Numark industries dj equipment user manual (52 pages)
Summary of Contents for Numark NS4 FX
Page 1
The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by Numark. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited. If you are not authorized, please contact Numark and destroy all copies of this document.
Page 2
As the owner of the copyright to the Manual, Numark does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of Numark. Numark has no obligation to provide to you any correction of, or supplement to, the Manual, or any new or superseding version thereof.
Page 3
ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED NUMARK SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF THAT ENTITY, AND NUMARK SHALL HAVE NO LIABILITY TO THAT ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
Page 4
The product is exposed to water or excessive moisture, The AC power supply plug or cord is damaged, The product shows an inappropriate change in performance or does not operate normally, or The enclosure of the product has been damaged. Confidential Numark Service Manual...
SERVICE MANUAL MODEL: NS4FX SPECIFICATION FUNCTION 1. UI Browser – A standard detented encoder with push switch is used to navigate through the software. Push encoder to move in the software. 2. LOAD BUTTONS –Push twice to perform instant doubles to the deck in focus. Song will load to the deck(s) currently in focus. 3.
DISASSEMBLY PROCEDURES DISASSEMBLE THE BOTTOM PANEL. (A) REMOVE 22 PCS SCREW FROM THE BOTTOM PANEL. (Fig1)
Page 7
DISASSEMBLE THE WHEEL BASE ASS'Y AND KNOB AND VR KNOB. (A)REMOVE 29 PCS KNOB AND 7 PCS VR KNOB FROM THE TOP PANEL. (B)REMOVE 2 PC DISPLAY PLATE FROM THE WHEEL PLATE. (C)REMOVE 12 PCS SCREW FROM THE WHEEL FIXED HOLDER. (D)REMOVE 4 PCS SCREW AND 2 PCS WASHER FROM THE TOP PANEL.
Page 8
DISASSEMBLE THE PCB ASS'Y OF THE TOP PANEL. (A)REMOVE 4 PCS SCREW FROM THE TOGGLE SWITCH PCB ASS’Y. (B)REMOVE 2 PCS SCREW FROM THE TOP PANEL. (C)REMOVE 3 PCS SCREW FROM THE LEFT FUNCTION PCB ASS’Y. (D)REMOVE 3 PCS SCREW FROM THE LEFT SENSOR PCB ASS’Y. (E)REMOVE 3 PCS SCREW FROM THE RIGHT SENSOR PCB ASS’Y.
Page 9
DISASSEMBLE THE PCB ASS'Y OF THE BOTTOM PANEL. (A)REMOVE 4 PCS AND 1 PC HOLDER SCREW AND 1 PC CABLE CLAMP FROM THE BOTTOM PANEL. (B)REMOVE 3 PCS SCREW FROM THE USB PCB ASS’Y. (C)REMOVE 2 PCS SCREW FROM THE INPUT PCB ASS’Y. (D)REMOVE 3 PCS SCREW FROM THE HP PCB ASS’Y.
