HATHASPACE HARMONY 1500 Product Manual

1 hepa air purifier
Hide thumbs Also See for HARMONY 1500:
Table of Contents

Advertisement

Quick Links

PURE AIR,
ALWAYS.
1 HEPA Air Purifier
HSE1500
PRODUCT MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HARMONY 1500 and is the answer not in the manual?

Questions and answers

Related Manuals for HATHASPACE HARMONY 1500

Summary of Contents for HATHASPACE HARMONY 1500

  • Page 1 PURE AIR, ALWAYS. 1 HEPA Air Purifier HSE1500 PRODUCT MANUAL...
  • Page 2 NOTE: Remove plastic bag from filter before first use...

  • Page 3: Table Of Contents

    Contents 1. Basic Information 2. Safety Instructions 3. Product Diagram 4. 4-in-1 Purification System 5. Buttons and Indicators 9-12 5.1. Control panel 5.2. LED display 5.3. Air quality indicator 5.4. Particle sensor 5.5. Brightness adjustment 6. Air Purifier Maintenance 13-14 6.1.

  • Page 4: Basic Information

    READ AND SAVE THESE INSTRUCTIONS Use unit according to instructions provided in the manual. Keep manual for future reference. This appliance can be used by children aged 8 years and above and individuals with reduced physical, sensory, mental capabilities or lack of experience if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

  • Page 5: Safety Instructions

    Do not use without removing the plastic wrap from the air purifier and filters. Do not attempt to use other filters with this appliance. Only use Hathaspace air replacement filters for this unit.
  • Page 6 2. Safety Instructions Do not operate the unit if the power cord or plug is damaged. Doing so may result in injury or damage to the unit. Do unplug the appliance from the power supply before servicing. Do inspect the unit frequently. Dirt that has collected should be removed regularly to prevent excessive accumulation that may result in flashover or fire.

  • Page 7: Product Diagram

    3. Product Diagram Control Panel Air Outlet Air Inlet Particle Sensor Removable Base Power Cord to replace the filter HSE1500 Air Purifier...

  • Page 8: In-1 Purification System

    4. 4-in-1 Purification System 4-in-1 Air Filtration System Your Hathaspace filter uses 4 advanced technologies to keep your air clean, capturing airborne particles: 1. Polypropylene Pre-filter A preliminary Polypropylene Pre-filter removes large particles like pet hair, dust, and floating debris. This helps extend the life of the composite filter.

  • Page 9: Buttons And Indicators

    5. Buttons and Indicators 5.1. Control Panel Icon Function Power button: Press to power on/off function. Four Speed button: Adjust fan speed to 1- 2- 3- 4- SLP levels. Sleep mode: Press speed button to choose sleep mode. In sleep mode, the screen will show “SLP”, all the other indicator lights are turned off.

  • Page 10: Led Display

    5. Buttons and Indicators 5.2. LED Display Icon Definition Fan Speed Indicator, 1-2-3-4-SLP levels. Time Indicator Eco mode: When lit, the unit automatically enters energy saving Eco mode when the PM2.5 count is lower than 35 for 30 mins or AQI>80%. The motor stops for 10 minutes, then runs for 10 minutes in speed 1.

  • Page 11: Air Quality Indicator

    5. Buttons and Indicators 5.3. Air Quality Indicator Index (ug/ m³) AQI (%) Air Quality Speed Color ≤50 72.5%-100% Excellent Green PM2.5 51-100 62.9%-72% Good Blue & 101-150 55.1%-62.8% Fair Yellow >150 0.0%-54.9% Poor 5.4. Particle Sensor The sensor is placed inside the air purifier and can detect the air quality intelligently. Mode Operation Adjust fan speed based on your needs.

  • Page 12: Brightness Adjustment

    5. Buttons and Indicators 5.5. Brightness Adjustment There are six levels of light brightness. The light levels are pre-set at these levels: • The default brightness of lights is 100% (including all indicators and air quality lights). • Press the brightness adjustment button to manually adjust the air quality indicator light levels as follows: 0%>20%>40%>60%>80%>100% •...

  • Page 13: Air Purifier Maintenance

    To maintain the performance of the air purifier and purification effect, we advise to replace the filters every 4 months or 3000 hours. For the best performance and longest lifespan, use certified HARMONY 1500 replacement filters for HSE1500. 1) Unplug the air purifier from the electrical outlet.
  • Page 14 6. Air Purifier Maintenance 3) Remove the old filter and dispose of it properly. The filter is not recyclable. 4) Remove the new filter packaging and insert it into the air purifier. 5) Turn it clockwise to tighten the bottom panel. 6) Place the air purifier on the floor again and plug it back into the electrical outlet.
  • Page 15 7. Troubleshooting Problem Reasons Possible Solution A. Check that the unit is properly A. No electricity. plugged into an electrical Air purifier cannot be turned on B. Power cord is damaged. outlet. or respond to button controls. C. The outlet is damaged. B.

  • Page 16: Replacing The Filter

    7. Troubleshooting Problem Reasons Possible Solution A. Reset the air purifier by The filter light is still on after A. Forgot to reset the air purifier. pressing the “filter light” replacing the filter. button for 5 seconds. A. The appliance has been running The filter light isn’t on within infrequently.

  • Page 17: Limited Warranty

    Damage in return transit. Please see warranty details at https://www.hathaspace.com 9. Customer Support Hathaspace strives to make every part of your experience exceptional. If you have any questions or concerns about your air purifier, please feel free to contact our Customer Support.
  • Page 18 HEPA AIR PURIFIER HSE1500 www.hathaspace.com team@hathaspace.com 1-800-446-0535 Hathaspace Manufactured for Hathaspace EPA Est. No. 87627-CHN-1 © Hathaspace. All rights reserved.
