- Page 1 Hybrid Inverter Installation and Operation Manual +86-21-54326236 +86-21-54326136 info@aforenergy.com Building 7, No.333 Wanfang Rd, Minhang District, Shanghai, China. 201112...
-
Page 2: Table Of Contents
Contents Contents 1. About This Manual ..... . 1.1 Scope of Validity ......1.2 Target Group . - Page 3 Contents 5. Operation ......5.1 Control Panel ....... 5.2 Menu Overview .
-
Page 4: About This Manual
5. Please ensure that the used device and any relevant accessories are disposed of in accordance with applicable regulations. 6. Afore inverter should be placed upwards and handled with care in delivery. Pay attention to waterproof. Do not expose the inverter directly to water, rain, snow or spray. -
Page 5: Explanations Of Symbols
Safety & Symbols 2.2 Explanations of Symbols Afore inverter strictly comply with relevant safety standards. Please read and follow all the instructions and cautions during installation, operation and maintenance. Danger of electric shock The inverter contains fatal DC and AC power. All work on the inverter must be carried out by qualified personnel only. -
Page 6: Introduction
Introduction 3. Introduction 3.1 Basic Instruction The Afore AF-DH series hybrid inverters are designed to increase energy independence for homeowners. Energy management is based on time-of-use and demand charge rate structures, significantly reduce the amount of energy purchased from the public grid and optimize self-consumption. -
Page 7: Time Of Use
Introduction Note: Advance Setting When select 0 W under P_Feed menu, the inverter will export zero energy to the grid. When select xx W under P_Feed menu, the inverter will export customized energy to the grid. 3.2.2 Time of Use The Time of Use mode is designed to reward customers who do their part to reduce demand on the electric grid, particularly during peak usage periods. - Page 8 Introduction Note: After select AC charge, the AC will also charge the battery when the PV is low or no PV. B. Forced discharge 4 periods of time discharge setting Energy flow: Battery and PV → Load → Grid C. Forbidden Discharge 4 periods of time discharge setting, the battery will be charged firstly.
-
Page 9: Selling First
Introduction 3.2.3 Selling First The Selling First mode is suitable for the regions with high feed-in tariff. Energy flow: PV → Load → Grid → Battery 3.2.4 Back-Up When the grid fails, the system will automatically switch to Back-Up mode. The back-up loads can be supplied by both PV and battery energy. -
Page 10: Installation
Installation 4. Installation 4.1 Pre-installation 4.1.1 Unpacking & Package List Unpacking On receiving the inverter, please check to make sure the packing and all components are not missing or damaged. Please contact your dealer directly for supports if there is any damage or missing components. Package List Open the package, please check the packing list shown as below. -
Page 11: Product Overview
Introduction No. Qty Items No. Qty Items Security Screw Hybrid Inverter Wall Mounting Bracket Expansion Tube Quick Installation Instructions Backet Screw Inspection Certificate Battery Terminals Warranty Card Earth Terminals Monitor Quick Installtion Monitor Module Smart Meter (Opitional) Power Connectors Communication Connectors 4.1.2 Product Overview 228.6mm 400.0mm... -
Page 12: Mounting Location
Installation Inverter Terminals Items Items Emergency Stop Grid Port DC Switch BACK UP Battery Port Communication Port Wifi Port Waterproof Ventilating Valve PV Port Grounding Screw 4.1.3 Mounting Location The inverters are designed for indoor and outdoor installation (IP65), to increase the safety, performance and lifespan of the inverter, please select the mounting location carefully based on the following rules: •... - Page 13 Installation The inverter should be installed vertically on the wall, or lean back on plane with a limited tilted angle. Please refer to below picture. <15° >0° Leave the enough space around inverter, easy for accessing to the inverter, connection points and maintenance. 300mm 500mm 500mm...
