i-PRO WV-S1536LNS Installation Manual

Installation Guide
Included Installation Instructions
Network Camera
For professional use only
WV-S1536LNS
Model No.
(Heavy salt damage resistance)
About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (this document): Provides information about "Precautions",
"Precautions for installation" and the installation method.
• Basic Information (Refer to the link on the following support website):
Provides information about "Precautions for use", "Parts and functions" and "Detail
specifications".
• Operating Instructions (Refer to the link on the following support website):
Explains how to perform the settings and how to operate this camera.
https://i-pro.com/global/en/surveillance/training-support/documentation-database-list
"<Control No.: C****>" used in these documents should be used to search for information
on our technical information website
(https://i-pro.com/global/en/surveillance/training-support/support/technical-information)
and will guide you to the right information.
• Before attempting to connect or operate this product, please read these instructions
carefully and save this manual for future use.
• microSDXC/ microSDHC/ microSD memory card is described as microSD memory card.
• The external appearance and other parts shown in this manual may differ from the actual product within the
scope that will not interfere with normal use due to improvement of the product.
i-PRO Co., Ltd.
Fukuoka, Japan
https://www.i-pro.com/
© i-PRO Co., Ltd. 2022
Disposal of Old Equipment and Batteries
Only for European Union and countries with recycling systems
These symbols on the products, packaging, and/or accompanying documents mean that used
electrical and electronic products and batteries must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to
applicable collection points in accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and prevent any potential
negative effects on human health and the environment.
For more information about collection and recycling, please contact your local authority.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
Note for the battery symbol (bottom symbol)
This symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical involved.
For U.S.A.
NOTE: This equipment has been tested and found
to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment
is operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at his
own expense.
For U.S.A.
The model number and serial number of this prod-
uct may be found on the surface of the unit.
You should note the model number and serial num-
ber of this unit in the space provided and retain this
book as a permanent record of your purchase to aid
identification in the event of theft.
Model No.
Serial No.
For Canada
CAN ICES-3(A)/NMB-3(A)
La capacité
Méthode Vis de fixation de traction
d'installation recommandée minimale
requise
Quand la caméra
M4 × 16 mm
vidéo est directement
{5/8 pouces} 724 N {163 lbf}
installée au plafond
/ 4 él.*
ou sur le mur.
* La longueur de la vis est un exemple lors de
l'installation de la caméra au plafond ou sur un mur
robuste d'une épaisseur de 20 mm {25/32 pouces}
ou plus.
Outdoor use
Authorised Representative in EU:
i-PRO EMEA B.V.
Laarderhoogtweg 25, 1101 EB
Amsterdam, Netherlands
i-PRO EMEA B.V. UK Branch
1010 Cambourne Business Park,
Cambridgeshire CB23 6DP
Ns0722-0
Printed in China
FCC CAUTION: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate
the equipment.
Supplier's Declaration of conformity
Trade name : i-PRO
Model No. : WV-S1536LNS
Responsible Party :
i-PRO Americas Inc.
8550 Fallbrook Drive, Suite 200 Houston,
Texas 77064
Support Contact : 1-800-513-5417
For U.S.A.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Caution:
• The DC power supply connected to the camera must
be in the same building.
• The network camera is only intended for a
connection to an ethernet or PoE network without
routing to the outside plant.
• This product has no power switch. Be sure to install
disconnect devices such as a circuit breaker to shut
down the main power of power supplying equipment
to this product.
• Only connect 12 V DC Class 2 power supply (UL
1310/CSA 223), limited power source (IEC/EN/UL/
CSA 60950-1, IEC/EN/UL/CSA 62368-1 Annex Q)
or IEC/EN/UL/CSA 62368-1 PS2.
• Before attempting to connect or operate this
product, please read these instructions carefully.
Precautions
„ Do not insert any foreign objects.
„
Fire or electrical shock may be caused if water or any foreign objects, such as metal objects, enter inside the
unit.
Turn the power off immediately and contact qualified service personnel for service.
