I65/I56I HARDWARE DESCRIPTION

10 Connector Supplier and Peripheral devices

10.1 50-pin connector

The 50-pin connector used in the integrated module is a Samtec SMT
connector.
Part number of 50-pin connector : FTS-125-01-F-DV-P-TR.
Counterpart number of connector : CLP-125-02-G-D-PA.
For more information about this connector :

10.2 GSM Antenna

The integrated modem antenna connector is a MMCX connector. The
MMCX connector incorporates a 'Snap On' latching action in order to make
the connection easier with an excellent RF performance. An additional
advantage is its small physical size which is 50% of the standard MCX
connector. This type of connector is suitable for the standard ranges of
flexible and semi-rigid cables. The characteristic impedance of the MMCX
coaxial connector is 50 ohm. The antenna manufacturer must guarantee that
the antenna will be working according to the following radio characteristics:
Frequency RX 869 to 894 MHz
Frequency TX
RF power stand
Impedance
VSWR
Typical radiated
gain
Table 21: radio characteristics
The I56/I56i requires a MMCX (Miniature Micro Connector) plug to
connect a GSM antenna. To connect a GSM antenna (e. g ANT010
850/1900 MHz) to the I56/I56i modem, the FALCOM offers a antenna
cable product called KA07 (MOQ-set of 10 pieces). Figure 25 shows the
KA07 antenna cable with MMCX and FME-female connectors.
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
EGSM 850
824 to 849 MHz
2 W at 12.5 %
duty cycle
http://www.samtec.com/
GSM 1800
1805 to 1880 MHz
1710 to 1785 MHZ
1 W at 12.5 % duty
cycle
50 Ω
< 2
0 dBi on azimuth plane
VERSION 1.00
GSM 1900
1850 to 1910 MHz
1930 – 1990 MHz
1 W at 12.5 % duty
cycle
