TURNTIDE VES-Artex INDC60ODP Operating Instructions Manual

Operating Instructions
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS. Read carefully before attempting to assemble, install, operate or
maintain the
product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could
VES-Artex Industrial
result in personal injury and/or property damage! Retain instructions for future reference.
Ceiling Fan

Description

The VES-Artex model INDC60ODP ceiling fan is a high efficiency, industrial ceiling
fan. It is designed to create air velocity and a cooling effect on high speed. The
lower speeds can be used for reduced velocity or heat de-stratification. The low
speed gently de-stratifies the air giving a constant room temperature. The
INDC60ODP is outdoor rated, ETL Certified in the United States and Canada and
comes with plug and controller.

Unpacking

1. After opening carton, look for concealed damage.
2. If concealed damage is found, immediately file claim with carrier.

Specifications

Model Size Volts
60" 120
INDC60ODP

General Safety Information

Disconnect power
supply before wiring
connections are made to prevent possible
electric shock or damage to equipment.
Read and follow
instructions carefully.
Failure to comply with instructions could
result in fire, electric shock, injury to
persons and/or damage to equipment.
Follow all
Maintenance
procedures enclosed.
Failure to properly
ground unit could
result in severe electrical shock or death.
1. All wiring should conform to the
National Electrical Code in the United
States and local regulations.
2. Make certain the entire installation
is grounded as a precaution against
possible electrical shock.
Amps Watts RPM Down-Rod Down-Rod
0.8 95 250
3. Do not exceed maximum amperage
rating of the ceiling fan as overload-
ing can result in damage to ceiling
fan and control.
4. When wiring an electrical appliance
or device follow all electrical and
safety codes, as well as the most
recent National Electrical Codes
(NEC) and the Occupational Safety
and Health Act (OSHA).

Assembly

1. Remove all ceiling fan parts from the
box.
2. Tools and supplies needed – Flat and
Phillips screwdriver – 9/16" and 3/8"
open wrench or adjustable wrench,
2-3 wire nuts.
Printed in China
Version 2
2020
Type
24" Down Draft
3. Install a junction box to accept the
wiring of the fan. In many cases, a
qualified electrician will be required
to install the outlet box keeping with
local electrical codes or to meet the
National Electrical Codes (NEC).
4. For installation to open web steel
joist – use threaded J-hook as sup-
plied. For wood joist construction
– use J-hook with lag threads. For
attachment in concrete, drill concrete
anchors into the concretes as per
specification applicable to National
Electrical Code procedures.
VES-Artex002
2020
PUM-012-INDC60-01
INDC60ODP
103424
