Summary of Contents for Thermo Scientific OGS 60

  • Page 2 ® Heratherm is a registered trademark of Thermo Scientific. Thermo Scientific is a brand owned by Thermo Fisher Scientific Inc. All other trademarks mentioned in the operating instructions are the exclusive property of the respective manufacturers. Thermo Electron LED GmbH Robert-Bosch-Straße 1...

  • Page 3: Table Of Contents

    Floor stand unit spacers (not with 3P units) ..................3-14 Chapter 4 Product Description ......................4-1 Heratherm OGS Series Oven Overview ..................... 4-1 Heratherm OMS Series Oven Overview..................... 4-8 Safety Devices........................... 4-10 Work Space Atmosphere ........................4-10 Thermo Scientific Heratherm...
  • Page 4 Stopping a Timer..........................7-8 Settings............................... 7-9 Error Log............................7-9 Calibration ........................... 7-10 Temperature Display Unit......................7-11 Configuration ..........................7-12 Chapter 8 Shut-down ........................8-1 Shutting the Oven Down ........................8-1 Chapter 9 Cleaning and Disinfection....................9-1 Cleaning ............................. 9-1 Heratherm Thermo Scientific...
  • Page 5 Replacing the Power Cord.........................10-4 Returns for Repair..........................10-4 Chapter 11 Disposal...........................11-1 Overview of Materials Used ......................11-1 Chapter 12 Error Codes........................12-1 Chapter 13 Technical Data ........................13-1 Chapter 14 Spare Parts and Accessories ..................14-1 Chapter 15 Device Log ........................15-1 Chapter 16 Contact ..........................16-1 Thermo Scientific Heratherm...
  • Page 6 Contents Heratherm Thermo Scientific...
  • Page 7 List of Figures Figure 3-1 Table-top oven units OGS 60 / OGS 100 / OGS 180, dimensions and required clearances ....3-5 Figure 3-2 Floor stand ovens OGS 400, dimensions and required clearances ............3-6 Figure 3-3 Floor stand ovens OGS 750, dimensions and required clearances ............3-7 Figure 3-4 Lift Points.............................
  • Page 8 List of Figures Figure 10-1 Door seal replacement (example showing OMH Series oven) ............. 10-4 Heratherm Thermo Scientific...

  • Page 9: Chapter 1 Safety Notes

    • Keep these operating instructions close to the oven so that safety instructions and important information are always accessible. • Should you encounter problems that are not detailed adequately in these operating instructions, please contact Thermo Electron LED GmbH immediately for your own safety. Thermo Scientific Heratherm...

  • Page 10: Operational Safety Rules

    • an installation verification test is performed on commissioning the oven for the first time and repeated after each inspection and repair activity. The warranty is valid from the date of delivery of the oven to the customer. Heratherm Thermo Scientific...

  • Page 11: Explanation Of Safety Information And Symbols

    Indicates a hazardous situation which, if not avoided, could result in death or serious injuries. Indicates a situation which, if not avoided, could result in damage to equipment or property. Is used for useful hints and information regarding the application. Thermo Scientific Heratherm...

  • Page 12: Additional Symbols For Safety Information

    Safety Notes Explanation of Safety Information and Symbols Additional symbols for safety information Wear safety gloves! Wear safety goggles! Harmful liquids! Electric shock! Hot surfaces! Fire hazard! Explosion hazard! Suffocation hazard! Danger of tipping! Heratherm Thermo Scientific...

  • Page 13: Symbols On The Oven

    To avoid the risk of explosion do not load the oven with tissue, material, or liquids that: • are easily flammable or explosive, • release vapor or dust that forms combustible or explosive mixtures when exposed to air; • release poisons, • create a humid atmosphere, Thermo Scientific Heratherm...

  • Page 14: Standards And Directives

    Additionally, the oven is in compliance with many other international standards, regulations and directives not listed here. Should you have any questions regarding compliance with national standards, regulations and directives applicable for your country, please contact your Thermo Fisher Scientific sales organization. Heratherm Thermo Scientific...

