Identify all parts packed in the carton against the parts list. Remove all protective
materials. Place parts on a non-abrasive surface to avoid scratching.
Do Not Attempt Assembly If Any Parts Are Missing Or Damaged.
Warning: Please do not use acid or alkaline washing liquid to clean the product.
Assemble the product as shown below, step-by-step.
Part List
NO.
SKETCH
DESCRIPTION
A
Back Frame
B
Seat Frame
C
Seat Cushion
D
Back Cushion
E
Foot Glider
Assembly Instructions
QTY
NO.
1
AA
1
BB
1
CC
1
DD
4
EE
SKETCH
DESCRIPTION
Bolt
(M6*60)
Steel Washer
(Φ14*Φ6.5*1.5)
Steel Washer
(Φ16*Φ7*1.5)
Bolt cap
Wrench
GLA-5106-14
JWUA
JWUA
Made in China
SKU#70551063
QTY
2
2
2
2
1
1
Advertisement
Related Manuals for ROOMS TO GO 70551063
Summary of Contents for ROOMS TO GO 70551063
- Page 1 SKU#70551063 Assembly Instructions Identify all parts packed in the carton against the parts list. Remove all protective materials. Place parts on a non-abrasive surface to avoid scratching. Do Not Attempt Assembly If Any Parts Are Missing Or Damaged. Warning: Please do not use acid or alkaline washing liquid to clean the product.
- Page 2 STEP 1 Hand tighten nut 3-4 revolutions only,after attached all the bolts,adjust all the part at correct position,then tighten all the bolts and nuts.Do not over tighten. STEP 2 Adjust the pre-installed foot glider(E) at the end of each Chaise Lounge leg until the Chaise Lounge is level with the ground Securely, Your Chaise Lounge is ready for use.
