Shoe Clamp Frame
INSTRUCTION MANUAL
Program Ver. *1.60 ~
FCRC20-4
0
IMPORTANT SAFETY INSTRUCTIONS
Use this Manual together with Instruction Manual of embroidery machine for mounting this appliance and for
operating.
Use this appliance only for its intended use as described in this manual. Use only attachments recommended
by the manufacturer as contained in this manual.
Keep fingers away from all moving parts. Special care is required around the sewing machine needle.
Do not pull or push fabric while stitching. It causes damage.
Do not modify this appliance.
SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for HappyJapan HCH Puls
Summary of Contents for HappyJapan HCH Puls
- Page 1 HCH(Puls),HCS2, HCD2,HCD3 Shoe Clamp Frame INSTRUCTION MANUAL Program Ver. *1.60 ~ FCRC20-4 IMPORTANT SAFETY INSTRUCTIONS Use this Manual together with Instruction Manual of embroidery machine for mounting this appliance and for operating. Use this appliance only for its intended use as described in this manual. Use only attachments recommended by the manufacturer as contained in this manual.
-
Page 2: Table Of Contents
INDEX BASIC INFORMATION OF SHOES CLAMP FRAME ..1-1 ACCESSORIES.............. 1-2 ADJUSTMENT OF EMBROIDERY AREA ...... 2-1 ADJUSTMENT OF UPPER ARM ........2-2 INSTALLING THE FRAME ..........3-1 HOOPING SHOES Side of shoes ..............4-1 Tongue ................4-3 STARTING TO EMBROIDER ......... 5-1 ETC. EXCHANGE SPONGE AND SHEET ......6-1 PARTS LIST ..............7-1 PB19... -
Page 3: Basic Information Of Shoes Clamp Frame
BASIC INFORMATION OF SHOE CLAMP FRAME The types of shoe clamp frame are described below. Use correct type of shoe frame for your embroidery machine. CAUTION: To avoid problems. To use shoe clamp frame, select “Special frame” from frame selection menu. Please note that the following functions will be canceled at “Special Frame” mode. * Frame confirmation (embroidery area of frame) * Auto stop function when frame movement exceeds the carriage limit. FRA21D1 FRA21D0 Shoes clamp frame ass’y (for HCD2, HCD3) Shoes clamp frame ass’y (for HCH, HCS2) ACCESSORIES FRA21161 Sponge (2 pcs) FRA21171 Sheet (2 pcs) (packed with frame) PB19... -
Page 4: Adjustment Of Embroidery Area
ADJUSTMENT OF EMBROIDERY AREA Adjust width of the upper arm to meet size of tongue and embroidery design. Width of the arm should have enough margins for embroidery area. Loosen both side knob nuts for adjustment of arm. Tighten all knob nuts after adjustment. Knob nut Knob nut 60mm 0 ~ 100mm 5mm ~ 5mm ~ ADJUSTMENT OF UPPER ARM Please note that basically the upper arm and the lower arm should be parallel at locking posi- tion. In case the thickness of the material is uneven, use adjusting set screw and eccentric pin to change angle of the upper arm to give holding pressure evenly. Upper arm Parallel Lower arm Lever Set screw Left Right Eccentric pin Open Open Close Close PA13... -
Page 5: Installing The Frame
INSTALLING THE FRAME When you use Shoe clamp frame or Side clamp frame, please make machine setting according to frame type se- lected. CAUTION: To avoid problems. The machine and / or frame may be damaged if the incorrect frame settings are used. 1. Turn on the power switch. Indicates the selected frame. Selected frame 2. In case required “Special frame” is already selected, press the and jump to operation no.4. In case selected frame type is not “Special frame”, press 3. Select “Special frame”. 4. Press PA13... - Page 6 INSTALLING THE FRAME 5. Press Iindication of frame type disappears. It means that “Special frame” is selected. When you need to change from Special frame to oth- er type of frame, please powor machine off and start again. Without re-starting machine, machine will move in- correctly. Frame Iindication disappears 6. Press and move the carriage to the position shown by press HCH, HCS2 Machine Carriage HCD2, HCD3 Carriage Machine PA13...
