Summary of Contents for Teba therm T-30

  • Page 1 Installation & Manual Boiler With Solid Fuel Model T-30 / T-40...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. SOLID FUEL BOILERS AND EFFICIENCY ............3 2. BOILER SPECIFICATIONS ..................3 3. IMPORTANT POINTS FOR THE HEATING SYSTEM ......4 4. THE PROCEDURES AND SECURITY PRECAUTIONS BEFORE USING THE FLOOR HEATING ...................... 4 5. ELECTRONIC CONTROL SYSTEM INSTALLATION AND USE ....
  • Page 3: Solid Fuel Boilers And Efficiency

    1-5) Automatic ash-discharge system. 1-6) Due to the open circuit of the operating system, there is no expansion of pressure due to the water vapor in the boiler. 2. BOILER SPECIFICATIONS T-30 DEPTH WIDTH HEIGHT FUEL TYPE SOLID FUEL...
  • Page 4: Important Points For The Heating System

    3. IMPORTANT POINTS FOR THE HEATING SYSTEM In a single-storey locations, the installation main piping should be suitable for the boiler outlet diameters (eg, if the boiler outputs are 1 " metal pipe, the main line pipes 1" metal pipe or the inner diameter 1 "could be plastic pipe suitable for the metal pipe.
  • Page 5 3-) On the bottom of the floor, where the boiler will be installed, there must nothing contain that can be ignited such as carpet, wood and plastic pads. If you are going to install the boiler on a wood parquet, an upgrate part should be placed 4-) Chimney needs to be used at the exit of the waste gas.
  • Page 6 10-) As shown in FIG. 2, the expansion tank steam inlet should be connected to the steam outlet of our boiler. This connection prevents the accumulation of pressure by sending water vapor inside the boiler and the air inside the boiler to the expansion tank.
  • Page 7: Electronic Control System Installation And Use

    Note: The amount of hot water to be supplied from our boiler must not exceed 6 lt per minute. The temperature ratio is 75% of the boiler temperature. The boiler water temperature should not be lower than 55° C. 5. ELECTRONIC CONTROL SYSTEM INSTALLATION AND USE 5.1 INSTALLATION 1- The electrical and sensor sockets on the upper part of the solid fuel floor heater are attached to the sockets at the bottom of our electronic control...
  • Page 8 buttons on the right side of the control system to enter the temperature value that you desire the fan motor to terminate the operation. When the boiler temperature reaches this value, the fan automatically deactivates and the operation stops. Moreover, if the boiler temperature drops below the set value, the fan motor automatically switches on and starts running.
  • Page 9: Features Of Electronic Control System

    5.3 FEATURES OF ELECTRONIC CONTROL SYSTEM 1 - Electronic control system is a system that allows you to make the heat control of your boiler comfortable and at the same time, eliminate problems that may arise from low and high heat of the boiler and installation. 2- Due to the LCD display, it provides instant monitoring of the boiler temperature, pump and fan operating status.
  • Page 10: 7, Care And Use Of The Solid Fuel Boiler

    CAUTION: If there is no movement in the circulation pump by removing the 2-socket plug and inserting the electrical plug, remove the yellow screw located in the middle part of the circulating pump. If the shaft does not rotate, rotate it with the screwdriver, and put the yellow screw in place. 3- Cancel the fan by pressing the FAN button on the electronic control system.
  • Page 11 our installation and boiler. Our company is not responsible for damages caused by not adding antifreeze. 5 - Water shortages in the expansion tank must be filled, otherwise the excessive water loss in the boiler and the installation will cause failure in the circulation pump and the plastic materials in the installation.
  • Page 12: General Warranty And Policies

    8. GENERAL WARRANTY AND POLICIES ARAL MAKİNA MADENİ EŞYA SAN. VE TİC.LTD. ŞTİ provides warranty to the buyer within the framework of legal provisions. 2 (two) year warranty period against production defects starts from the actual delivery date. An invoice must be presented for inclusion in the warranty.

This manual is also suitable for:

T-40