  • Page 15: Chapter 2 Delivery Of The Oven

    Risk of injury Should sharp edges have formed in damaged areas or elsewhere on the device, take all necessary precautions to protect personnel handling the oven. For example, have them wear protective gloves and other personal protection equipment. Thermo Scientific Heratherm...

  • Page 16: Scope Of Supply

    Scope of Supply Ovens Quantity of components supplied (pieces) OGS Series OMS Series Wire-mesh shelf Support rail for shelf (for table-top units only) Shelf support Power cord Clip springs (for table-top units only) Operating manual Short reference guide Heratherm Thermo Scientific...

  • Page 17: Chapter 3 Installation

    Thermo accessory) should be used, which can be connected to the air exhaust port with a draft interrupter. If several built-in units in a row are connected to a central air exhaust system (see illustration), a draft interrupter should be installed. Fig. 2 Fig. 1 Thermo Scientific Heratherm...

  • Page 18: Intermediate Storage

    When the oven is placed in intermediate storage, which is permissible for a maximum of four weeks, make sure that the ambient temperature is between 20 °C to 60 °C (68 °F to 140 °F) and the maximum relative humidity does not exceed 90%, non-condensing. Heratherm Thermo Scientific...

  • Page 19: Room Ventilation

    • Mark hot exhaust air piping with appropriate hot surface warning signs or restrict access to such piping altogether to avoid the risk of injury through contact with hot surfaces. Thermo Scientific Heratherm...

  • Page 20: Space Requirement

    After connecting the built-in unit to the electrical power supply, avoid damaging the power cord, then sliding into the installation position. When installing the oven, make sure that the installation and supply connections remain freely accessible. The specified side clearances represent minimum distances. Heratherm Thermo Scientific...

  • Page 21: Figure 3-1 Table-Top Oven Units Ogs 60 / Ogs 100 / Ogs 180, Dimensions And Required Clearances

    Installation Space Requirement Table-top units Figure 3-1 Table-top oven units OGS 60 / OGS 100 / OGS 180, dimensions and required clearances Table 3-1 Heratherm Oven Dimensions Type A (mm/inch B (mm/inch) C (mm/inch D (mm/inch) OGS 60 / OMS 60 530 / 20.8...

  • Page 22: Floor Stand Units

    * Depth of handle /display (66 mm/2.6 in) not included in overall depth specified. The width of the hinge (23 mm) is not included in the overall width. Table 3-4 Required Clearances E (mm/inch) F (mm/inch) H (mm/inch) I (mm/inch) 120 / 4,7 50 / 2,0 200 / 7,9 200 / 7,9 Heratherm Thermo Scientific...

  • Page 23: Figure 3-3 Floor Stand Ovens Ogs 750, Dimensions And Required Clearances

    Depth of handle /display (66 mm/2.6 in) not included in overall depth specified. The width of the hinge (23 mm) is not included in the overall width. Table 3-6 Required Clearances E (mm/inch) F (mm/inch) H (mm/inch) I (mm/inch) 120 / 4.7 50 / 2.0 200 / 7.9 350 / 13.8 Thermo Scientific Heratherm...

  • Page 24: Transport

    Protection Equipment, such as safety shoes, when lifting the oven. To avoid crushing your fingers or hands (particularly in a closing door) or damaging the oven, do not use any other lift points than those indicated in the illustration above. Heratherm Thermo Scientific...
  • Page 25 Before moving the unit, ensure that it has been unplugged. Move the Heratherm floor stand units with caution. Quick starts and stops can result in tipping! Always ensure that the doors are closed when moving the unit. Thermo Scientific Heratherm...

  • Page 26: Stacking Kit

    Slotted screwdriver 5,5x100 or Torx screwdriver 20x100. Installing the Stacking Feet Remove the left and right blank plugs at the top blank. Install the stacking feet with the enclosed screws using a slotted or Torx screwdriver. 3-10 Heratherm Thermo Scientific...

