Tower Air Fryer T17024 Manual: Instructions, Recipes etc.

Specifications

• Check that the voltage of the main circuit corresponds with the rating of the appliance before operating.
• If the supply cord or appliance is damaged, stop using the appliance immediately and seek advice from the manufacturer, its service agent or a similarly qualified person.
•
  DO NOT let the cord hang over the edge of a table or counter, serious burns may result from the air fryer being pulled off the counter where it may be grabbed by children or become entangled with the user.
• DO NOT carry the appliance by the power cord.
• DO NOT use any extension cord with this appliance.
• DO NOT pull the plug out by the cord as this may damage the plug and/or the cable.
• Switch off at the wall socket then remove the plug from the socket when not in use or before cleaning.
• Switch off and unplug before fitting or removing tools/attachments, after use and before cleaning.
• Close supervision is necessary when any appliance is used by or near children.
• Children should not play with the appliance.
• This appliance can be used by children aged from 16 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Cleaning and user maintenance should not be undertaken by children without supervision.
• Take care when any appliance is used near pets.
• DO NOT use this product for anything other than its intended use.
• This appliance is for household use only.
• This appliance includes a heating function. Please ensure that the appliance is used on a stable, level, and heat resistant surface.
• DO NOT immerse cords, plugs or any part of the appliance in water or any other liquid.
• DO NOT use the appliance outdoors.
• DO NOT place the air fryer on or near combustible materials such as a tablecloth or curtain.
• DO NOT place the air fryer against a wall or against other appliances. Leave at least 10cm free space on the back and sides and 10cm free space above the appliance.
• Allow the air fryer cool down for approx. 30 minutes before you handle or clean it.
• Make sure the food prepared in the air fryer comes out golden-yellow instead of dark brown. Remove burnt remnants.
• During hot air frying, hot steam is released through the air outlet openings. Keep your hands and face at a safe distance from the steam and from the air outlet openings.
• Hot steam and air may escape when you remove the pan from the air fryer.
• Any baking trays or oven dishes used in the air fryer will become hot. Always use oven gloves when handling or removing anything from the air fryer.
•
  DO NOT fill the air fryer pan with oil as this may cause a fire hazard.
• Always put ingredients to be fried in the basket. DO NOT press the basket release button during shaking.
• DO NOT place anything on top of the air fryer.
• In the unlikely event the appliance develops a fault, stop using it immediately and seek advice from the Customer Support Team: +44 (0) 333 220 6066

Before First Use

1. Remove your appliance from the packaging.
2. Check that there is no damage to the cord or any visible damage to the body.
3. Dispose of the packaging in a responsible manner.
4. Remove any stickers or labels from the appliance
5. Thoroughly clean the basket and pan with hot water, some washing-up liquid and a nonabrasive sponge. Note: You can also clean these parts in the dishwasher.
6. Wipe the inside and the outside of the appliance with a damp cloth.

Using Your Appliance

Automatic Switch Off - Air Fryer Drawer Safety Switch:

• When using the air fryer, please ensure that the basket is inside of the drawer, the drawer is fully closed and that the cooking timer has been set.

Removing The Frying Basket:

• The pan and frying basket can both be fully removed from the air fryer.
• Pull on the handle to slide the pan and frying basket out.
• Push the cover for the handle release button forward. There will be a small button on the top of the handle.
• Push it down and lift upwards to remove the frying basket from the pan.

Preparing For Use:

1. Place the appliance on a stable, horizontal and even surface. Do not place the appliance on a non-heat-resistant surface.
2. Place the basket in the pan.
3. Pull the cord from the storage compartment, which is located on the bottom of the appliance.
4. Do not fill the pan with oil or any other liquid.
5. Do not put anything on top of the appliance, as it will disrupt the airflow and affect your cooking results.