- Page 7 INSTALLING THE FRAME 7. Insert shoe clamp frame to below the fixing HCH, HCS2 Fixing base base of carriage by sliding on bed. Fix knob screws as hitting the bearing Shoes clamp frame against the carriage while pressing the shoe Knob screw Carriage clamp frame to the carriage. Carriage Pushing against Bearing HCD2, HCD3 Knob screw Carriage Fixing base Pushing...
-
Page 8: Hooping Shoes Side Of Shoes
HOOPING SHOES Side of shoes The following is an example to make embroidery on side of sports shoe. 1. Adjust width of the arm to meet size of ma- terial and embroidery design. Width of the arm should have enough mar- gins for embroidery area. Loosen both side knob nuts for adjustment of arm. 5mm~ 5mm~ Tighten all knob nuts after adjustment. Knob nut Knob nut 2. Turn right and left lever to open the upper Upper arm Lever arm. Left Right Open Open Close Close Tongue 3. Remove shoestring. - Page 9 HOOPING SHOES 4. Turn right and left lever, then the shoe will Embroidery area be locked. Please make sure that the material inside of embroidery area is set flat. Please also check that no hard material like eyelet is located in the embroidery area. Lever Shoes support should be inserted in the shoe. Shoes support PA13...
-
Page 10: Tongue
HOOPING SHOES Tongue The following is an example to make embroidery on tongue of sports shoe. 1. Adjust width of the upper arm to meet size of tongue and embroidery design. Width of the arm should have enough mar- gins for embroidery area. Loosen both side knob nuts for adjustment of arm. 5mm~ 5mm~ Tighten all knob nuts after adjustment. Knob nut Knob nut Upper arm 2. Turn right and left lever to open the upper Lever arm. Left Right Open Open Close Close Tongue 3. Remove shoestring. Pull tongue toward outside. - Page 11 HOOPING SHOES 4. Turn right and left lever, then the shoe will Embroidery area be locked. Please make sure that the material inside of embroidery area is set flat. Please also check that no hard material like eyelet is located in the embroidery area. Lever Shoes support should be inserted in the shoe. In case you cannot install shoes support due to shape of the shoe, hold the body of the shoe by hand while making embroidery to prevent the tongue from coming off. Shoes support PA13...
-
Page 12: Starting To Embroider
STARTING TO EMBROIDER Embroidery area Side of shoes Tongue 1. Press and move the frame to the original : Original point (Start point) point with the 2. Press Press , and the embroidering frame moves Backward only when pressing for the design trace. Forward only when pressing You can confirm outline trace and the position of the design. Press , and trace is stopped. Go on to step 4 if you want to start embroidering You can confirm the outline Pause button without tracing. and position of design. -
Page 13: Etc
ETC. EXCHANGE SPONGE AND SHEET Sponge and sheet are located under the upper arm and on the lower arm to hold fabric firmly. When sponge or sheet are worn or damaged, please exchange sponge or sheet. 1. Remove the set screw and disassemble the eccentric pin. Lower arm Sheet 2. Remove the upper arm. Set screw 3. Remove the sponge or sheet from the upper arm or the lower arm. Right side Eccentric pin Sponge Upper arm 4. Attach the sponge to fit with the edge of the upper arm as shown. Upper arm Sponge Lower arm 5. - Page 14 SHOES FRAME FCPA13 HCH, HCS2 HCD2, HCD3...
- Page 15 SHOES FRAME 靴枠 FCPA15 指図 部品番号 部品名 備考 Ass'y El't Parts No. Parts Names Note 1 FRA21D0 Shoes frame ass'y (for HCH, HCS2) 靴枠組（HCH, HCS2用） 2 FRA21D1 Shoes frame ass'y (for HCD2) 靴枠組（HCD2, HCD3用） 3 FRA21F00 Lower arm (right) ass'y 下アーム（Ｒ）組...
- Page 16 HEAD OFFICE 3-3515, Tachiyagawa, Yamagata-city, 990-2251, Japan Phone: +81-23-686-2272 Fax: +81-23-686-2243 TOKYO OFFICE 2-9-5, Taito, Taito-Ku, Tokyo 110-0016, Japan Phone: +81-3-3834-0711 Fax: +81-3-3835-8917 OA01E...