  • Page 27: Installing The Stacking Adapter

    • The levelling feet on the top device must be screwed in all the way. • The levelling feet of the top device must be aligned with and placed exactly on the stacking pads of the stacking adapter. • The anti-tilt anchor must be installed on the top device. Thermo Scientific Heratherm 3-11...

  • Page 28: Installing The Anti-Tilt Anchor

    Position the unit with the anti-tilt anchor to in an angle of approx. 90° +/- 20%. Take care that the stacking feet of the unit are still in correct place on the lower unit or on the stacking adapter. Fix the anti-tilt anchor to a solid part of the building. 3-12 Heratherm Thermo Scientific...
  • Page 29 Additionally, the following caution notes must be heeded at all times: Risk of overheating with stacked devices To avoid the risk of electrical components and the outer enclosure overheating or temperature control failing due to insufficient ventilation, do not exceed the specified stacking height! Thermo Scientific Heratherm 3-13...

  • Page 30: Floor Stand Unit Spacers (Not With 3P Units)

    Separate and move each device one by one, then restack them. Thermo Scientific accepts no responsibility or liability whatsoever with regard to stacked third party devices; this is at the user’s own risk.

  • Page 31: Chapter 4 Product Description

    • high-precision work space temperature control, adjustable in steps of one degree up to 250 °C/626 °F; • a mechanically-operated damper for venting the work space, equipped with an external slider; • a countdown timer for timed process control; • an On/Off-timer; • two wire-mesh shelves; Thermo Scientific Heratherm...

  • Page 32: Figure 4-1 Heratherm Ogs 60 / Ogs 100 / Ogs 180 Series Front View

    Heratherm OGS Series Oven Overview The individual features of OGS Series ovens are shown in the figures below. Figure 4-1 Heratherm OGS 60 / OGS 100 / OGS 180 Series Front View Outer door Door latch cutout Door latch and handle...

  • Page 33: Figure 4-2 Heratherm Ogs 60 / Ogs 100 / Ogs 180 Series Rear View

    Product Description Heratherm OGS Series Oven Overview Figure 4-2 Heratherm OGS 60 / OGS 100 / OGS 180 Series Rear View Door latch and handle Control panel Stacking pad Spacer Mechanical air inlet slider [10] - [11] Electronics compartment [12] Levelling foot...

  • Page 34: Figure 4-3 Heratherm Ogs 400 Series Front View

    Door hook catch Temperature sensor Exhaust air tube [10] - [11] - [12] - [13] - [14] - [15] - [16] - [17] - [18] - [19] - [20] - [21] - [22] - [23] Air baffle, side Heratherm Thermo Scientific...

  • Page 35: Figure 4-4 Heratherm Ogs 400 Series Rear View

    Figure 4-4 Heratherm OGS 400 Series Rear View Outer door Unit caster [10] - [11] Exhaust air tube [12] Anti-tilt anchor [13] Electronics compartment [14] Inlet air tube [15] Hinge [16] Handle [17] Display [18] Nameplate on sidewall Thermo Scientific Heratherm...

  • Page 36: Figure 4-5 Heratherm Ogs 750 Series Front View

    [10] Door hinge [11] - [12] - [13] - [14] - [15] - [16] - [17] - [18] - [19] - [20] - [21] - [22] - [23] Air baffle, side [24] Main switch (only with 3P units) Heratherm Thermo Scientific...

  • Page 37: Figure 4-6 Heratherm Ogs 750 Series Rear View

    Unit caster [10] - [11] Exhaust air tube [12] Anti-tilt anchor [13] Electronics compartment [14] Inlet air tube [15] Hinge [16] Handle [17] Display [18] Nameplate on sidewall [19] Hinge [20] Power cord (only with 3P units) Thermo Scientific Heratherm...

