Digital Projection LIGHTNING

Optical

Digital Light Processor
Contrast Ratio
Pixel fi ll factor
Lamp power
Lamp life (typical)
Brightness
Colour temperature

Electrical

Input
Pixel clock
Control inputs
Indicators
Mains voltage
Power consumption
International Regulations

Physical

Operating Temperature
Storage Temperature
Thermal Dissipation
Operating Humidity
Weight
Rev B. April 2008
i
sx+, 1080p, Reference 1080p
isx+: 3 x 0.94" Texas Instruments DMD™,
resolution 1400 x 1050 pixels
1080p: 3 x 0.95" Texas Instruments DMD™,
resolution 1920 x 1080 pixels
isx+: 1800:1 full fi eld (±10%)
1080p: 2000:1 full fi eld (±10%)
Reference 1080p: 5000:1 full fi eld (±10%)
87%
30: 3.0kW
40: 3.6kW
30: 750 hours
40: 500 hours
30isx+: 18,000 Center lumens, 16,000 ANSI lumens (±10%)
40isx+: 22,000 Center lumens, 21,000 ANSI lumens (±10%)
30-1080p: 15,000 ANSI lumens (±10%)
40-1080p: 20,000 ANSI lumens (±10%)
Reference 1080p-30: 10,000 ANSI lumens (±10%)
Reference 1080p-30: 14,000 ANSI lumens (±10%)
3000-9300°K
RGB1, RGB2, SDI, DVI, Composite Video, S-Video,
Component
up to 165MHz
1 x LAN
1 x wifi LAN
1 x RS232 serial: 19200 baud, 8 bits, 1 stop bit, no parity
1 x remote control
Input, Power, Shutter, Error, IR, Lamp (Lamp 1 only)
200-240 VAC, 50/60Hz (single phase)
30: 4000W
40: 4600W
Meets FCC Class A requirements
Meets EMC Directives (EN 55022, EN 55024, EN 55103)
Meets Low Voltage Directive (EN 60950)
10 to 35°C
-10 to 50°C
30: 13640 BTU/hr
40: 15695 BTU/hr
up to 80% non-condensing
114kg (249lbs)
FCC WIFI ID, R68WIPORT
English
