Diagramm für Anschluss
1
HMDI
2
31
Italiano
Schließen Sie den NVR (LAN-Port)
mittels eines Ethernet-Kabels an
den Router an. Danach verbinden
Sie die Maus mit dem USB-Port
des NVRs.
VGA
Schließen Sie den NVR mittels
eines VGA-oder HDMI-Kabels
an den Bildschirm an.
AVVISO: Il cavo di VGA non viene
incluso nella confezione.
DC Power
Reset Button
Network (LAN)
3
4
AVVISO: Alcune telecamere WiFi Reolink funzionano anche con l'NVR PoE Reolink. Per
ulteriori informazioni, andare su
https://support.reolink.com
WiFi Cameras Work with Reolink PoE-NVRs.
Collegare le telecamere alle porte
PoE dell'NVR.
Collegare l'NVR a una presa
di corrente ed accendere
l'interruttore d'accensione.
e ricercare Make Reolink
Italiano
