  • Page 1 AF3K-DH, AF3.6K-DH, AF4K-DH, AF4.6K-DH, AF5K-DH, AF5.5K-DH, AF6K-DH, AF7K-DH, AF7.6K-DH, AF8K-DH, AF8.6K-DH, AF9.6K-DH Installation and Operation Manual...

  • Page 2: Table Of Contents

    Contents Contents ..................... １ 1.About This Manual ....................３ 1.1 Scope of Validity....................３ 1.2 Target Group....................３ 2.Safety Guidance ....................３ 2.1 Safety Instruction.................... ３ 2.2 Symbols......................４ 3.Introduction ......................４ 3.1 Basic Instruction....................４ 3.2 Operation Modes.................... ５ 3.2.1 Self- use....................５ A.
  • Page 3 5.Operation ......................２８ 5.1 Control Panel....................２８ 5.2 Menu Overview................... ２９ 5.3 Setting......................３０ 5.3.1 Time....................３０ 5.3.2 Safety....................３０ 5.3.12 PV Mode..................３１ 5.3.4 Lithium Battery..................３１ 5.3.5 Lead Acid................... ３２ 5.3.6 Energy Management System............３２ 5.3.7 Timing Charging&Discharging............３３ 5.3.8 AC Timing Charging................３３ 5.3.9 Forced Charging.................３４...

  • Page 4: Contents

    Packed with EPE foam and carton, the inverter should be placed upwards and handled  carefully during delivery. Pay attention to waterproof. Alternative applications, modifications to the inverter are not recommended. Installation of  components that is not authorized by Afore New Energy will make the warranty claims invalid. ３...

  • Page 5: Symbols

    2.2 Symbols AF-DH series hybrid inverters strictly comply with relevant safety standards. Please read and follow all the instructions and cautions before installation, operation and maintenance. 3.Introduction 3.1 Basic Instruction AF-DH series hybrid inverters, when work with batteries can significantly reduce the energy that purchased from the public grid and optimize self-consumption.

  • Page 6: Operation Modes

    1. Solar energy system can work without PV or Battery. 2. Off-grid application is available. 3. With anti-feed-in (default value 0). 3.2 Operation Modes 3.2.1 Self- use A. Normal Mode Priority: Load > Battery > Grid This mode applies to situation that with low feed in subsidy and high electricity price. Solar energy supply to the local load and charge to the battery first.

  • Page 7: Timing Charging

    3.2.2 Timing Charging This mode applies to situation with peak-valley electricity price. Battery can be charged during off-peak hours. The charging and discharging time can be set flexibly, it also allows to set whether charge from the grid or not. 3.2.3 Selling First Priority: Load >...

  • Page 8: Backup First

    3.2.4 Backup First Priority: Battery > Load > Grid This mode applies to situation with frequent power outages. When the public grid is off, enough energy can be supplied to the local load by the batteries. Battery will be charged first, and discharge energy for the local load when the grid is off. It would be charged automatically.

  • Page 9: Eps

    3.2.6 EPS When the grid is suddenly off or abnormal, inverter will change to off grid status automatically. Energy from PV system and battery will supply the local load. 4.Installation 4.1 Pre-installation Check the equipment before installation to make sure whether the packaging and components are lost or damaged, if it is, please contact local distributor directly for support.

  • Page 10: Exterior Objects

    Item Item Hybrid Inverter Security Screw Wall Mounting Bracket Expansion Tube Quick Installation Instructions Backet Screw Inspection Certificate Battery Terminals Warranty Card Earth Terminals Monitor Quick Installtion Monitor Module Smart Meter (Opitional) Power Connectors Communication Connectors 4.1.2 Exterior Objects ９...

  • Page 11: Mounting Location

    Hybrid Inverter Terminals Item Item Emergency Stop Grid Port DC Switch Back Up Battery Port Communication Port Wifi Port Waterproof Ventiating Valve PV Port Earth Screw 4.1.3 Mounting Location AF-DH series hybrid inverters are designed for indoor and outdoor installation (IP65), make sure the mounting location meets the following conditions : Inverters should be installed on a solid surface ...
  • Page 12 Inverters should be installed vertically on the wall, or lean back on plane with a limited tilted  angle. Please refer to following figure. Keep enough space for sufficient heat dissipation, convenient operation and maintenance.  １１...

