah. Marmara Cad. No:74 Ümraniye - İstanbul Tel. : +90 216 360 71 21-22 : +90 216 360 72 25 22.07.22...