  • Page 38: Heratherm Oms Series Oven Overview

    Support rail for wire mesh shelf Shelf support [10] Fan cover, integrated into air baffle [11] Door hook catch [12] Air baffle [13] Door seal [14] Stacking pad [15] Spring for air baffle [16] Temperature sensor [17] Exhaust air tube Heratherm Thermo Scientific...

  • Page 39: Figure 4-8 Heratherm Oms Series Rear View

    Product Description Heratherm OMS Series Oven Overview Figure 4-8 Heratherm OMS Series Rear View Door latch and handle Control panel Stacking pad Spacer Exhaust air tube Mechanical air inlet slider [10] - [11] Electronics compartment [12] Levelling foot Thermo Scientific Heratherm...

  • Page 40: Safety Devices

    [1] is mounted in the top panel of the work space compartment. Figure 4-9 Sensor Mounting Location - OGS Series and OMS Series - Table-top units Figure 4-10 Sensor Mounting Location - OGS Series and OMS Series - Floor stand units 4-10 Heratherm Thermo Scientific...

  • Page 41: Data Communications & Alarm Interface

    The RS- 232 interface (see figure 4-11) may be used to connect ovens to the serial interface port of a computer to allow for the computer-aided acquisition and documentation of major operating parameters (temperature, error codes, etc.). Thermo Scientific Heratherm 4-11...

  • Page 42: Ac Power Socket

    Two 16 A slow-blow fuses mounted on the oven’s main electronic circuit board protect internal circuitry from the impact of excessive power consumption. Replacement should only be carried out by skilled and authorized qualified personnel of electrotechnology/signal engineering! 4-12 Heratherm Thermo Scientific...

  • Page 43: Work Space Components

    For details on using the shelf system, see the section “Start-up” page 5-1. Spring Air baffle, side Support rails Wire-mesh shelf Air baffle, bottom Figure 4-13 Shelf System - OGS Series Oven - Table-top units Thermo Scientific Heratherm 4-13...

  • Page 44: Tube Access Ports

    19/0.75 or 53/2.09 24/0.95 or 58/2.28 24/0.95 or 58/2.28 24/0.95 or 58/2.28 The tube access ports are mounted in fixed locations in the side and top panels (see figure 4-15). 4-14 Heratherm Thermo Scientific...

  • Page 45: Figure 4-15 Tube Access Ports

    Risk of Burning on Hot Surface The surface around the tube access ports may become extremely hot. Thermo Scientific Heratherm 4-15...
  • Page 46 Product Description Tube Access Ports 4-16 Heratherm Thermo Scientific...

  • Page 47: Chapter 5 Start-Up

    • Push the retaining spring [1] into the guide on the support rail [2], making sure that the locking nub [3] on the retaining spring safely engages with the matching hole in the support rail. Figure 5-1 Sliding the Retaining Spring into the Support Rail Thermo Scientific Heratherm...

  • Page 48: Installing The Shelving

    Air baffle, lateral Shelf support Wire-mesh shelf Air baffle, bottom Figure 5-2 OGS Series - Installing the Shelving Retaining spring rear Air baffle, Shelf support Wire-mesh shelf Support rail Figure 5-3 OMS Series - Installing the Shelving Heratherm Thermo Scientific...

  • Page 49: Preparing The Work Space

    [3] must be facing upwards. 1. Place the support rail [4] on the lower embossing [6] and tilt it upwards against the work space side wall so that the rail is positioned over the two embossings at [5] and [2]. Thermo Scientific Heratherm...

  • Page 50: Installing An Uninstalling The Rear Air Baffle (Oms Series Only)

    Place the air baffle on the lower embossings and tilt it upwards against the back wall of the work space. 4. Clamp the two retaining springs [2] into the upper embossings. 5. Secure the air baffle to the work space back wall by fastening the two screws at [1]. Heratherm Thermo Scientific...

