I65/I56I HARDWARE DESCRIPTION
The values stated below are measured directly at the reference points on the
I56/I56i board.
The POWER and (CRG option) pins serve as control signals for charging a
Li-Ion battery.
Signal name
VC5+
GND
POWER
Table 9: Pin description of 50-pin board-to-board connector

5.4.3 Power up/down scenarios

In general, be sure not to turn on GSM/GPRS part of the I56/I56i module while
it is out of the operating range of voltage and temperature stated in chapters
and 3.3. The GSM/GPRS part of the I56/I56i would immediately switch off
after having started and detected these inappropriate conditions.
5.4.3.1 Turn on the GSM/GPRS part of I56/I56i
The GSM/GPRS part of the I56/I56i can be activated in a variety of ways,
which are described in the following chapters:
via SOFT_ON line: starts normal operating state (see chapter 5.4.3.2)
via POWER line: starts charging algorithm (see chapter 5.4.3.3)
5.4.3.2 Turn on the I56/I56i module using the SOFT_ON line
To switch on the I56/I56i module the SOFT_ON signal needs to be set to
HIGH level for at least 100 ms. On open collector is also internally
integrated on this line, which manage the turn on procedure.
