jWIN JT-P850 Features And Specifications

JT-P850
1. Features and Specifications
a). 14 minutes of voice storage time (1M*4 DRAM)
b). Voice date -time stamp (DTS) and user prompts.
c). Record messages up to 59.
d). OGM (up to 50seconds), Memo, ICM recording up to 1 minute.
e). Two default outgoing message (OGM).
f). Erase each message/all messages, save all erased messages function.
g). Busy tone/Ring/continuous tone detection.
h). 3-digit user selectable remote codes, default "000".
I). 2-digit LED display
j). DTMF detectio n for remote control.
k). Answer on/off selection, indicator and announcement.
l). Call screening.
m). Intercept function by stop key or seizing line action.
n). VOX function.
o). New Message LED& LCD icon indication
p). (2way+Room monitor) optional

2. DAM Description and Operation

2.1 Key Operation

2.1.1 ANSWER ON /OFF
- Press to toggle between answer on/off. (It will announce "ANSWER ON"/ ANSWER
OFF")
- Press and hold for 2 seconds, it will announce "Security Code" and the LED show "Sc",
and then the security code.
- Press to advance to next digit during security code.
2.1. 2 TIME
- Press and hold to start the setup of day-time
- Press to play the current day and time.
2.1.3 OGM/FORWARD
- Press and hold to start recording the answer-record OGM (OGM1)
- Press once to play OGM1
- Press to skip message during message playback.
- Press to increment the digit during DTS or security code setup.
2.1. 4 MEMO/REPEAT
- Press and hold for two seconds. The display shows "oo". Release key after one short
beep to start memo recording.
PAGE 1
