RF Demo Kit
RF Demo Kit 是由 BH5HNU 自主设计的 NanoVNA 射频测试板，尺寸 10*10CM，用于学习矢量网络分析仪使用。
背面印刷了史密斯圆图，可以用于学习识读史密斯圆图，学习阻抗匹配基本原理。
测试板有 18 种电路。了解更多：deepelec.com/rf-demo-kit
The RF Demo Kit is a NanoVNA RF test board independently designed by BH5HNU, with a size of 10 * 10CM. It is used to learn the use of
a vector network analyzer.
The Smith chart is printed on the back, which can be used to learn to read the Smith chart and learn the basic principles of impedance matching.
The test board has 18 kinds of circuit. More visit : deepelec.com/rf-demo-kit