  • Page 51: Installing And Uninstalling The Lateral Air Baffles (Ogs Series Only)

    2. Grab the two retaining springs [1] at their tabs and pull them downwards out of the embossings, then pull off the lateral air baffle. Risk of damage to sensor! To prevent accidental damage, be sure to avoid collision with the sensor when installing or uninstalling panels in the oven‘s workspace. Thermo Scientific Heratherm...

  • Page 52: Figure 5-8 Removing The Lateral Air Baffle

    Place the lateral air baffle on the lower embossings and tilt it upwards against the side wall of the work space. 4. Clamp the two retaining springs [1] into the upper embossings. 5. Replace the bottom panel into the embossings and secure it by fastening the two screws at [1]. Heratherm Thermo Scientific...

  • Page 53: Commissioning Of Floor-Mounted Units

    Loosen and remove the eight (8) screws for the left and right support profiles and then take out the lateral air baffles. Figure 5-11 Removing the rear air baffle OGS 400/750 On the OGS 400/750 model remove the ten (10) screws for the rear air baffle and then remove the air baffle. Thermo Scientific Heratherm...

  • Page 54: Commissioning, General

    Horizontal position of support rails Please note the alternating sequence of round and oblong holes. Be sure to use the correct pair of opposite holes, so the support rails are truly horizontal. Figure 5-12 Shelf Support Bracket Installation Heratherm Thermo Scientific...

  • Page 55: Installing The Wire-Mesh Shelves

    The oven has a class I, protection-earthed enclosure. To minimize the risk of electrical shock, use the AC power cord supplied to connect the oven to a correctly installed and protection-earthed power supply source, with the following features in place for each oven: • T 16 A slow-blow fusing Thermo Scientific Heratherm...

  • Page 56: Connection To The Power Supply Source

    Make sure that power outlets remain freely accessible at all times! In an emergency the power connection must be rapidly disconnectable; so be sure to have the power outlets freely accessible at all times! Figure 5-14 AC Power Supply Socket 5-10 Heratherm Thermo Scientific...

  • Page 57: Connecting The Rs-232 Interface

    2. Route the serial interface cable along a path that does not cross hot exhaust air piping, tables, aisles or passageways. With stacked devices, keep the serial interface cable away from hot spots on the other oven in the stack. Thermo Scientific Heratherm 5-11...
  • Page 58 — XXXXXX: is the significant status information queried; — cc: is a check sum (technically an inverted XOR of all bytes returned, excluding the check sum bytes and the <CR> character); — <CR> is for carriage return. 5-12 Heratherm Thermo Scientific...
  • Page 59 Combined Date and Time ?:0010:00::c1 !:0010:11:31.07.10;01:02:23:e2 Date Time Date only ?:0011:00::c0 !:0011:08:31.07.10:d2 Date Time only ?:0012:00::c3 !:0012:08:01:02:23:dc Time Temperature Set Value (T1); Current Work Space Temperature (T2); Reference Temperature (T3); Sample Sensor Temperature (T4) ?:3010:00::c2 !:3010:1f:+125.00;+124.96;+000.000;+000.00:b0 Thermo Scientific Heratherm 5-13...
  • Page 60 Start-up Connecting the RS-232 Interface 5-14 Heratherm Thermo Scientific...

  • Page 61: Chapter 6 Operation

    •refrain from loading the oven with any of the substances listed in the section “Incorrect Use” page 1-5 • make sure that the ambient air is free of any solvents • do not operate the oven in areas with an explosion hazard Thermo Scientific Heratherm...
  • Page 62 To ensure sufficient air circulation and uniform heating of the samples, do not use more than 70% of the maximum surface area of the work space. Bulky objects in the work space that dissipate heat may impair heat distribution. Heratherm Thermo Scientific...

