- Page 1 brabura G R I D D L E INSTRUCTIONS MANUAL GAS GRIDDLE M O N S A L U D 2 3 | 0 6 2 2 0 V I L L A F R A N C A D E L O S B A R R O S ( B A D A J O Z ) | S P A I N G G E D 0 0 | b r a b u r a g r i d d l e .
- Page 2 Model No: BGG0001 BRABURA L CLASS 40 Model No: BGG0002 BRABURA L CLASS 30 Model No: BGG0003 BRABURA L CLASS 20 0051...
-
Page 3: Table Of Contents
CONTENTS Introduction Safety and warnings Quick reference guide Brabura griddle dimensions Before you begin Lighting instructions Installation Gas connections Leak testing Care and cleaning Troubleshoothing Installer checklist G G E D 0 0 | b r a b u r a g r i d d l e . c o m... -
Page 4: Introduction
INTRODUCTION Welcome to your BRABURA Griddle This manual has been written to help you use your BRABURA Griddle with safety and satisfaction. It includes detailed information about the griddle, the components supplied or installed, its systems, and information about its operation. Please read it carefully, and familiarize yourself with your BRABURA Griddle before you start cooking. -
Page 5: Safety And Warnings
SAFETY AND WARNINGS DANGER IF YOU SMELL GAS Shut off gas to the appliance. Extinguish any open flame. Open the lid. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death. - Page 6 All pipe sealants must be of an approved type and resistant to the actions of butane/propane instructions listed below. Read all the guidance before using the BRABURA Griddle. Do not use a gases. Never use pipe sealant on flared fittings.
-
Page 7: Quick Reference Guide
QUICK REFERENCE GUIDE MODELS DIMENSIONS 40’’ 30’’ 20’’ SPECIFICATIONS 40’’ 30’’ 20’’ Brabura L Class 40 Height 330 mm 330 mm 330 mm Reference BGG0001 BGG0002 BGG0003 Width 506 mm 813 mm 1016 mm Burners Depth Power kW 609 mm... -
Page 8: Brabura Griddle Dimensions
BRABURA GRIDDLE DIMENSIONS BRABURA L CLASS 20” - Chassis + Enameled Cast Iron Cooking Plate 22" 23 15/16" 559mm 609mm 19 15/16" 18 1/2" 506mm 470mm 4 3/4" 120mm 8 1/4" 210mm front profile Enameled Cast Iron Chassis Cooking Plate... - Page 9 BRABURA GRIDDLE DIMENSIONS BRABURA L CLASS 30” - Chassis + Enameled Cast Iron Cooking Plate 32" 23 15/16" 813mm 609mm 29 15/16" 18 1/2" 760mm 470mm 4 3/4" 120mm 8 1/4" 210mm front profile Enameled Cast Iron Chassis Cooking Plate...
- Page 10 BRABURA GRIDDLE DIMENSIONS BRABURA L CLASS 40” - Chassis + Enameled Cast Iron Cooking Plate 40" 23 15/16" 1016mm 609mm 37 15/16" 18 1/2" 963mm 470mm 4 3/4" 120mm 8 1/4" 210mm front profile Enameled Cast Iron Chassis Cooking Plate...
-
Page 11: Before You Begin
BEFORE YOU BEGIN The BRABURA Griddle it is delivered with five AA (1,5V) battery. Ignition Place a battery in the piezoelectric located on the bottom of the chassis. Led Knob * Place four batteries in battery cartridge located on the bottom of the chassis. -
Page 12: Lighting Instructions
Push in and hold the selected dial for 2 seconds before turning to High. Hold for 10 seconds to light the griddle. To turn the BRABURA Griddle off turn the cylinder valve to the off position and then turn all the control knobs on the appliance clockwise to the off position. - Page 13 Adjust the heat by turning the knob to the high/low position. To turn the BRABURA Griddle off turn the cylinder valve to the off position and then turn all the control knobs on the appliance clockwise to the off position.
-
Page 14: Installation
Check with the manufacturer of the siding material for details. BRABURA Griddle is design-certified for use outdoors only and is not intended to be installed in or on recreational vehicles and/or boats. This appliance must be on a level, stable surface in an area clear of combustible material. - Page 15 INSTALLATION - COUNTERTOP Your BRABURA Griddle may be installed on top of a non-combustible counter. The Griddle must be located outdoors only. This appliance must be on a level, stable surface in an area clear of combustible material. Locating the Griddle...
- Page 16 INSTALLATION - BUILT-IN The BRABURA Griddle is designed for easy installation into masonry enclosures. The griddle is intended either for installation in a built-in enclosure constructed of non-combustible materials or for an installation in a built-in enclosure constructed of combustible material when installed with a BRABURA Build-In Liner.
- Page 17 INSTALLATION - BUILT-IN Cutout Dimensions - Combustible Construction with Build-in Liner Combustible constructions refers to a building structure or decorative structure made of wood, compressed paper, plant fibers, vinyl/plastic or other materials that are capable of transferring heat or being ignited and burned. Such material shall be considered combustible even though flame- proofed, fire-retardant treated or surface-painted, or plastered.
-
Page 18: Gas Connections
European Countries where the appliance can be operated. The recall of the gas to be used is indicated on the packaging and on the rating plate of the BRABURA Griddle. The unit has been factory set for use with 28-30/37mbar butane/propane gas in bottle. - Page 19 GAS CONNECTIONS Gas Connection BRABURA Griddle is set up for gas gas. Use butane or propane gas tanks 6 to 13kg and the appropriate Regulator/Hose assembly. The gas tank used, equipped with the regulator/hose assembly, must have a maximum height of 615mm and width of 310mm. If the installation the Griddle is into a enclosure constructed or on the rolling cart gas, the gas tank must have a maximum height of 400mm and depth of 310mm.
-
Page 20: Leak Testing
Advice: Do not modify the appliance Advice: before each use of the BRABURA Griddle clean and inspect the hose. If there is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced prior to the appliance being put into operation. -
Page 21: Care And Cleaning
Use a microfiber pad to polish the enameled cast iron cooking plate until it shines. If your BRABURA Griddle will be not used for a long time, it is recommended to store it in a dry place and protect with a soft cover. -
Page 22: Troubleshoothing
Confirm grease tray positioning Grease tray positioned incorrectly * Example image: BRABURA L CLASS 40’’ G G E D 0 0 | b r a b u r a g r i d d l e . c o m... -
Page 23: Installer Checklist
INSTALLER CHECKLIST Read instructions manual to see if the BRABURA Griddle has been correctly installed. Ensure that installation has been completed correctly before use. Clearances are correctly maintained to combustibles ˆ Proper enclosure ventilation has been verified ˆ All film protection have been removed ˆ... - Page 24 IT´S THE GRIDDLE Share Life v i s i t b r a b u r a g r i d d l e . c o m M O N S A L U D 2 3 | 0 6 2 2 0 V I L L A F R A N C A D E L O S B A R R O S ( B A D A J O Z ) | S P A I N...
