PIRANHAMAX 4 TRANSDUCER
Install Guide
WB.TD.01
ATTENTION
Ensure the proper template is selected for the Piranhamax 4 transducer and Boat model.
TOOLS REQUIRED
INSTALL GUIDE
9/64" Drill Bit
Transducer
Silicone
Drill
Template
Phillips Bit
Tape Measure
Safety Glasses
https://support.legendboats.com/
1
Advertisement
Table of Contents
Related Manuals for Humminbird PIRANHAMAX 4
Summary of Contents for Humminbird PIRANHAMAX 4
- Page 1 PIRANHAMAX 4 TRANSDUCER Install Guide WB.TD.01 ATTENTION Ensure the proper template is selected for the Piranhamax 4 transducer and Boat model. TOOLS REQUIRED INSTALL GUIDE 9/64” Drill Bit Transducer Silicone Drill Template Phillips Bit Tape Measure Safety Glasses https://support.legendboats.com/...
- Page 2 PIRANHAMAX 4 TRANSDUCER Install Guide WB.TD.01 STEP 1 Arrange all parts and hardware to begin installing the Transducer. Assemble the Transducer onto the Mounting Bracket. NOTE Refer to the supplied manufacturer’s instructions for full assembly steps. STEP 2 Using the proper Transducer Template, mark the installation location of the Mounting 12”...
- Page 3 PIRANHAMAX 4 TRANSDUCER Install Guide WB.TD.01 STEP 4 Using marine grade Silicone, seal the pilot holes prior to installing the Mounting Bracket. STEP 5 Using the supplied hardware, install the Mounting Bracket onto the Transom. Mount the transducer in the highest position.
