Panacea
®
1000-FLEX BED
ADJUSTABLE HEIGHT LOW BED
Owner's Manual
Please keep and refer to this Owner's Manual.
Thank you for purchasing a Panacea
1000-FLEX Bed from Direct Supply Equipment & Furnishings
. Please read this entire
®
®
guide carefully and keep it for future reference. This guide will provide you with instructions, warnings, warranty informa-
tion and other important information about your Panacea bed. Share this information with your housekeeping, nursing and
maintenance staff to help ensure the bed is cared for properly.
1-800-634-7328 DirectSupply.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panacea 1000-FLEX BED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Direct Supply Panacea 1000-FLEX BED

  • Page 1 ADJUSTABLE HEIGHT LOW BED Owner’s Manual Please keep and refer to this Owner’s Manual. Thank you for purchasing a Panacea 1000-FLEX Bed from Direct Supply Equipment & Furnishings . Please read this entire ® ® guide carefully and keep it for future reference. This guide will provide you with instructions, warnings, warranty informa- tion and other important information about your Panacea bed.
  • Page 2: Table Of Contents

    Table of Contents Important Precautions ............................. 3 - 4 Features and Specifications ............................5 Installation ................................6 - 8 Operation ..................................9 Split Frame Usage ..............................10 - 13 Servicing ................................14 - 15 Troubleshooting ................................16 Cleaning ..................................17 Maintenance and Inspection Information ........................17 End of Life Disposal ..............................
  • Page 3: Important Precautions

    State injury or death. and Federal guidelines. Direct Supply recommends the use of a mattress with minimum dimensions of 35" width and 6" height. •...
  • Page 4 ® A). If it is used in a residential environment (for which CISPR for the Direct Supply Panacea 1000-FLEX bed and it is locked in 11 class B is normally required) this equipment might not offer place. Failure to lock assist devices may result in injury or death.
  • Page 5: Features And Specifications

    Features and Specifications Mechanical Specifications Direct Supply Panacea 1000-FLEX Bed Standard Features Description: Dimensions: Overall Dimensions ....86.9"L x 35.0"W x 8.75"H 80" Mattress Support Platform Weight - Total without Panels ....145 lb (65.8 kg) 8" to 28" Travel Range Quiet DC Actuators Weight - Head Frame ......
  • Page 6: Installation

    Installation • CAUTION: Carefully remove the packaging straps (orange zip ties) before attempting to operate the bed. • CAUTION: Prior to operation, refer to operating conditions above to ensure bed electronics are within ambient temperature. Check that all parts of the bed were delivered and inspect for damage. Parts to Prepare: a.
  • Page 7 3. Panels should slip in and out of their sockets easily and securely. IV Sockets Direct Supply Panacea 1000-FLEX Bed Platform has four IV sockets as standard equipment. There are two sockets at head end of bed and two at foot end (Figure 8). The IV Figure 7 sockets are used with most ½"...
  • Page 8 Installation (cont.) For models with staff control in foot panel - cable install and routing: 1. Raise the bed to a comfortable working height and raise the foot section with the pendant. Then unplug the bed. 2. Locate the two staff control cables. Lay them out side by side with one cable reversed.
  • Page 9: Operation

    Operation Your Direct Supply Panacea 1000-FLEX bed comes with a Staff Control Operation pendant (Figure 13).The pendant allows the patient/resident to operate the bed. • WARNING: Possible Injury or Death. This bed should not be operated (control the movements of the bed...
  • Page 10: Split Frame Usage

