Assembly Instructions Rutland Premium Pergola Before you commence the assembly process, we recommend that you read these instructions thoroughly beforehand to familiarise yourself with the assembly process and to also check that you have the correct components. If for any reason you need assistance, you can find our contact details on the final page of these instructions.
Page 2
6 post pergolas 4.2 and 4.8M in length are one piece runner. All pergolas 5.4M in length and above are split runner. Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 3
(see image above). Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 4
Drop the remaining rafters into their slots... before securing with a 200mm coachscrew driven down through the rafter and runner into each post. Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 5
…before fixing to the runner with a pair of 65mm them into position as shown, centred between the 2 central woodscrews. rafters… Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 6
4 x 65mm woodscrews through the pre-drilled holes per panel. Repeat for each face of the post. Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 7
65mm woodscrews. through each end. Repeat Steps 15-18 and so you have a mirror copy of the “Goalpost” already assembled. Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 8
Drop one outer rafter into the post slots and one into the vertical as shown… intermediate rafter into place at the other end of the structure. Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 9
...and secure in place with 2 of the 65mm woodscrews. place so that the runner end fully locates in the centre post slot…. Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 10
4 x 65mm each end. woodscrews through the pre-drilled holes per panel. Repeat for each face of the post. Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
Page 11
We hope that you found your product quick and easy to assemble but if not and you require any 01778 440803 further assistance or have any questions you can contact us by telephone on: Email: info@rutlandcountygardenfurniture.co.uk www.rutlandcountygardenfurniture.co.uk Rutland County Garden Furniture Ltd, Ashbourne House, 2 Dovecote Meadows, Aslackby, Sleaford, Lincs, NG34 0HZ. Company No: 7670072 VAT No: 151744027...