Using The Control Panel (see specification page):

1. Plug the power cord into a suitable power socket. Insert the basket into the pan. All of the indicators will display for 1 second (the food pre-set back-light will also illuminate) and will then turn off. The start key will remain visible.
2. Press the START button (key 3) for 2 seconds (a sound will indicate this has been pressed). The panel will then illuminate. When it is in default mode the Temp/Timer (key 7/8) displays will blink and "15:00" will display as the default time. The temperature indicator light will turn on.
3. Press Temperature/Timer (key 2) to toggle the display.
4. When the "MIN" light is illuminated the panel is in timer mode.
5. When the "°C" light is illuminated the panel is in Temperature mode.
6. When the Time indicator illuminates, the Menu indicator (key 1) will turn off.
7. Touch the Plus '+' (key 7) or Minus '-' (key 8) buttons until your desired cooking time is set. The display will increase or decrease by 1 minute with each press. If you press down and hold the Increase/Decrease indicators (key 7/8) you can quickly adjust the settings.
   Note: There will be no accompanying sound for this operation.
8. Set the range to between 00:00-60:00.The display will cease blinking after the timer is set.
9. Switch to the temperature setting by pressing the Toggle key (key 2).
10. The Timer 'MIN' light will now turn off and the temperature indicator light will turn on.
11. Touch the Plus '+' (key 7) or Minus '-' (key 8) buttons until your desired cooking temperature setting is reached. The display will increase or decrease by 10°C with each press. If you press down and hold the Increase/Decrease indicators (key 7/8) you can quickly adjust the settings.
    Note: There will be no accompanying sound for this operation.
    Note: You may set the range to between 80-200°C.
    Note: The display will stop blinking once the setting is complete.
12. Press the Menu Indicator (key 1) and the food pre-set back-light will turn on. Cycle through the food options from left to right and through the cooking time display accordingly. Press the Temp/Timer button (key 2) to toggle through your preference for each food setting.
13. Press the START/PAUSE indicator (key 3) once after you have finished with your settings. The unit will commence operation. The heating element and motor will start. The timer light will turn on, and the temp light will turn off. The display will begin counting down. Press START/PAUSE (key 3) again for a few seconds and the heating element and motor will stop working. Take out the basket. The display will no longer illuminate. You can now resume using the fryer.
14. During operation, press the Timer/Temp toggle (key 2) and then press the '+' or '-' buttons (key 7/8) to increase or decrease the temp or timer setting. The fryer will continue to operate and heat while the display is illuminated. It will blink for 5 seconds after your setting is complete, then continue to work as normal.
15. During cooking, press the START/PAUSE indicator (key 3) for 2 seconds. The fryer's heating element and motor will stop working and the display will switch off.
16. End of function/sequence: When the fryer has finished cooking, the display will show the numbers "00" and you will hear a sound. The motor will then stop working and the display will turn off.
17. Once a batch of ingredients is ready, the air fryer will immediately be ready for preparing another batch.

Air Frying:

1. Connect the mains plug into an earthed wall socket.
2. Carefully pull the pan out of the air fryer.
3. Put the ingredients in the basket.
   Tip: If you have a separator (NOT SUPPLIED) to separate items, you will be able to prepare different ingredients at the same time. Place the separator in the basket and fill up each side of the basket with the ingredients. Make sure you check the preparation time and the temperature required for the different ingredients before you start to prepare them. Potato cubes and schnitzel, for example, can be prepared simultaneously because they require the same settings. Please note that the maximum amount for each of the ingredients is half the normal amount.
4. Slide the pan back into the air fryer, making sure to carefully align with the guides in the body of the fryer.
5. Never use the pan without the basket in it.

   Do not touch the pan immediately after use, as it gets very hot. Allow plenty of time to for it too cool. Only hold the pan by the handle.
6. Determine the required preparation time for each ingredient (refer to the 'Settings' section below for instructions on how to do this.)
7. Adjust the temperature control dial to the required setting. Refer to the 'Settings' and 'Control Panel' sections in this manual for instructions on how to determine the right temperature. Add 3 minutes to the preparation time when the appliance is cold.
8. Excess oil from the ingredients is collected on the bottom of the pan.

Settings:
The table on the next page will help you select the basic settings for each ingredient.

Note: Keep in mind that these settings are indications, as ingredients differ in origin, size, shape and brand, we cannot guarantee the best settings for your ingredients. Because the rapid air technology instantly reheats the air inside the appliance, pulling the pan briefly out of the appliance during hot air frying barely disturbs the process.