  • Page 13: Tools Required For Installation

    Inverters should be installed at suitable height for convenient maintenance.  4.1.4 Tools Required for Installation To install the inverter properly, the following tools need to be prepared. Name Remarks Mark Pen Mark the punching position Spanner Screwdriver Wire stripper Crimp Earth Terminals Wire Cutter Power Drill...

  • Page 14: Mounting

    4.2 Mounting １３...

  • Page 15: Electrical Connection

    4.3 Electrical Connection 4.3.1 Communication Communication terminals and configured switches on the bottom of the inverter: １４...

  • Page 16: Adaptation Switch

    Item Switch Switch BAT 485/Meter NTC/BAT CAN Communication Terminals RS485 CT1/CT2 Dry Contact 4.3.1 .1 Adaptation Switch S1 Adaptation Switch Remarks Emergency Switch( default off) CAN-BAT CT485 BAT485 RS485-2 RS485-WIFI 4.3.1.2 BAT/Meter/CT Meter and a current sensor(CT for short below) are used to detect current power direction of the local load and the grid.
  • Page 17 Lithium １６...
  • Page 18 BAT&Meter 485 BAT 485A BAT 485B Meter 485A Meter 485A Connect the meter with the inverter With negative value, the hybrid inverters is feeding power to the grid. With positive value, the load is consuming the power from grid. With below figures and “Imp.”, the system is importing active energy. With below figures and “Exp.”, the system is exporting active energy.
  • Page 19 １８...

  • Page 20: Multi Inverter Parallel

    CT-AC/Meter CT_U CT_N CT_W CT_N Meter Pin definition 4.3.1.3 Multi Inverter Parallel RS485-3 connector is for Multi inverter parallel communication connection. Please check with local distributor or Afore for more information. １９...

  • Page 21: Wifi/Gprs/Lan

    4.3.1.4 WIFI/GPRS/LAN The WiFi/GPRS/LAN module could transmit data to cloud server, and display data on PC (personal computer), tablet and smart-phone. Install the WiFi/GPRS/LAN to the hybrid inverter Turn on the AC power supply and the AC breaker, until the LED indicator on the ...
  • Page 22 BAT NCT&CAN TEP T TEP G CAN H CAN L ２１...

  • Page 23: Drm(Demand Response Mode)

    4.3.1.6 DRM(Demand Response Mode) DRM is only for Australia. DRM1/5 DRM2/6 DRM3/7 DRM4/8 REF/GEN/0 3.3V 4.3.2 PV Connection The AF-DH series hybrid inverters up to three MPPT channels, can be connected with three strings of PV panels. Please make sure below requirements are followed before connecting PV panels and strings to the inverter: Disconnect all the PV (DC) switches before wiring ...

  • Page 24: Battery Connection

    PV3- and the red wire PV1+, PV2+, PV3+ into the terminals on the PCB, and tighten the screws. 4.3.3 Battery Connection AF-DH series hybrid inverters are compatible with lithium battery. For lead acid battery or batteries with other brands, please confirm with local distributor or Afore for technical support. ２３...

  • Page 25: Ac Connection

    4.3.4 AC Connection There are three AC terminals marking with "GRID", "EPS" and "GEN". Before connecting, a separate AC breaker between individual inverter and AC input power is necessary. This will ensure the inverter be securely disconnected during maintenance and fully protected from current of AC input.
  • Page 26 Please follow steps for AC connection Connect DC protector or breaker first before connecting.  Remove insulation sleeve 11mm(0.5 inch) length, unscrew the bolts, insert the AC input  wires according to polarities indicated on the terminal block and tighten the terminal screws.
  • Page 27 EPS Connection Generator Connection ２６...
  • Page 28 Then, insert stripped AC output wires into the terminal block according to polarities  indicated and tighten the terminal. Corresponding N wires and PE wires to the AC terminal should be inserted as well. ２７...