-
Page 14: Mounting
Installation 4.2 Mounting Step 1 373.5mm 18mm 260mm Step 2 Step 3... -
Page 15: Electrical Connection
Installation 4.3 Electrical Connection GRID BAT- BAT+ L1 N L2 L1 N L2 L1 N L2 Generator Critical Load Wind Turbines PV Array Smart meter Wind Turbines PV Array Grid Wind Turbines PV Array Load... -
Page 16: Communication
Installation 4.3.1 Communica�on Communication terminals and configured switches on the bottom of the inverter: Item Switch Communication terminal Adaptation switch Communication terminal BAT485 and Meter Communication terminal NTC and BAT CAN Communication terminal RS485 CT1 and CT2 Communication terminal Communication terminal Dry Connector Communication terminal 4.3.1.1 Adapta�on Switch... -
Page 17: Bat/Meter/Ct
Set Make sure AC cable is totally isolated from AC power before connecting Smart Meter & CT. One meter and 2pcs CT used for one hybrid inverter. Meter Install the Meter Step 1 Inverter GRID L1 N L2 Afore Meter Main Breaker Grid Grid Load... - Page 18 Installation Step 2 Connect the Meter to the inverter 485-1 -2 The Meter Communication port Meter 485B Lithioum Smart Meter Meter 485A BAT & Meter 485 BAT 485A BAT 485B Meter 485A PIN 1 2 3 4 Meter 485B...
- Page 19 Installation Connect the meter with the inverter With negative value, the hybrid inverters is feeding power to the grid. With positive value, the load is consuming the power from grid. With below figures and “Imp.”, the system is importing active energy. With below figures and “Exp.”, the system is exporting active energy.
- Page 20 Installation Install the CT Step 1 GRID L1 N L2 CT_W CT_U Grid Load Connect the CT to the inverter Step 2 CTU CTW The CT communication port CT_W CT_U...
-
Page 21: Adaptation Switch
Installation Step 3 CT-AC/Meter CT_U CT_N CT_W PIN 1 2 3 4 CT_N 4.3.1.3 Adaptation Switch RS485-3 connector is for Multi inverter parallel communication connection. Please check with local distributor or Afore for more information. 485-3 1B 2B... -
Page 22: Wifi/Gprs/Lan
Installation 4.3.1.4 WIFI/GPRS/LAN The WiFi/GPRS/LAN module could transmit data to cloud server, and display data on PC(personal computer), tablet and smart-phone. Install the WIFI / Ethernet / GPRS / RS485 Communication Turn on the AC power supply and the AC breaker, until the LED indicator on theWiFi/GPRS/LAN module flashing. - Page 23 Installation Step 1 Step 2 TEP CAN Lithium Lead Acid BAT NTC & CAN TEP T TEP G CAN H PIN 1 2 3 4 CAN L...
-
Page 24: Drm (Demand Response Mode)
Installation Note: NTC（temperature sensor）：Lead Acid CAN：Lithium 4.3.1.6 DRM (Demand Response Mode) 1 2 3 4 5 6 7 8 DRM1/5 REF/GEN/0 DRM2/6 3.3V DRM3/7 DRM4/8 4.3.2 PV Connection The AF-DH series hybrid inverters up to three MPPT channels, can be connected with threestrings of PV panels. -
Page 25: Battery Connection
4.3.3 Battery Connection AF-DH series hybrid inverters are compatible with lithium battery. For lead acid battery or batteries with other brands, please confirm with local distributor or Afore for technical support. Note: Set battery type and manufacturer, please refer to Chapter 5.3. -
Page 26: Ac Connection
Installation Step 1 11±0.5mm AC cable Note: Cable suggestion: Cross-section 8-10AWG Note: Please make sure the battery polarities are correct. Step 2 GRID 4.3.4 AC Connection There are three AC terminals marking with "GRID", "EPS" and "GEN". Before connecting, a separate AC breaker between individual inverter and AC input power is necessary. - Page 27 Installation Please follow steps for AC connection · Connect DC protector or breaker first before connecting. · Remove insulation sleeve 11mm (0.5 inch) length, unscrew the bolts, insert the AC input wires according to polarities indicated on the terminal block and tighten the terminal screws.
- Page 28 Installation EPS Connection Step 1 11±0.5mm AC cable Note: Cable suggestion: Cross-section 8-10AWG Step 2 Critical Load EPS Connection Step 1 11±0.5mm AC cable Note: Cable suggestion: Cross-section 8-10AWG...
