To prevent fire or shock hazard, do not use this plug with an extension cord, receptacle or other
outlet unless the blades can be fully inserted to present blade exposure. To prevent fire or shock
hazard, do not expose this appliance to rain or moisture.
IMPORTANT SAFETY INSTRUCTIONS
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water (swimming pool, beach, lake etc.).
6.
Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in accordance with the manufacturer\s instructions.
8.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.
Protect the power cord from being walked on or pinch particularly receptacles, and the point
where they exit from the stereo.
11.
Only use attachments / accessories specified by the manufacturer.
12.
Unplug this apparatus during lightning storms or when unused for long periods of time.
13.
Refer all servicing to qualified service personnel. Servicing is required when the system has
been damaged in any way, such as power-supply cord or plug, has been exposed to rain or
moisture, does not operate normally, or has been dropped.
14.
This appliance shall not be exposed to dripping or splashing water and objects filled with water,
such as vases, should NOT be placed on his unit.
WARNING
WARNING
W AR N IN G : TO R E D U C E TH E
R IS K O F E L EC T R IC SH O C K,
D O N O T R E M O V E C O V ER (O R
B AC K ) N O U S ER - SE R VIC E A BL E
PAR TS IN S ID E R E FE R
S ER V IC IN G TO Q U AL IF IE D
S ER V IC E P E R SO N N E L.
1
!

Advertisement

loading
Need help?

Need help?

Do you have a question about the JX-CD7100 and is the answer not in the manual?

Questions and answers

Summary of Contents for jWIN JX-CD7100

  • Page 1 To prevent fire or shock hazard, do not use this plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to present blade exposure. To prevent fire or shock hazard, do not expose this appliance to rain or moisture. W AR N IN G : TO R E D U C E TH E R IS K O F E L EC T R IC SH O C K, D O N O T R E M O V E C O V ER (O R...
  • Page 2 T A B L E O F C O N T E N T S This instruction manual is important to you. Please read it. This manual tells excatly how to connect, operate and adjust this unit for best performance. It shows simple things to do and check before you call for help and saves the cost of unnecessary service and call out charges.
  • Page 3 C O N N E C T I N G T O M A I N S S U P P L Y MAINS (AC) OPERATION This unit is designed to operate on 120V, 60Hz current only. Connecting it to other power sources may damage the unit.
  • Page 4 L O C A T I O N O F C O N T R O L S 1. Memory / Program 2. Memory Up/Program 3. Tuning / Search REW 4. Tuning / Search Forward 5. Band / Stop 6. Play / Pause 7.
  • Page 5 R E M O T E C O N T R O L A N D B A T T E R Y INSTALLATION BATTERY Insert 2pcs [AAA[ size (Alkaline) batteries (not included) into the battery compartment of the remote control. Be sure to observe the polarity markings which are engraved inside the battery compartment, then close the cover.
  • Page 6 TUNING TO A PRESET STATION Select the desired program number by pressing the Memory Up/Repeat button. Storing Stations Tune either automatically or manually (as described in precious sections) to the station to be stored. Press the Memory/Program button once; ]Memory^ will flash on the display. The display will change for 10 seconds;...
  • Page 7 LOADING AND UNLOADING COMPACT DISCS Press the Power button to turn the unit on. Select the CD function by pressing the CD button. Press PUSH/OPEN to open the CD compartment. When the disc compartment has opened, remove a disc from its case and place it carefully in the disc compartment with the label side facing up.
  • Page 8 Play a new disc. If the CD player operates normally, the skipping problem is probably due to a defective disc. TO STOP A CD PART WAY THROUGH Press the Stop/Band button. Disc play will show the total number of tracks. To temporarily stop disc play(pause mode),press the PLAY/PAUSE button.
  • Page 9 FOR REPEAT PLAY OF ALL THE TRACKS Press the Memory Up/Repeat button twice. The REPEAT will be displayed. Select the desired track by pressing the Tuning/Search Forward or REW buttons. The selected track will be shown on the CD display. Press the PLAY/PAUSE button.
  • Page 10 NOTES: If the PLAY/PAUSE Button is pressed before the Memory/Program Button is pressed to store a track, the track will not be programmed, and the disc will start playing from the first selected track. Any track can be programmed to play more than one. Repeatedly pressing the Memory/Program button will enable you to check the Program if required.
  • Page 11 After hour is set, press the MEMORY/CLOCK button again, the minute start to flash in the display, use the SKIP Up/Down buttons to set the required minute. Press the MEMORY/CLOCK button on the remote control again to complete the required time. TIMER will flash and your setting time will be shown for 5 sec.
  • Page 12 T E C H N I C A L S P E C I F I C A T I O N S Power supply AC ... 120V 60Hz Radio frequency coverage FM ... 87.5 - 108 MHz AM ... 520 - 1710 KHz CD player Pick up ...
