inVue OneKEY AKD40 Manual

OneKEY
Counter Detacher
AKD40

Screw Mount (Optional):

3a
Peel the clear film from the 3
adhesives on the bottom of the base.
1
Use the provided alcohol wipe to
1
clean the area where the Detacher
will be placed, either on a horizontal
or vertical surface. Allow it to dry
completely.
Or
Place the base in the desired location
3b
and use the 2 provided screws to
secure the base to the fixture.
Decide how the power cable will
2a
be routed. There are 4 options; the
power cable can be routed out from
the back of the base (Option A), out
either side of the base (Options B or
C) or the power cable can be routed
straight down through the fixture
(Option D shown in the next step).
Option B
Option A
Option C
3c Insert one side of the pad into the
rim of the base. The tabs on the pad
will fit into the slots on the inner rim
of the base.
If mounting the base over a hole, the
2b
power cable can be routed straight
down through the fixture.
Option D
3d Apply pressure around the edge of
the pad to fully secure the pad in the
rim of the base.
