Your safety, and the safety of others, is very important. To help you make informed decisions about safety, we have provided installation
and operating instructions and other information on labels and in this guide. This information alerts you to potential hazards that could
hurt you or others. It is not possible to warn you about all potential hazards associated with this product, you must use your own good
judgment.
CARELESS INSTALLATION AND OPERATION CAN RESULT IN SERIOUS INJURY OR EQUIPMENT DAMAGE.
READ AND UNDERSTAND ALL SAFETY PRECAUTIONS AND OPERATING INSTRUCTIONS BEFORE INSTALLING
AND OPERATING THIS PRODUCT.
This guide identifies potential hazards and has important safety messages that help you and others avoid personal injury or death.
WARNING and CAUTION are signal words that identify the level of hazard. These signal words mean:
WARNING signals a hazard that could cause serious injury or death, if you do not follow recommendations.
CAUTION signals a hazard that may cause minor to moderate injury, if you do not follow recommendations.
This guide uses NOTICE to call attention to important mechanical information, and Note: to emphasize general information worthy of
special attention.
SEVERE INJURY OR DEATH MAY RESULT IF YOU IGNORE ANY OF THE
FOLLOWING.
• Read the Winch Operator's Manual, ATV Operator's Manual, and all warning
labels before operating the winch and ATV.
• Stay clear of moving parts and cable. Keep others away when operating the winch.
• Inspect the winch mechanism, fasteners, and cable, before operating. Replace all
worn or damaged parts before operating.
• Make sure the winch is deactivated when leaving the ATV unattended.
PART NO.
37831
37205
1322
1321
WARN INDUSTRIES
INSTALLATION INSTRUCTIONS
ATV WINCH MOUNT
Mount Kit: PN 37812
Application: SUZUKI QUAD MASTER/QUAD
WARNING
PARTS LIST:
QUANTITY
1
4
8
8
PAGE 1
RUNNER 500
DESCRIPTION
Winch mounting plate
U-Bolt ¼-20
Hex Nut ¼-20
Lock Washer, 1/4
38083 Rev B1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Warn PN 37812
Summary of Contents for Warn PN 37812
- Page 1 This information alerts you to potential hazards that could hurt you or others. It is not possible to warn you about all potential hazards associated with this product, you must use your own good judgment.
- Page 2 INSTRUCTIONS: STEP 1: Remove the four bolts that attach the skid pan and remove the skidpan. STEP 2: Place winch up into the frame of the ATV, below and behind the front bumper. WARN INDUSTRIES PAGE 2 38083 Rev B1...
- Page 3 Do not bolt down the winch at this time. STEP 4: Place the ¼-20 u-bolts into position around the frame and bumper tubes and into the mounting bracket. Tighten with the ¼-20 hex nuts and lock washers. WARN INDUSTRIES PAGE 3 38083 Rev B1...
- Page 4 NOTE: There is an alternate two hole winch mount configuration (not shown in pictures) on mounting plate. When mounting a winch using these holes use hardware and fairlead plate provided with alternate winch. WARN INDUSTRIES PAGE 4 38083 Rev B1...