  • Page 29: Earth Connection

    4.3.5 Earth Connection A second protective earth (PE) terminal should be connected to the inverter. This prevents electric shock if the original protective PE wire fails. 5.Operation 5.1 Control Panel ２８...

  • Page 30: Menu Overview

    Items Items Warning Down Power On ENTER Running Items Color Indication Green Power On Power On Yellow Running Running Warning Warning 5.2 Menu Overview AF-DH hybrid inverter has a LCD for clearly operating, and menu of the LCD can be presented as following: Indication for Menu ２９...

  • Page 31: Setting

    Items Indication Running Param To set running parameters Protection Param To set protection parameters System Param To set system parameters Com Param To set communication parameters EMS Param To set energy management parameters P Mode To set active power control parameters Q Mode To set reactive power control parameters 5.3 Setting...

  • Page 32: Pv Mode

    Step3: Password Confirm, “ ▲ /▼” Up/Down Chose “0”, “ ” Confirm, ▼” Up/Down Chose Lith (Lithium Battery), “ ” Enter Battery Factory, Step4: “ ▲ Step5: “ ▲ ▼” Up/Down Chose IvyHv/JBS48/JBSHV/HSD48/TaiSu/HSDHV/Afore/PYLON/Ivy48/, “ ” Confirm, Step6: “ ” Return.

  • Page 33: Lead Acid

    Running Param Running Bat Param ▲/▼ Chose Bat Param Lith Bat Param ▲/▼ Chose AFORE Lith AFOR Lith Param 5.3.5 Lead Acid Step1: “ ” Entry Menu, Step2: “ ▲ /▼”Up/Down Chose Running Param, “ ” Confirm, Step3: Password Confirm, “ ▲ /▼” Up/Down Chose “0”, “ ” Confirm, Step4: “...

  • Page 34: Timing Charging&Discharging

    MENU Running Param ▲/▼ Chose Running Param Running Param EMS Param ▲/▼ Chose EMS Param EPSModeEn EMS Param ▲/▼ Chose EPS Mode SelfUse EPS Mode 5.3.7 Timing Charging&Discharging Step1: “ ” Entry Menu, Step2: “ ▲ /▼” Up/Down Chose Running Param, “ ” Confirm, Step3: Password Confirm, “...

  • Page 35: Forced Charging

    MENU Running Param ▲/▼ Chose Running Param Running Param EMS Param ▲/▼ Chose EMS Param AC Chg EMS Param ▲/▼ Chose AC Chg AC Chg OFF/ON AC Chg 5.3.9 Forced Charging Step1: “ ” Entry Menu, Step2: “ ▲ /▼” Up/Down Chose Running Param, “ ” Confrim, Step3: Password Confirm, “...

  • Page 36: Meter&Ct

    Step3: “ ▲ /▼” Up/Down Chose Meter param，“ ” Confrim, Step4: “ ▲ /▼” Up/Down Chose No Meter / CT/ Meter，“ ” Confrim, Step5: if select Meter, “ ▲ /▼” Up/Down chose Afore / Afore3 / UKOB / User2, Step6: if select CT, “ ▲ /▼” set CT gains, Step7: “...

  • Page 37: Communication Parameters

    EPS side, Gen side). Earth line and Smart meter/CT line are connected.  AF-DF hybrid inverters should be set according to the required local grid standard.  More information please contact with Afore or distributors.  ３６...

