SIMPLETT PLUS
Instructions for use
The Biolan Simplett Plus dry toilet can be installed
directly on a floor surface and is suited for both indoor
and outdoor use. The functioning of the Simplett Plus is
based on the separation of liquid and solid waste in the
seat part. No water or power supply is required.
Contents
Keep these instructions for use!
4
5
5
5
6
6
7
7
7
8
8
8
8
8
8
8
EN
DE
FR
ES
SV
NO
DA
FI
PL
CS
ET
LV
LT
RU
3
Advertisement
Table of Contents
Related Manuals for BIOLAN Simplett Plus 70570250
Summary of Contents for BIOLAN Simplett Plus 70570250
- Page 1 Keep these instructions for use! SIMPLETT PLUS Instructions for use The Biolan Simplett Plus dry toilet can be installed directly on a floor surface and is suited for both indoor and outdoor use. The functioning of the Simplett Plus is based on the separation of liquid and solid waste in the seat part.
- Page 2 Component list Part Item Part number Material Dispenser knob Dispenser axle Dispenser plate Bulking material container lid Latches Bulking material container Container’s hinges Pehvakka thermal seat 70578500 PPE Hinge pin, 2 pcs 18726240 PE Toilet tank lid Horizontal ventilation pipe 28704055 PP or PVC Receptacle 18703050 PP Lead-through rubber 75/83...
- Page 3 (EN) INSTRUCTIONS FOR USE 1. PLANNING AND INSTALLATION Install Biolan Simplett Plus horizontally on a floor surface. When selecting the location, consider the organisation of the ventila- tion and liquid removal and leave enough space for use and main- tenance. The device should be placed so that the ventilation pipe is easy to bring outside.
- Page 4 Figure 3. The horizontal ventilation pipe is extended with a sewer pipe of Ø 75 mm until it reaches above the roof ridge. Biolan Ventilation Tube Package has been specifically designed for this purpose, and it is available as an accessory.
- Page 5 2.1 Using the bulking agent Using a suitable bulking agent is crucial for the proper function- ing of the toilet. The recommended bulking agent is Biolan Toilet Bulking Material. Before use, place a couple of centimetres of the bulking agent on the bottom of the receptacle (part 12). Fill the bulking agent container (part 6) with bulking agent (Figure 6).
- Page 6 2. Biolan Oy reserves the right to either repair or replace dam- aged parts at its discretion. 3. Any damage resulting from careless or forcible handling of 2.4 Composting solid waste...
