Cadet RMT2 Installation Instructions page 2

1. All electrical work and materials must comply
with the National Electric Code (NEC), the Occu-
pational Safety and Health Act (OSHA), and all
state and local codes.
2. Use copper conductors only.
1. Read your Register heater instructions for safety infor-
mation and how to install heater. Set the heater assembly,
blower wheel first, into the left side of the wall can. Fasten
at top with screw provided.
2. Connect the two black thermostat wires to the two
heater wires. Connect the two red thermostat wires to the
incoming supply wires. (Refer to the wiring diagram on
page 1.)
3. Gently place wires inside wiring compartment area
keeping the wires away from all moving parts.
4. Place the bracket/thermostat assembly so that it cap-
tures the bottom edge of the wall can. Fasten the bracket
at the top with the #8 screw provided.
NOTE: This thermostat is double pole and so has a positive off. If you do not want the heater to come on even when the
climate turns cold, turn the knob fully counterclockwise.
For more effective and safer operation and to prolong the life of the heater,
read the Owner's Guide and follow the instructions. Failure to properly
maintain the heater will void any warranty and may cause the heater to
function improperly.
LIMITED ONE-YEAR WARRANTY: Cadet will repair or replace any RMT2
thermostat found to be defective within one year after the date of purchase.
These warranties do not apply:
1. Damage occurs to the product through improper installation or incorrect
supply voltage;
2. Damage occurs to the product through improper maintenance, misuse,
abuse, accident, or alteration;
3. The use of unauthorized accessories or unauthorized components con-
stitutes an alteration and voids all warranties. Refer to Cadet website or
call customer service at 855.CADET.US for list of authorized accessories
and components.
4. CADET'S WARRANTY IS LIMITED TO REPAIR OR REPLACEMENT.
Page 2
INSTALLATION INSTRUCTIONS
Figure 1
Warranty
3. Turn off power to heater circuit at main discon-
nect panel.
4. Connect grounding lead to grounding screw
provided.
5. Holding the grill with labels on top, remove the second
louver from the bottom with needle nose pliers. By bend-
ing the louver back and forth at each end, the louver will
separate from the grill (Figure 2). Important: Only remove
the right side louver.
6. Align the thermostat face plate so that the four small
tabs slip under the center divider and the first and third
louvers. Turn the grill over and bend all four tabs to secure
the plate in place.
7. Align the grill so that the thermostat shaft is in the center
of the hole of the face plate. Tighten the grill to the heater
with screws. Press the thermostat knob onto the shaft and
turn fully counter-clockwise.
8. Turn on power at the circuit breaker (fuse box) and turn
thermostat knob fully clockwise until temperature is com-
fortable, then turn knob left until a click sound is heard and
the heater turns off. A few adjustments may be necessary
to find your comfort zone.
5. IN THE EVENT CADET ELECTS TO REPLACE ANY PART OF YOUR
CADET PRODUCT, THE REPLACEMENT PARTS ARE SUBJECT TO
THE SAME WARRANTIES AS THE PRODUCT. THE INSTALLATION OF
REPLACEMENT PARTS DOES NOT MODIFY OR EXTEND THE UNDER-
LYING WARRANTIES. REPLACEMENT OR REPAIR OF ANY CADET
PRODUCT OR PART DOES NOT CREATE ANY NEW WARRANTIES.
If you believe your Cadet product is defective, please contact Cadet during
the warranty period, for instructions on how to have the repair or replace-
ment processed.
Parts and Service
Visit cadetheat.com/parts-service for information on where to obtain parts
and service.
Reduce-Reuse-Recycle
This product is made primarily of recyclable materials. You can
reduce your carbon footprint by recycling this product at the
end of its useful life. Contact your local recycling support center
for further recycling instructions.
©2016 Cadet
Figure 2
Printed in USA Rev 11/16 #720128