„ Do not use this product in an inflammable atmosphere.
„
Failure to observe this may cause an explosion resulting in injury.
„ Avoid installing this product in the locations where corrosive gas is produced.
„
Otherwise, the mounting portions will deteriorate and injury or accidents due to a fall of the product may occur.
„ Do not strike or give a strong shock to this product.
„
Failure to observe this may cause injury or fire.
„ Keep microSD memory cards away from infants and children. „
Otherwise, they may swallow the cards by mistake.
In this case, consult a doctor immediately.
„ Do not hang down from this product or use this product as a pedestal.
„
Failure to observe this may cause injury or accidents.
„ Do not damage the power cable.
„
Do not damage, fabricate, twist, stretch, bundle, or forcibly bend the power cable. Do
not place heavy objects on it, and keep it away from heat sources.
Use of a damaged power cable may cause electric shock, short circuit, or fire.
Consult the dealer for repair.
„ Do not install this product on a place that is greatly influenced by wind.
„
Installation on a place where the wind speed is 60 m/s {approx. 134 mph} or more may cause a fall of the
product resulting in injury or accidents.
„ Do not sprinkle more water, exceeding the performance limit of waterproof with a high
„
pressure cleaning machine, etc.
Fire or electrical shock may be caused by immersion.
„ Do not attempt to disassemble or modify this product.
„
Failure to observe this may cause fire or electric shock. Consult the dealer for the repair or inspections.
„ Do not install or clean the camera, or touch this product, the power cable or the
„
connected cables during thunder storms.
Failure to observe this may cause electric shock.
„ Refer installation work to the dealer.
„
Installation work requires technique and experience. Failure to observe this may cause fire, electric shock, injury,
or damage to the product. Be sure to consult the dealer.
„ Stop the operation immediately when something is wrong with this product.
„
When smoke goes up from the product, the smell of smoke comes from the product, or the exterior of the
product has deteriorated, continued use will cause a fire or fall of the product resulting in injury, or damage to
the product.
In this case, turn the power off immediately and contact qualified service personnel for service.
„ Select an installation area that can support the total weight.
„
Selecting an inappropriate installation surface may cause this product to fall down or topple over, resulting in
injury or accidents. Installation work shall be started after sufficient reinforcement.
„ Periodic inspections shall be conducted. „
Rust on the metal parts or screws may cause a fall of the product resulting in injury or accidents.
Consult the dealer for the inspections.
„ The exclusively designed mount bracket shall be used.
„
Failure to observe this may cause a drop resulting in injury or accidents.
Use the exclusively designed mount bracket for installation.
„ The screws and bolts must be tightened to the specified torque.
„
Failure to observe this may cause a drop resulting in injury or accidents.
„ Turn the power off when do wiring of this product.
„
Failure to observe this may cause electric shock. In addition, short circuit or wrong wiring may cause fire.
„ Install this product in a location high enough to avoid people and objects from bumping
„
the product.
Failure to observe this may cause injury.
„ Do not install this product in locations subject to vibration.
„
Loosening of mounting screws or bolts may cause a fall of the product resulting in injury or accidents.
„ Correctly perform all wiring.
„
Short circuits in the wiring or incorrect wiring may cause fire or electrical shock.
„ The measures of protection against snowfall shall be taken.
„
Weight of snow may cause a fall of the product resulting in injury or accidents. Protect the product against
snowfall by installing it under eaves.
„ Install the product securely on an installation surface in accordance with the installation „
instructions.
Failure to observe this may cause injury or accidents.
„ Do not rub the edges of metal parts with your hand.
„
Failure to observe this may cause injury.
„ Turn the power off when cleaning this product.
„
Failure to observe this may cause injury.
Notice:
• This product is not suitable for use in locations
where children are likely to be present.
• Do not install this product in locations where
ordinary persons can easily reach.
• This product is a professional equipment.
• For information about screws and other
parts required for installation, refer to the
corresponding section of this document.
: Direct current symbol
