CALIBRATION PROCEDURE
NI 5122/5124
Contents
Conventions ............................................................................................ 2
Introduction ............................................................................................. 2
Self-Calibration ........................................................................ 3
External Calibration.................................................................. 3
Calibration Interval................................................................... 3
Software and Documentation Requirements........................................... 3
Software ........................................................................................... 3
Documentation................................................................................. 5
Self-Calibration Procedures .................................................................... 5
MAX ................................................................................................ 6
Scope SFP ........................................................................................ 6
NI-SCOPE ....................................................................................... 6
External Calibration Options .................................................................. 8
Complete Calibration ....................................................................... 9
Optional Calibration ........................................................................ 10
External Calibration Requirements......................................................... 12
Test Equipment ................................................................................ 12
Test Conditions ................................................................................ 12
External Calibration Procedures ............................................................. 13
Verifying NI 5122/5124 Specifications ........................................... 13
Vertical Offset and Vertical Gain Accuracy............................. 13
Programmable Vertical Offset Accuracy.................................. 20
Timing Accuracy ...................................................................... 22
Bandwidth and Flatness............................................................ 24
Trigger Sensitivity ........................................................................... 29
Adjusting the NI 5122/5124 ............................................................ 31
Calibration Utilities................................................................................. 33
MAX ................................................................................................ 33
NI-SCOPE ....................................................................................... 34
Calibration Function References............................................................. 34
Where to Go for Support......................................................................... 34
