Summary of Contents for Zebronics BT6593RUCF
- Page 1 5 . 1 S p e a k e r BT6593RUCF BT6593RUCF User Manual www.zebronics.com...
- Page 2 Thank you for purchasing the ZEB- BT6593RUCF 5.1 Speaker. Please read this user manual carefully and keep for future reference. Warning TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
-
Page 3: Important Safety Instructions
The exclamation point within an equilateral triangle is intended to alert the user of the presence of important operating and maintenance (servicing) instructions in the manual accompanying the product. IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions before using the product. 2) Read all the warnings carefully. - Page 4 1.select the audio input to BT mode 2 . s e a r c h BT d e v i c e w i t h n a m e “ Z E B - BT6593RUCF” 3.connect the BT 4.if your BT device below 5.0 version, input...
-
Page 5: Product Representation
Product Representation Front Panel AUTO/ INPUT : Input Mode BT v5.0/USB/FM/AUX/AC-3 5.1/2.1 : 5.1/2.1 function key. STANDBY / / AUTO : Stand by function by pressing it 3 secs in BTv5.0/USB/FM/AUX/AC-3 Mode; Play/Pause in BT/USB mode; Automatic FM radio search by pressing 3 secs. VOL- / / CH- : Turn down the volume;... - Page 6 Important Notes • Make sure that the power supply is proper and never handle the power cord or its plug with wet hands when plugging into, or unplugging from an plug-point. • Ensure that the main power switch is in the "OFF"...
-
Page 7: Remote Control
Remote Control Power switch button (Standby) switch On or off USB input MUTE 5.1/2.1 FM Radio AUX Input BT Input AC-3 input for 5.1 mode audio source. Equalizer preset Play & pause Previous track when USB/BT Input Previous Channel When FM Input Next track when USB/BT Input Next Channel... - Page 8 5.1/2.1 5.1/2.1 mode. SW -/+ To calibrate the woofer sound level. FL -/+ To calibrate the front left speaker level. FR -/+ To calibrate the front right speaker level. CEN -/+ To calibrate the center level. SL -/+ To calibrate the surround left levels. SR -/+ To calibrate the surround right sound levels.
-
Page 9: Speaker Terminals
Output connectivity CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN SPEAKER TERMINALS Connect front speakers, center speaker, surround speakers to 5.1 speaker output terminals. Ÿ The front speaker's cords to the FRONT SPEAKERS terminals Ÿ The center speaker's cords to the CENTER SPEAKERS terminals Ÿ... - Page 10 Unit Operation Ÿ First plug the cable of all the satellite into the output jack on the rear panel of the woofer, one end of the audio cord into the input jack on the rear panel, the other end into the output jack of the computer or any external audio source, the power cord into the power plug socket.
- Page 11 Ÿ When USB drive is working, press the PLAY/PAUSE button to pause the music, press the PLAY/PAUSE button again to resume music. Ÿ When USB drive is playing, press the MODE button to cycle through the LINE IN, USB, FM, BT mode. Ÿ...
- Page 12 Max. supported USB memory size : 128GB FM frequency scan range : 87.5MHz-108MHz BT name : ZEB-BT6593RUCF BT version : 5.0 + EDR Product dimension (W x D x H) Subwoofer : 165 X 295 X 310 mm Satellite : 95 x 98 x 150 mm Net.