  • Page 63: Chapter 7 Handling And Control

    The display returns to its default mode upon completion of adjustments or whenever no entries have been made for a period of 30 seconds. The graphic below shows the Heratherm OGS 60/100/180/400/750 and Heratherm OMS 60/100/180 control panel with all of its visualization elements and controls.
  • Page 64 The table below contains brief descriptions of the display features of the control panel (items D1 through D3 in figure 7-1; the identifiers through refer to the buttons shown in that figure). Heratherm Thermo Scientific...
  • Page 65 Invokes a submenu with the following functions: - Read access to error log - Calibrating the oven - Toggling the temperature display unit between °C and ° F - Entering a configuration control code (Instructions: “Settings” page 7-9) Thermo Scientific Heratherm...
  • Page 66 ). Unlike other menu items, this icon cannot be selected. Button Inactivity Monitoring When no button is pressed for more than 30 seconds in any selected menu item, the display exits from the selected screen and returns to default display mode. Heratherm Thermo Scientific...

  • Page 67: Powering Up

    7-1) and a residual heat temperature readout in case the work space temperature is still 50 °C/122 °F. The oven is switched off ≥ now. 2. If required, unplug the AC power plug to power down the oven completely. Thermo Scientific Heratherm...

  • Page 68: Temperature Set Value

    0 ° C (32 ° F), press to confirm your settings. The display returns to its default mode. The actual temperature measured in the work space and shown in the temperature display area starts to drop, showing the progress of the cool-down process. Heratherm Thermo Scientific...

  • Page 69: Timer

    Table 7-7 Setting a Countdown-type On Timer Press to activate the menu bar, then use select the Timer icon and press to confirm. The word OFF appears in the multifunctional display pane. Thermo Scientific Heratherm...

  • Page 70: Stopping A Timer

    To cancel a pre-programmed on timer while the oven is switched off, hold the On/Off button depressed for a few seconds. In the menu bar, the Timer icon will go out. The display returns to its default mode. Heratherm Thermo Scientific...

  • Page 71: Settings

    E01 (Error 01). This entry represents the most recently registered error. After a few seconds, the display pane automatically switches to the internal error code - for example, 109. E01 shows the latest fault, E22 shows the oldest fault. Thermo Scientific Heratherm...

  • Page 72: Calibration

    Table 7-11 Entering the Calibration Reference Temperature Manually Press to activate the menu bar, then use to select the Settings icon and press confirm. Press to switch to the CAL(ibration) menu item and press to confirm. 7-10 Heratherm Thermo Scientific...

  • Page 73: Temperature Display Unit

    Settings icon and press confirm. Press to switch to the C - F menu item. The text C - F is flashing in the display pane. Thermo Scientific Heratherm 7-11...

  • Page 74: Configuration

    Settings icon and press confirm. Press to switch to the ConF(iguration) menu item. The word ConF will be flashing in the multifunctional display pane. Press the button. 7-12 Heratherm Thermo Scientific...
  • Page 75 The display returns to its default mode. The Settings icon in the menu bar will go out. Enter the four-digit code ‘1234’ to reset the user calibration. Enter the four-digit code ‘4321’ to reset the sensor sample calibration. Thermo Scientific Heratherm 7-13...
  • Page 76 Handling and Control Switching the Oven Off / Powering Down 7-14 Heratherm Thermo Scientific...

  • Page 77: Chapter 8 Shut-Down

    2. Turn the oven off using the control panel. 3. Unplug the power connector and secure it against accidental reconnection. 4. Until the oven is shut down, the work space must be continuously ventilated. Leave the door open and secure it against accidental closure. Thermo Scientific Heratherm...
  • Page 78 Shut-down Shutting the Oven Down Heratherm Thermo Scientific...

  • Page 79: Chapter 9 Cleaning And Disinfection

    Wipe the surfaces clean using a clean cloth and clear water. Then, wipe the surfaces dry using a clean cloth. Wipe / Spray Disinfection The manual wipe and spray disinfection is the following process: • predisinfection • cleaning as appropriate for the current application. Thermo Scientific Heratherm...

