After the software has been installed and started, load the
photos. Select the area of the photo which will be
displayed on the screen. The photo may be rotated. After
one photo has been edited, load the next one. When all
the photos are ready, save them in the main folder of the
memory stick. Next, insert the memory stick into the USB
port and activate Photo upload function in the controller
menu.
It is possible to upload up to 8 photos. When uploading
new photos, the old ones are automatically removed from
the controller memory.
• Slide show frequency - This option is used to set the frequency at which the photos are displayed on the screen if the
Slide show is activated.
5.

PRENATAL LOCK

Tapping on Parental lock icon in the main menu opens up
a screen enabling the user to configure the parental lock
function. When this function is activated by selecting
Auto-lock ON, the user may set the PIN code necessary to
access to the controller menu.
NOTE
Default PIN code is „0000".
6.

SOFTWARE VERSION

When this option is selected, the display shows the logo of the manufacturer as well as the software version used in the
regulator.
NOTE
When contacting Service Department of TECH company it is necessary to provide the software version number.
7.

SERVICE MENU

Service menu functions should be configured by a qualified fitter. Access to this menu is protected with a 4-digit code.
8.

FACTORY SETTINGS

This option enables the user to restore factory settings defined by the manufacturer.
9.

MANUAL MODE

This function enables the user to check if the contact to which the heating device is connected works correctly.
10.

LANGUAGE SELECTION

This option is used to select the software language preferred by the user.
10
