Page 2: Safety Warnings
TO DAXOM USER In order to perform device’s function properly and for your safety follow the instructions mentioned in the user manual of the device during the mounting and the usage of the device. In case of an unauthorized mounting and maintenance, the device will be void from warranty cover. - Page 3 2. THE FEATURES AND THE CHARATERISTICS OF WATER HEATER With digital constant water setting function the water temperature will remain constant in the degree you set. The fuel efficiency because of your device can operate constantly at set water temperature, fuel efficiency decreases. By the automatic water controlled on/off system, when the water tap is turn on, the water heater will automatically operate and the hot water flow will be provided.
- Page 4 instant water flow, instant gas consumption and warnings. In case of fault condition, it gives information about fault reason with fault code. 3. THE CONFIGURATION OF WATER HEATER...
-
Page 5: Technical Informations
4. TECHNICAL INFORMATIONS Device Model UKDAX-11ST Device Type Gas Category II2H3 B/P Gaz Type LPG(G30/G31) Natural Gas(G20) Gas Inlet Pressure 30mBar 20mBar Nominal Load (Q) 22,80 kW Nominal Power (P) 19,61 kW Gas Consumption 1,78 kg/h 2,38 m3/h Min. 0.3 Bar Water Pressure Max. -
Page 6: Installation Of Water Heater
5. INSTALLATION OF WATER HEATER 5.1 Installation Conditions and Safety Warnings The waste gas pipe should not be installed in the general chimney or ventilation space of the building. The waste gas pipe should definitely go outside the building. Pipe exit should not be made to passages and corridors, narrow eaves, ventilation and light spaces of buildings, balconies (open or closed), elevator shafts and protruding building parts that prevent waste gas outlet, openings that provide... - Page 7 Your water heater is a household device. In case of using industrial places, your device will unguaranteed 5.2. Wall Installation Of Water Heater Drill at least two holes of appropriate diameter from the bottom and top of the device according to the measurements of the water heater mounting holes in the place selected in accordance with the above mentioned conditions.
- Page 8 5.2.1. Waste Gas Pipe Installation Place the fresh air / discharge gas pipe as open side will be outside to hole which is drilled before. Install the bracket part as installing one edge is to heater pipe another edge is to discharge pipe. Fill the hole on the wall opened for discharge pipe with fire resistance material and insulate it.
- Page 9 5.2.2. Installation Of Water And Gas Connections There must absolutely be valve at water supply which will be connected to cold water inlet of heater. Silt trap has to be installed after valve for some installations which have probability entering dirt from water network to inside of heater.
- Page 10 6. WATER HEATER USAGE 6.1. Operation of Water Heater Be sure that, gas type which will be used is same with the one stated in the brand plate. Follow following steps for operate of your heater. Turn On the water valve of water heater ...
- Page 11 When it is pressed to button, set value is seen. By pressing button you can increase temperature. By pressing button you can decrease the temperature. 6.1.2. The Amount of Water Used In Liter When it is pressed to button once , instant water flow is seen in terms of l/min. When it is pressed twice numerical values between 00 and 99 are appeared.
- Page 12 6.1.3. Determination of Quantity of Used Gas When it is pressed third time, with numeric values between 05 and 34 you can see instant gas amount that device consumed. Values changing between 05 and 34 shows gas amount as l/h. 6.2.
- Page 13 Check pipes and connections pipes regularly. If you suspect that there is gas leakage caused by pipe and connection pipes, consult to number 187 gas failure department of necessary gas company. If you suspect that there is gas leakage except pipe and pipe connections consult to your service agency.
-
Page 14: Repair And Service
. For operating of this system, gas and electric connection must not be cut off, LCD display must be ON. In other words, make sure that device is at “ON” position. Although the device has a freezing prevention system, the freezing prevention system will not operate in case of electric or gas cut off very short time in very cold and windy weather. - Page 15 8. MULFUNCTION Warning Cause Solution Code Water inlet NTC failure Electrical Connection Call Authorised Service Problem No Gas Gas Valve problem or cable Check if gas is coming to device or not. connection loose ...
- Page 16 PROBLEM SOLUTION WAYS CAUSE ● No Energy Check the electricity fuse ● Gas valve is not ON Turn on gas valve or perform gas load ● ● Gas valve semi Gas Turn on the gas valve completely Turn on / Turn off until combustion ●...
- Page 21 Namık Kemal Mah. Marmara Cad. No:74 Ümraniye – İstanbul Tel. : +90 216 369 85 36-37 : +90 216 385 95 45 E-Mail : info@daxom.com Merkez Servis Namık Kemal Mah. Marmara Cad. No:74 Ümraniye - İstanbul Tel. : +90 216 360 71 21-22...
