IV. MAIN SCREEN DESCRIPTION
The regulator is controlled using touch screen.
1
7
6
1. Enter the controller menu
2. Regulator operation mode - the pre-set temperature is selected according to the schedule or manual settings (manual
mode). Touch the screen here to open up a schedule selection panel
3. Current time and date
4. Time left before the next change of the pre-set temperature in current operation mode
5. Pre-set zone temperature - tap on the screen here to edit this value. Once the temperature has been changed manually,
manual mode is activated in the zone
6. Current zone temperature
7. Icon informing about window opening or closing
V.

SCHEDULE

1. SCHEDULE
Pressing this icon activates / deactivates the controller's operating mode according to a set schedule.
2.

SCHEDULE SETTINGS

After entering the schedule editing screen, the schedule may be adjusted to the user's needs. The settings may be
configured for two separate groups of days – the first group in blue, the second one in grey. It is possible to assign up to
3 time periods with separate temperature values to each group. Outside these periods, a general pre-set temperature
will apply (its value may also be edited by the user).
2
5
5
3
4