Tips:

• The preparation time will depend on the size of your ingredients. Smaller sizes may require a shorter cooking time.
• Shaking ingredients halfway during the cooking time will improve the end result and can help prevent unevenly fried ingredients.
• Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the air fryer within a few minutes after you added the oil.
• Be cautious of using extremely greasy ingredients such as sausages in the air fryer.
• Snacks that can be prepared in an oven can also be prepared in the hot-air fryer
• The recommended amount for preparing crispy fries is 500g

Note: This air fryer uses hot air heating technology. Never pour oil or fat into the fryer.

Tips:

• Try soaking your raw cut fries in cold water for 30 minutes and then dry well before putting in the air fryer.
• Be careful not to overfill the basket with food.
• For a great, even brown crisp, toss your fries multiple times during cooking.
• Remove your fries quickly once the cooking process is complete to ensure they stay crispy.
• Thinly slice and separate onions.
• Cut all vegetables into small pieces to make sure they cook properly.
• The air fryer can also be used to reheat ingredients. To reheat, set the temperature to 150°C for up to 10 minutes.

Troubleshooting

Recycling

DISPOSAL OF THE UNIT

Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are required to dispose of old electrical and electronic appliances like this separately. Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.

Cleaning & Care

DO NOT IMMERSE THE APPLIANCE IN WATER OR ANY OTHER LIQUID.

Allow the appliance to fully cool down before cleaning and storing.

1. Clean the appliance after every use.
2. Clean the pan and the non-stick coating basket:
3. Do not use metal kitchen utensils or abrasive cleaning materials to clean them, as this may damage the non-stick coating.
4. Remove the mains plug from the wall socket and let the appliance cool down.
   Note: Removing the pan will help the air fryer cool down quicker.
5. Wipe the outside of the appliance with a damp cloth.
6. Clean the pan, separator and basket with hot water, some washing-up liquid and a nonabrasive sponge.
7. You can use degreasing liquid to remove any remaining dirt.
   Note: The pan and basket are dishwasher-proof.
   Tip: If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot water with some washing-up liquid. Put the basket in the pan and let the pan and the basket soak for approximately 10 minutes.
8. Clean the heating element with a cleaning brush to remove any food residues.

Do not use the appliance if it is damp. Ensure the air fryer is completely clean and dry before storing

To store your appliance:

• Unplug the power cord from the power outlet as instructed.
• Allow the appliance to dry fully.
• Store on a flat, dry, level surface, out of the reach of children.

Wiring Safety for UK Use Only

This Appliance MUST be Earthed

Warranty

3-Year Guarantee

As a thank you for purchasing one of our fantastic products, we are offering you an extra 2 years peace of mind in addition to your 1 year guarantee.

To receive your extra 2 year guarantee, register your appliance online within 28 days of purchase by visiting www.towerhousewares.co.uk

This product is guaranteed for 12 months from the date of original purchase. If any defect arises due to faulty materials of workmanship, the faulty products must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer.

The Following Conditions Apply:

• The product must be returned to the retailer with proof of purchase or a receipt.
• The product must be installed and used in accordance with the instructions contained in this instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• Tower has limited liability for incidental or consequential loss or damage.

This guarantee is valid in the UK and Eire only.

The standard one year guarantee is only extended to the maximum available for each particular product upon registration of the product within 28 days of purchase. If you do not register the product with us within the 28 day period, your product is guaranteed for 1 year only.

To validate your extended warranty, please visit www.towerhousewares.co.uk and register with us online. Alternatively, call our customer registration line on +44 (0) 333 220 6066.

Please note that length of extended warranty offered is dependent on product type and that each qualifying product needs to be registered individually in order to extend its warranty past the standard 1 year. Extended warranty is only valid with proof of purchase or receipt.

Weights & Measures

Refer to the charts below for basic imperial to metric weight conversions.

Food Allergies

Some of the recipes contained in this document may contain nuts and/ or other allergens. Please be careful when making any of our sample recipes that you ARE NOT allergic to any of the ingredients. For more information on allergies, please visit the Food Standards Agency's website at: www.food.gov.uk
