- Page 1 Dome C2, C3, and C5i Displays Dome DX/PCI Display Controller Dome CXtra Software QUICK REFERENCE Windows XP Windows 2000...
-
Page 2: Before You Begin
DX board. Enabling this function can improve video performance on the board by 100% or more. The results: faster image loads, increased window and level speed, and enhanced system performance. For more information, visit www.planar.com. Wear an antistatic heel or wrist strap when installing the Warning board and display to avoid damage to computer components. -
Page 3: Unpacking The Display
Unpacking the Display Check the contents of your Dome CX display package for all the items shown here. Save the original packing materials for storage and shipping. Guidelines • Use both hands to lift or adjust the display. AC power •... - Page 4 Setting DIP Switch S2 Slide switch 1 on DIP switch S2 into the ON position to enable VGA mode or into the OFF position to disable it. Enable VGA on only one (1) board when you install multiple DX boards. Disable VGA on all DX boards if you are using a separate VGA card.
-
Page 5: Installing The Board
Installing the Board Turn your computer off. Leave the power cord plugged into the grounded outlet. Remove the blank bracket from an Insert the board into the slot, align the available PCI slot. connector pins, and press the board down until it is firmly seated. Secure the mounting bracket with screws. - Page 6 Identifying Controls and Connectors Interface plate Reset LEDs Locate your specific display to the right USB ports on desktop stand Reset LEDs Interpreting LED Status Lights LED A indicates the digital-link status between the display controller and the interface. Reset LEDs LED B indicates the display-panel status;...
- Page 7 Specific Interface Plates Reset LEDs Power Reset LEDs DVI B DVI A Power Reset LEDs Power USB Ports Only the C3 display has USB ports on its interface plate. C2 and C5i displays have USB ports on the desktop stand. For more information, see the CX Installation and Maintenance guide.
- Page 8 Connecting the Board, Display, and Power Supply Turn your computer off. Leave the power cord plugged into the grounded outlet. Use CX displays only with the grounded power supply and video cables shipped. Reset LEDs Power Components not to scale to each other.
- Page 9 Plug one end of the DVI cable into the DVI port on the interface plate. Turn the screws to secure the connection. Plug the power supply cord into the power connector on the interface plate. Plug the other end of the DVI cable into the Video 1 port on the installed DX board. Plug one end of the power cord into the power supply.
- Page 10 Installing the Display Driver on Windows XP/2000 Remove the previously installed 63-WINDX driver before you install the 63-W2KDXPCI driver. To remove the 63-WINDX driver Log on with administrator privileges. Insert the WINDX CD. Open the CD folder. Browse to the Win2k directory. Double-click Setup.exe.
- Page 11 Click Next to proceed through installation and start copying files. Click Yes on the Digital Signature Not Found dialog box for each display you install. (On Windows XP systems, the Hardware Installation dialog box is equivalent. Click Continue Anyway to proceed.) Select Yes, I want to restart my computer now, and click Finish.
- Page 12 Changing Display Properties on Windows XP/2000 Log on with administrator privileges. Right-click the desktop. Select Properties > Settings. Select Default Monitor and DOME DX/PCI Properties. Activate Extend my Windows desktop onto this monitor. Select Advanced > DOME. Choose a resolution. Click Apply. Click OK three times.
- Page 13 CX Display Resolutions and Palette Options CX Display Resolution Palette Option 1200 x 1600 Dynamic gray 1600 x 1200 Nonlinear gray Static gray 1536 x 2048 Dynamic gray 2048 x 1536 Nonlinear gray Static gray Pseudocolor True color* 2048 x 2560 Dynamic gray 2560 x 2048 Nonlinear gray...
- Page 14 Using Dome CXtra Through value-added services, the Dome CXtra monitoring and calibration software enhances the functionality of Dome CX displays for viewing medical images in diagnostic settings. All Dome CX displays ship with the CX Edition Base Package. The CX Edition Validation Package is sold separately.
-
Page 15: Cleaning The Lcd Screen
Cleaning the LCD Screen Unplug the power supply before cleaning the display. Dampen a soft, clean cloth with water or a mild cleanser. Wipe the screen gently with the dampened cloth. Use a dry, soft, clean cloth to wipe off the residue. Always wipe off water and other stains immediately to avoid damage to the screen. -
Page 16: Customer Support
E-mail medicalsupport@planar.com • Call (866) PLANAR1 Copyright © 2004 Planar Systems, Inc. Planar, Dome, CXtra, RightLight, and QuickSwitch are either registered trademarks or trademarks of Planar Systems, Inc. Technical information in this document is subject to change without notice. 020-0277-01A...