-
Page 29: Earth Connection
Installation Step 2 Generator ・ Then, insert stripped AC output wires into the terminal block according to polarities indicated and tighten the terminal. Corresponding N wires and PE wires to the AC terminal should be inserted as well. Note: Make sure the wires are securely connected. 4.3.5 Earth Connection A second protective earth (PE) terminal should be connected to the inverter. -
Page 30: Operation
Operation 5. Operation 5.1 Control Panel ○ ○ ○ ○ ○ ○ ○ ○ Items Items LCD Display UP Touch Button POWER LED Indicator DOWN Touch Button BACK Touch Button GRID LED Indicator ENTER Touch Button FAULT LED Indicator Note: Hold UP/DOWN button can be rolling quickly. -
Page 31: Menu Overview
Operation 5.2 Menu Overview AF-DH hybrid inverter has a LCD for clearly operating, and menu of the LCD can be presented as following： PV Info Bat Info Inv Info Run Info Grid Info Safty Load Info Model EPS Info Prated Err Record Tem Info Vrated... -
Page 32: Time & Date
Operation 5.3.1 Time & Date Quick Set Date time XXXX Month 5.3.2 Safety Quick Set Safty Safety Specifications Com-50Hz Com-60Hz China Japan-50 Japan-60 Note: US_240S Select the safty according to the US_240D requirements of the installation site. US_208S US_208D Australia UK-G99 UK-G98 .. -
Page 33: Lithium Battery
Operation 5.3.3 Lithium Battery Quick Set Bat Type Lithium 5.3.4 PV Mode Quick Set PV Mode Independent 1. No PV connection Parallel 2. “Independent” and “Parallel” setting NoPV for professional installers. 5.3.5 Lead Acid Quick Set Bat Type Lead-Acid... -
Page 34: Energy Management System (Ems Param)
Operation 1. Lead-acid battery manufacturer. 2. Capacity range. Brand COMMOM/SACRED 3. Resistance compensation. Capacity 0-1000Ah 4. Temperature compensation. BatResComp 0-1000mΩ 5. Constant voltage charging voltage. 6. Discharge termination voltage. BatTemcomp 0-500mV/℃ 7. Number of batteries in series. VConstvolt 0-850V 8. One lead-acid battery voltage rating. VDiSchgEnd 0-850V 9. -
Page 35: Timing Of Use
Operation 5.3.7 Time of Use Mode Set Chg&Dischg Range Battery charge / discharge setting. 1. Upper state of charge. SocMax 0.0% 2. Lower state of charge. SocMin 0.0% 3. Battery Overvoltage Threshold. VBatMax 0.0V 4. Battery undervoltage threshold. VBatMin 0.0V 5. -
Page 36: Forced Charging
Operation 5.3.9 Forced Charging Mode Set Timing Control Force Charge Force Charge Green 1. Force Charge — Force charging enable. SOC Max 0.0% 2. SOC Max — Forced charging power percentage. Chg Pwr% 0.0% 3. Chg Pwr% — Forced charging Max Soc. Tim1 Start 00:00 4. -
Page 37: Protection Parameters
Operation 5.3.11 Protection Parameters Advanced Set Protection Parameter 1. Insulation resistance detection. IsoChk Green 2. Leakage current detection. GfciChk Green 3. Ground detection. EarthChk Green 4. Restart enable. RSSEn Green 5. Impedance lower limit. ISOmin 0KΩ 6. Grid level one overvoltage protection value. 7. -
Page 38: Diesel Generator Setting
AC side(Such as the grid side, EPS side, Gen side). • Earth line and Smart meter/CT line are connected. • AF-DH hybrid inverters should be set according to the required local grid standard. • More information please contact with Afore or distributors. -
Page 39: Power On
Maintenance&Trouble Shooting 6.1 Power ON • Turn on DC switch. • After LCD lighting, hybrid inverter should be set following Chapter 5.3 at the first time. • When inverter running under normal mode, Running indicator will light up(Ref. to Chapter 5.1). 6.2 Power OFF •... - Page 40 Maintenance&Trouble Shooting Fault Code and Trouble Shooting Type of Fault Code Name Description Recommend Solution • Check PV modules connection PV connection type • Check PV Mode setup Ref. PvConnectFault different from setup Chapter 5.3. • Check PV modules wires, those wires are soaked or damaged, and then carry ISO check among PV out rectification.
