- Page 2 Dear Daxom User, In order to perform device’s function properly and for your safety follow the instructions mentioned in the user manual of the device during the mounting and the usage of the device. In case of an unauthorized mounting and maintenance, the device will be void from warranty cover.
- Page 3 1. THE FEATURES AND THE CHARACTERISTICS OF YOUR WATER HEATER Thanks to its feature of digital constant water setting, the water temperature will remain constant in the degree you set. The fuel efficiency is reduced in low water temperature as your device can operate in the desired constant water temperatures.
- Page 4 LCD display provides you to see the water temperature that you set. When you press the On/Off button you can see the water flowing, the fan turning, the temperature you set and the occurrence of the flame on the LCD display. 2.
-
Page 5: Technical Informations
3. TECHNICAL INFORMATIONS Model:DAXOM Type: UKDAX-11ST Device type Gas category II2H3 B/P Gas type LPG(G30/G31) Natural Gas(G20) Gas input pressure 30mBar 20mBar Fan Power 36 W Water flow(Δt=25K) 11 l/min 11 l/min Nominal power P 19,15 KW Nominal load 22,8KW... - Page 6 The waste gas pipe can be extended when necessary however the total pipe length should not exceed 2 m. The extension pipe should be supplied by DAXOM. More than 2 brackets should not be used for extension (including original bracket), the pipes should be appropriately fixed.
- Page 7 4.2. The Wall Mounting Of The Heater Drill bolts and screw holes by using the mounting template supplied with the water heater in a place appropriate to the conditions mentioned above. Insert the Ø8 diameter bolt to the upper part and insert the screws to the lower part.
- Page 8 4.2.1.a. The Up and Side Mounting Of Waste Gas Pipe Insert the bolt to the mounting rings on the water heater. Fix the water heater by tightening the nut on the bolt. Mount the pipe to the hole opened previously on the wall as the fresh air/waste gas outlet will be outside.
- Page 9 4.2.2. Performing of Connection of Water and Gas Connect the cold water inlet of your device to the cold water main pie with the ½ ‘’ flex pipe supplied with the device. The isolation seal should be applied to the connections to prevent water leakage. There should be a valve in the cold water main pipe line in order to cut the water when needed.
- Page 10 5.1. THE Operation Of The Heater 5. USING OF THE WATER HEATER Make sure the used gas type is the same with the one stated in the brand plate. Turn on the gas and power supply of the water heater . The light will highlight on the buttons existing on the control panel with a warning sound.
- Page 11 The fault code may occur on the Lcd display when the device does not operate and the device may give an audio warning. The meanings of these codes are: Fault codes FAILURE DESCRIPTION Water Inlet Sensor Failure No ignition Fan Failure NTC Failure 5.1.1.Water And Temperature Kontrol When the...
- Page 12 5.1.2. Real Time Water Flow Control and Setting Water Flow Rate Press the SET button on the display panel to present the real Ayarlama time water flow rate with range of 00 to 16. Forexample “0,8” indicates the real time water flow rate 8L/min then pres “SET” button enter injection...
- Page 13 5.3. The Precautions to be Taken Make sure the used gas type is the same with the one stated in the brand plate. The use of inappropriate type of gas may lead to accident. The repair of the water heater as unauthorized is dangerous and it may cause accidents.
-
Page 14: Repair And Service
5.5. For The Safe Use Check the newly mounted water heaters carefully and make sure it works properly before using. Wait for about 10~20 seconds to ignite again when the flame is out. Do not drink the water inside the water heater. If neccessary preventations do not taken, situations which ambient temperature deduct under the 0 degree, water inside heater can give damage to your heater by freezing. - Page 15 7. MULFUNCTION Electrical connection Problem Control the connection 1 Ignition fail without gas 1Change the gas bottle or 2. Gas valve problem or cable turn on the gas valve. connection loose Please check 3. Flame out problem electromagnetic valve makes it’s functions correctly or not.
- Page 16 8. CHART OF TROUBLESHOOT AND CORRECT PROBLEM WAYS OF SOLUTION CAUSE No energy Check the electricity fuse Turn the gas valve on or perform Gas valve is not on gas load Gas valve semi-on Turn the gas valve completely Turn the device on and off until the Air in the gas pipe ignition occurs Abnormal pressure...
