Channel Master CM-1776 Mounting Instructions

Step 1. (Figure 1)
Mounting Antenna Bracket:
Clamp the U-Bolt and the two parts of the
Mounting Brackets around a Mast/Pole.
Install the included 1/2" Nuts onto the U-Bolt and
tighten until the Mounting Brackets are secured to
the Mast/Pole.
(Mounting Bracket and U-Bolt will support Mast/
Pole up to 2" Diameter)
Step 2. (Figure 2)
Attaching Mounting bracket to the antenna:
Place the Boom Clamp around the Antenna Boom
(antenna square tube), then attach the Boom
Clamp to the mounting bracket using the included
1/2" Bolts.
For Video
Scan
Tutorial
Additional product information including videos and frequently asked questions is
Warranty Information is available online at www.channelmaster.com/warranty
(Fig.1)
U-Bolt
1/2" Nuts
Mounting
Brackets
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
(Fig.2)
Antenna
Boom
MORE INFORMATION
available at www.channelmaster.com/support
www.channelmaster.com
Antenna Mast/Pole
(Not Included)
1/2" Bolts
Boom Clamp
CM-1776 MOUNTING BRACKET REV-A 9/15/2021
