HCH(Puls),HCS2, HCD2,HCD3 Side Clamp Frame INSTRUCTION MANUAL Program Ver. *1.60 ~ FCRC20-4 IMPORTANT SAFETY INSTRUCTIONS Use this Manual together with Instruction Manual of embroidery machine for mounting this appliance and for operating. Use this appliance only for its intended use as described in this manual. Use only attachments recommended by the manufacturer as contained in this manual.
INDEX BASIC INFORMATION OF SIDE CLAMP FRAME .. 1-1 ACCESSORIES............1-2 ADJUSTMENT OF EMBROIDERY AREA ....2-1 ADJUSTMENT OF UPPER ARM ......2-2 INSTALLING THE FRAME ........3-1 HOOPING MATERIAL ..........4-1 STARTING TO EMBROIDER ........5-1 ETC. EXCHANGE SPONGE AND SHEET ..... 6-1 PARTS LIST ............. 7-1 PB19...
BASIC INFORMATION OF SIDE CLAMP FRAME The types of side clamp frame are described below. Use correct type of side clamp frame for your embroidery machine. CAUTION: To avoid problems. To use side clamp frame , select “Special frame” from frame selection menu. Please note that the following functions will be canceled at “Special Frame”...
ADJUSTMENT OF EMBROIDERY AREA Adjust width of the upper arm to meet size of material and embroidery design. Width of the arm should have enough margins for embroidery area. Loosen both side knob nuts for adjustment of arm. Tighten all knob nuts after adjustment. Knob nut Knob nut 140mm 0 ~ 220mm 5mm ~ 5mm ~ ADJUSTMENT OF UPPER ARM Please note that basically the upper arm and the lower arm should be parallel at locking posi- tion. In case the thickness of the material is uneven, use adjusting set screw and eccentric pin to change angle of the upper arm to give holding pressure evenly.
INSTALLING THE FRAME When you use side clamp frame, please make machine setting according to frame type selected. CAUTION: To avoid problems. The machine and / or frame may be damaged if the incorrect frame settings are used. 1. Turn on the power switch. Indicates the selected frame. Selected frame 2. In case required “Special frame” is already selected, press the and jump to operation no.4. In case selected frame type is not “Special frame”, press 3. Select “Special frame”. 4. Press PA13...
Page 6
INSTALLING THE FRAME 5. Press Iindication of frame type disappears. It means that “Special frame” is selected. When you need to change from Special frame to oth- er type of frame, please powor machine off and start again. Without re-starting machine, machine will move in- correctly.
Page 7
INSTALLING THE FRAME HCH, HCS2 7. Insert shoe frame to below the fixing base of Fixing base carriage by sliding on bed. Side clamp frame Fix knob screws as hitting the bearing Carriage Knob screw against the carriage while pressing the side clamp frame to the carriage. Carriage Pushing against Bearing Carriage HCD2, HCD3 Knob screw Fixing base Pushing against...
HOOPING MATERIAL The following is an example for bag embroidery. 1. Adjust width of the arm to meet size of ma- terial and embroidery design. Width of the arm should have enough mar- gins for embroidery area. Loosen both side knob nuts for adjustment of arm. Tighten all knob nuts after adjustment. 5mm ~ 5mm ~ Knob nut Knob nut Lever Upper arm 2. Turn right and left lever to open the upper arm.
Page 9
HOOPING MATERIAL 4. Turn right and left lever, then the bag will be Embroidery area locked. Please make sure that the material inside of embroidery area is set flat. Please also check that no hard material like metal hook is located in the embroidery area. Space below upper arm Edge of bag should be set in the space be- low upper arm. Lever If the bag is too heavy, use support table to prevent the arm from slanting down. (HCS2) Table PA13...
STARTING TO EMBROIDER Embroidery area (HCS2) 1. Press and move the frame to the original : Original point (Start point) point with the 2. Press Press , and the embroidering frame moves for the design trace. Backward only when pressing You can confirm outline trace and the position of Forward only when pressing the design. Press , and trace is stopped. Go on to step 4 if you want to start embroidering without tracing. You can confirm the outline Pause button and position of design. 3.
ETC. EXCHANGE SPONGE AND SHEET Sponge and sheet are located under the upper arm and on the lower arm to hold fabric firmly. When sponge or sheet are worn or damaged, please exchange sponge or sheet. 1. Remove the set screw and disassemble the Lower arm Sheet eccentric pin. Set screw 2. Remove the upper arm. 3. Remove the sponge or sheet from the upper arm or the lower arm. Right side Eccentric pin Sponge Upper arm 4. Attach the sponge to fit with the edge of Upper arm the upper arm as shown. Sponge Lower arm 5.
Page 12
SIDE CLAMP FRAME FCPA13 HCH, HCS2 HCD2, HCD3...
Page 13
SIDE CLAMP FRAME サイドクランプ枠 FCPA15 指図 部品番号 部品名 備考 Ass'y El't Parts No. Parts Names Note 1 FRA21G0 Side clamp frame ass'y (for HCH, HCS2) サイドクランプ枠組(HCH, HCS2用) 2 FRA21G1 Side clamp frame ass'y (for HCD2) サイドクランプ組(HCD2, HCD3用) 3 FRA21I00 Lower arm long ass'y (right) 下アームロング組(R)...
Page 14
HEAD OFFICE 3-3515, Tachiyagawa, Yamagata-city, 990-2251, Japan Phone: +81-23-686-2272 Fax: +81-23-686-2243 TOKYO OFFICE 2-9-5, Taito, Taito-Ku, Tokyo 110-0016, Japan Phone: +81-3-3834-0711 Fax: +81-3-3835-8917 OA01E...
