Numark NS7FX Service Manual page 6

24. FX Parameter. 360 pots with 11-LED position indicator ring
25. FX Select. 20 position encoder with push switch. Relative CC message
26. FX Wet/Dry. 30mm slide pot
27. MASTER BPM TAP: Tapping this enters the BPM for master FX processing
STANDARD
1. MaxMSP test program for production Line
2. AP fest specification
Voltage
Volume
Distortion defection
S/ N
Separation
F/R
Headphone : UN Balanced:
Volume
S/N
Distortion defection
F/R
RCA Balance Output
AC 100V~240V 50~60Hz
MASTER:3.5 0.5V
BOOTH:3.5 0.5V
BALANCED:12 2V
0.02% below
96dBr upward
94dBr upward
20~20KHz 0.5dB
1. When test is in progress , gain on Input and headphone is set at Max. volume.
2. 300mV 1KHz Sin wave form is input to left plug of Aux Input
7V 1V
85dBr upward
0.05% below
20~20KHz 1dB
