Living Spaces 305-P085170 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
hardware which may have come loose inside the carton during shipment. Identify and count all hardware
and compare with the hardware list below.
When placing furniture on non-carpeted flooring, HMI recommends the use of floor protection such as
an area rug or furniture pads. Area rugs and padding not included with purchase.
PARTS LIST
No. Description
1
Headboard
2
Headboard Leg (L&R)
3
Storage Footboard
4
Support Leg
5
Slat roll
6
Center Slat
7
Slat Support Leg
8
Side Rail
Made In Vietnam
L I V I N G S P A C E S
ASSEMBLY INSTRUCTIONS
ITEM 305-P085170 / 175 / 172
5/0 QUEEN STORAGE BED
Sketch Quantity
1
2
1
3
13
2
8
2
HARDWARE LIST
No. Description
A
Allen bolt
B
Lock washer
C
Flat washer
D
Allen key
E
Hanger bolt
F
Hex nut
G
Open wrench
Flat washer
H
Wood screw
K
TOOLS REQUIRED (NOT PROVIDED)
Sketch Size
4mm
12mm
M4 x 1-1/4"
PHILLIPS HEAD SCREWDRIVER
Quantity
8
16
8
1
8
8
1
8
26
Page 1 of 4