    Split Frame Usage Bed Frame Installation: After cutting orange zip ties, Identify head frame and foot frame by compatible ID labels on left side (Figure 16). 2. Lay frame halves on soft surface feet side down. Place packing material under head frame to make assembly easier (Figure 17).
  • Page 11 • CAUTION: Equipment Damage. Failure to install the actuators in the proper orientation may cause damage to the actuators. 3. Install the back actuator and knee actuator on the head frame and foot frame as shown using the actuator pin and clip (Figure 19).
  • Page 12 Split Frame Usage (cont.) Line up back and knee actuators and insert actuator pin then add clip to lock in place (Figure 22 and 23). Ensure the washers are used on the back actuator (Figure 24). Figure 22 Figure 23 Figure 24...
  • Page 13 2. Locate back actuator and head end hi-lo cables and route through safety pin bail (Figure 21), then route behind cable bundle (Figure 25 and 26). 3. Insert back actuator cable in port 1 and insert hi-lo actuator head end cable in port 3 (Figure 27). 4.
  • Page 14: Servicing

    Servicing Service parts list available upon request. The actuators and control box contain no serviceable items. Power Cord Port Pendant P/N: 11017194 Power Cord Class I P/N: 11016857 • WARNING: Possible Shock Hazard. Unplug power cord from wall outlet before performing any maintenance or service to control box.
  • Page 15 To Remove Actuator Recommended Tools: Screwdriver, Hammer, Punch Identify actuator to be replaced. 2. Tip bed on its side or upside down to replace hi-lo actuators. 3. Mark cable ties locations with tape for later reference. Cut cable ties that hold the motor cables to frame. 4.
  • Page 16: Troubleshooting

    To Maximize Service Life Keep the bed clean. 2. Observe bed operation and report any discrepancies or problems to Direct Supply Technical Support at 1-800- 634-7328 3. After initial week of use, check all threaded fasteners for looseness, and make sure all pins are in their normal location and fastened securely.
  • Page 17: Cleaning

    Clean all electrical components (actuators, control box, Visually inspect bed and accessories for broken pendant and cables) on your Direct Supply bed with a ® damp, well-wrung cloth. Excess water in or on electrical welds or cracks, and check for loose hardware on a parts can damage these components.
  • Page 18: Accessories

    Bed transport bar is designed to easily move the Panacea Trapeze (Figure 33) 1000-FLEX Bed, particularly when it is lowered onto its casters. Note: The Panacea 1000-FLEX Bed is not designed for use as resident/patient transport devices. We recommend using the Direct Supply trapeze with ®...
  • Page 19 Trapeze Adapter (Figure 34) The trapeze adapter is designed to allow attachment of the trapeze system to the Panacea 1000-FLEX Bed. Prior to use, please read important warnings related to this option and follow all instructions below. 2. Install the trapeze adapter according to the supplied instructions. If needed, call Technical Support at 1-800-634-7328 for instructions.
  • Page 20 The Direct Supply Panacea 1000-FLEX bed is intended for use in the electromagnetic environment (for professional healthcare) specified below. The customer or the user of the Direct Supply Panacea 1000-FLEX bed should assure that it is used in such an environment.
  • Page 21 The Direct Supply Panacea 1000-FLEX bed is intended for use in the electromagnetic environment (for professional healthcare) specified below. The customer or the user of the Direct Supply Panacea 1000-FLEX bed should assure that it is used in such an environment.
  • Page 22 The Direct Supply Panacea 1000-FLEX bed is intended for use in the electromagnetic environment (for professional healthcare) specified below. The customer or the user of the Direct Supply Panacea 1000-FLEX bed should assure that it is used in such and environment.
  • Page 23: Warranty

    Direct Supply Panacea 1000-FLEX Bed Frame We offer to you, as the original purchaser, a warranty for the Panacea 1000-FLEX Bed. Our warranty applies for the limited warranty period stated below. If any device or device part listed below is defective in material or workmanship during the applicable limited warranty period, we will repair or replace it at our cost.
  • Page 24 Distributed by Direct Supply Manufacturing, Inc. 7301 W Champions Way, Milwaukee, WI 53223. © 2021 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply , Panacea , and all associated logos are the registered ® ® trademarks of Direct Supply, Inc., used under license.