  • Page 38: Power On

    6.1 Power ON Turn on DC switch.  After LCD lighting, hybrid inverter should be set following Chapter 5.3 at the first time.  When inverter running under normal mode, Running indicator will light up(Ref. to Chapter  5.1). 6.2 Power off Turn off DC switch ( in hybrid inverter) and all extra-breaker.
  • Page 39 1. Check PV modules wires and connectors broken loose connect, then carry PvAfciFault PV current arcing rectification. 2. If the fault occurs continuously and frequently, please ask help for local distributors. Pv1OverVoltFault Pv2OverVoltFault Pv3OverVoltFault Pv4OverVoltFault 1. Reconfiguration of PV strings, PV Voltage over reduce the PV number of a PV string to reducing inverter PV input...
  • Page 40 Pv24AbnormalFault 1. Check inverters connected PcsBatOverVoltFault battery lines and connectors broken or loose connect, Battery voltage over 2. Carry out rectification if broken or under or loose. PcsBatUnderVoltFault 3. Checking battery voltage is abnormal or not, then maintenance PcsBatInsOverVoltFaul or change new battery. 1.
  • Page 41 BatChgCurOverFault 3. If this fault occurs continuously and frequently, please ask help for BatDChgCurOverFault local distributors. BatTemperatureOverFa BatTemperatureUnderF CelTemperatureOverFa CelTemperatureUnderF BatIsoFault BatSocLowFault BmsInterComFault BatRelayFault BatPreChaFault BmsBatChgMosFault BmsBatDChgMosFault BMSVolOVFault BMSVolLFault VolLockOpenFault VolLockShortFault ChgRefOVFault 1. Inverter will restart automatically when the grid return to normal.
  • Page 42 GridOverVoltFault Grid voltage over 1. The inverter will restart automatically when the grid three GridUnderVoltFault Grid voltage under phase return to normal. 2. Contact with local distributor or required grid company adjust GridLineOverVoltFault Grid line voltage over voltage protection parameters. Grid line voltage GridLineUnderVoltFault under...
  • Page 43 Pv12HwOverCurrFault Pv1SwOverCurrFault Pv2SwOverCurrFault Pv3SwOverCurrFault 1. Power off, power on then PV current over, restart. triggered by Software 2. If those faults occurs continuously logic and frequently, please ask help for local distributors. Pv12SwOverCurrFault Boost1SelfCheckFault Boost2SelfCheckFault Boost3SelfCheckFault 1. Power off, then restart (Ref. PV boost circuit Chapter8).
  • Page 44 BDCSwOverCurrFault Chapter8). 2. If those faults continuously and BiDC abnormal as self BDCSelfCheckFault frequently, please ask help for local checking distributors. BDCSwOverVoltFault BiDC voltage over TransHwOverCurrFault BiDC current over BDCFuseFault BiDC fuse broken 1. Change fuse. 1. Power off, then restart (Ref. Chapter8).
  • Page 45 start impulse current load. 2. Power off, then restart (Ref. Chapter8). UpsTOverCurrFault 3. If those fault occurs continuously and frequently, please ask help for local distributors. GenROverCurrFault 1. Check generator output voltage, Generator current GenSOverCurrFault frequency is stability, and adjust over GenTOverCurrFault generator.
  • Page 46 LeakCurAdChanFault VoltRefAdChanFault UpsRCurAdChanFault UpsSCurAdChanFault UpsTCurAdChanFault GenRCurAdChanFault GenSCurAdChanFault GenTCurAdChanFault UpsRDcvAdChanFault UpsSDcvAdChanFault UpsTDcvAdChanFault All temperature TempAdChanFault sensors abnormal The sample value of VoltAdConflictFault PV, battery and BUS 1. Power off, then restart (Ref. voltage inconsistent Chapter8). The sample value 2. If those faults occurs continuously between master CPU and frequently, please ask help for CPUAdConflictFault...
  • Page 47 and frequently, please ask help for local distributors. 1. The warnings are not matter EnvirTempAdChanWarning influence. 2. Power off, then restart (Ref. Some temperature Chapter8). CoolingTempAdChanWarni sensors abnormal 3. If those faults occurs continuously and frequently, please ask help for local distributors.
  • Page 48 1. Check earth line connection or earth connecting impedance, 2. if abnormal, then adjust it. Earth impedance over 3. Power off, then restart (Ref. GndAbnormalWarning by cable loose and so Chapter8). 4. If this those faults continuously and frequently, please ask help for local distributors.

  • Page 49: Specifications

    8. Specifications Hybrid Inverter ４８...
  • Page 50 ４９...
  • Page 51 ５０...
  • Page 52 Building 7, No.333 Wanfang Rd, Minhang District, Shanghai, China. 201112...