- Page 41 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution PV7ReverseFault PV8ReverseFault PV9ReverseFault PV10ReverseFault PV11ReverseFault PV12ReverseFault Pv1AbnormalFault Pv2AbnormalFault Pv3AbnormalFault Pv4AbnormalFault Pv5AbnormalFault Pv6AbnormalFault Pv7AbnormalFault Pv8AbnormalFault PV Fault Pv9AbnormalFault Pv10AbnormalFault • Check PV modules partial occlusion or Pv11AbnormalFault cells damaged. PV(+) and PV(-) reversed •...
- Page 42 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution • Check inverters connected battery lines PcsBatOverVoltFault and connectors broken or loose connect. • Carry out rectification if broken or Battery voltage over or PcsBatUnderVoltFault loose. under • Checking battery voltage is abnormal or not, then maintenance or change new PcsBatInsOverVoltFaul battery.
- Page 43 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution BatPreChaFault BmsBatChgMosFault BmsBatDChgMosFault BMSVolOVFault BMSVolLFault VolLockOpenFault VolLockShortFault ChgRefOVFault • Inverter will restart automatically when the grid return to normal. GridLossFault Grid lost (islanding) • Check inverter connected with grid connectors and cable normal or not. •...
- Page 44 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution • Reduce loads. • If sometimes overload, it can be ignored, when generation power enough UpsOverPowerFault 0ff-grid load over can be recovery. • If those faults occurs continuously and frequently, please ask help for local distributors.
- Page 45 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution Pv9SwOverCurrFault Pv10SwOverCurrFault Pv11SwOverCurrFault Pv12SwOverCurrFault Boost1SelfCheck(boost)Fault Boost2SelfCheck(boost)Fault Boost3SelfCheck(boost)Fault Boost4SelfCheck(boost)Fault Boost5SelfCheck(boost)Fault • Power off, then restart (Ref. Chapter8). PV boost circuit abnormal Boost6SelfCheck(boost)Fault • If those faults continuously and when self checking frequently, please ask help for local Boost7SelfCheck(boost)Fault distributors.
- Page 46 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution • Change fuse. BDCFuseFault BiDC fuse broken • Power off, then restart (Ref. Chapter8). • If those faults continuously and BDCRelayFault BiDC relay abnormal frequently, please ask help for local distributors.
- Page 47 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution UpsOverVoltFault Off-grid output voltage over or under UpsUnderVoltFault • Power off, then restart (Ref. Chapter8). • If those faults occurs continuously and UpsOverFreqFault AC Fault Off-grid output frequency frequently, please ask help for local over or under distributors.
- Page 48 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution UpsSCurAdChanFault UpsTCurAdChanFault GenRCurAdChanFault GenSCurAdChanFault GenTCurAdChanFault UpsRDcvAdChanFault UpsSDcvAdChanFault UpsTDcvAdChanFault All temperature sensors TempAdChanFault abnormal The sample value of PV, VoltAdConflictFault battery and BUS voltage • Power off, then restart (Ref. Chapter8). inconsistent •...
- Page 49 Maintenance&Trouble Shooting Type of Fault Code Name Description Recommend Solution EnvirTempAdChan- Warning • The warnings are not matter influence. • Power off, then restart (Ref. Chapter8). Some temperature sensors CoolingTempAdChan- • If those faults occurs continuously and abnormal Warning frequently, please ask help for local distributors.
-
Page 50: Specifications
Specifications 8. Specifications PV Input AF3K-DH AF3.6K-DH AF4K-DH AF4.6K-DH AF5K-DH AF5.5K-DH Max. Input Power (kW) Max. PV Voltage (V) MPPT Range (V) 80 - 550 Normal Voltage (V) Startup Voltage (V) Max. Input Current (A) 15.5 x 2 26.0 x 2 Max. - Page 51 Specifications PV Input AF6K-DH AF7K-DH AF7.6K-DH AF8K-DH AF8.6K-DH AF9.6K-DH Max. Input Power (kW) 10.5 11.4 12.0 12.9 15.0 Max. PV Voltage (V) MPPT Range (V) 80 - 550 Normal Voltage (V) Startup Voltage (V) 15.5 x 2 15.5 x 3 Max.