  • Page 80: Preparing The Manual Wipe/Spray Disinfection

    Contact with live electrical components may cause a lethal electric shock. Before connecting the oven to the power supply, check the power cord and the plug for damage. Do not use damaged cables for connecting the oven to the power source! Heratherm Thermo Scientific...

  • Page 81: Predisinfection

    2. Spray disinfectant onto the surfaces of the work space and of the accessories or wipe the surfaces clean using disinfectant. 3. Allow time for the disinfectant to act as specified by the manufacturer. Moisture-sensitive components Spray the sensor with disinfectant. Thermo Scientific Heratherm...
  • Page 82 Cleaning and Disinfection Wipe / Spray Disinfection Heratherm Thermo Scientific...

  • Page 83: Chapter 10 Maintenance

    • Perform electrical safety check in accordance with the relevant national regulations. Functional check If safety devices were removed or disabled for inspections, the oven must not be operated before the safety devices have been reinstalled and checked for their correct function. Thermo Scientific Heratherm 10-1...

  • Page 84: Service Intervals

    During this process, the temperature controller of the oven is set to the value measured during the temperature comparison measurement. Use a calibrated measuring instrument with an accuracy of < ± 1 °C (1.7 °F) for this test. 10-2 Heratherm Thermo Scientific...

  • Page 85: Comparison Measurement Procedure

    For detailed instructions on how to perform a manual temperature calibration, please refer to the instructions in the section “Calibration” page 7-10. Excessive Work Space Temperatures Excessive work space temperatures subsequent to a calibration run can be reduced by leaving the door open for approx. 30 seconds. Thermo Scientific Heratherm 10-3...

  • Page 86: Replacing The Door Seal

    Using a standard power cord with a lower temperature withstand class is prohibited. Returns for Repair Prior to returning any materials, please contact our Technical Services Department for a “Return Materials Authorization” number (RMA). Material returned without an RGA number will be returned. 10-4 Heratherm Thermo Scientific...
  • Page 87 • Clean the oven components thoroughly, then disinfect or decontaminate them (depending on application). • Fill in and attach a safety declaration with details on decontamination activities performed to the items that are to be repaired. Thermo Scientific Heratherm 10-5...
  • Page 88 Maintenance Returns for Repair 10-6 Heratherm Thermo Scientific...

  • Page 89: Chapter 11 Disposal

    Oven rear panel Galvanized steel sheet Outer door Galvanized steel sheet, painted Door inner panel OMS and OGS Series: Stainless steel 1.4301 Control panel and display window Polyethylene protective foil Heater Stainless steel-sheathed resistance heater wires Thermo Scientific Heratherm 11-1...
  • Page 90 Stainless steel 1.4301; shelves are nents and shelves chrome-plated Door frame seal Silicone Fan impeller Stainless steel 1.4016 (OMS Series only) Cables Plastic-sheathed stranded copper wire Packaging Corrugated board, polyethylene film, and styrofoam, chemically untreated wood 11-2 Heratherm Thermo Scientific...

  • Page 91: Chapter 12 Error Codes

    Power Down Error Power has been cut off Audible alarm activated, (E007) (power outage) while the alarm relay energized, ply. Power up then device was running. message shown on dis- device, then acknowledge play. the alarm by pressing Thermo Scientific Heratherm 12-1...
  • Page 92 If this doesn’t calibration references. shown on display. solve the problem, call service. 12-2 Heratherm Thermo Scientific...
  • Page 93 Note: This error does not indicate a defective triac. For 3P-units only: when set-point tempera- ture is stabilized, switch unit to Standby Mode and turn-on again. If unit can- not keep temperature without failure please call Technical Support. Thermo Scientific Heratherm 12-3...
  • Page 94 1.The rectification of an error is deemed to have been successful when the audible alarm stops sounding, the alarm relay drops out and the message disappears from the control panel display. 12-4 Heratherm Thermo Scientific...
  • Page 95 230 V/50 Hz. Options may have an impact on the specified performance. Table 13-1 Technical Data - OGS and OMS Series - Table-top units Parameter Unit OGS 60 OGS 100 OGS 180 OMS 60 OMS 100...
  • Page 96 Technical Data Table 13-1 Technical Data - OGS and OMS Series - Table-top units Parameter Unit OGS 60 OGS 100 OGS 180 OMS 60 OMS 100 OMS 180 Loading capacity Loading capacity per shelf kg/lbs 25/55 25/55 Max. overall loading...
  • Page 97 Technical Data Table 13-1 Technical Data - OGS and OMS Series - Table-top units Parameter Unit OGS 60 OGS 100 OGS 180 OMS 60 OMS 100 OMS 180 Minimum bottom clear- mm/in 200/8 200/8 ance Minimum top clearance mm/in 300/12 300/12 Temperatures as low as ambient +10 °C can be selected, this requires open damper and no additional...
  • Page 98 670 / 26.4 670 / 26.4 Minimum back wall clearance mm/in 120/5.9 Minimum top clearance mm/in 200/8 Temperatures as low as ambient +10 °C can be selected, this requires open damper and no additional heat in unit. 13-4 Heratherm Thermo Scientific...

  • Page 99: Chapter 14 Spare Parts And Accessories

    Kit fresh air filter for Heratherm ovens 50127431 Outer door for Heratherm IGS 60, IMH 60, IMH 60-S, OMS 60, OMH 60, OMH 60-S, OGS 60, OGH 60 and OGH 60-S with a door stop on the left side 50127432...
  • Page 100 Magnetic door hook catch for Heratherm incubators and heating & drying ovens with a door stop on the left side 50127499 Heating coils for Heratherm OGS 60, OGH 60, OGH 60-S at a voltage of 120 V 50127500 Heating coils for Heratherm OGS 60, OGH 60, OGH 60-S at a...
  • Page 101 Support stand with castors for Heratherm 100L 50127743 Support stand with castors for Heratherm 180L 50127761 Wire mesh shelf OGS 60 / OGH 60 / OGH 60-S, including 2 shelf supports 50127762 Wire mesh shelf OGS 100 / OGH 100 / OGH 100-S, including 2 shelf...
  • Page 102 Door outer casing left HTM 750 50135063 Door outer casing right HTM 750 50135151 Kit temperature sensor cpl HTM ovens floor 50135152 Kit overtemperature cut-off HTM ovens 350 floor 50135153 Kit door lock 400 right cpl HTM 14-4 Heratherm Thermo Scientific...
  • Page 103 Kit fan system Heratherm D=180 mm (7.1 inch) 208V 50136841 Kit fan system for Heratherm D=180 mm (7.1 inch) 230V 50136842 Kit fan system for Heratherm D=160 mm (6.3 inch) 208V 50136843 Kit fan system for Heratherm D=160 mm (6.3 inch)230V Thermo Scientific Heratherm 14-5...
  • Page 104 Spare Parts and Accessories 14-6 Heratherm Thermo Scientific...

  • Page 105: Chapter 15 Device Log

    Device Log Oven type: Part number: Serial number: Service number: Installation location Operator’s note: Work carried out Remarks Date Signed: Thermo Scientific Heratherm 15-1...
  • Page 106 Device Log 15-2 Heratherm Thermo Scientific...

  • Page 107: Chapter 16 Contact

    Enquiries from Europe, Middle East and Africa: Phone. + 49 (0) 6184 / 90-6940 + 49 (0) 6184 / 90-6772 E-Mail info.labequipment.de@thermofisher.com Postal address USA: Thermo Scientific 275 Aiken Road Asheville, NC 28804 Enquiries from North America: Phone +1 800-879 7767 +1 828-658 0363 Email info.labequipment@thermofisher.com...
  • Page 108 Contact 16-2 Heratherm Thermo Scientific...
  • Page 109 Contact Thermo Scientific Heratherm 16-3...
