COMPRESSEUR SILENCIEUX AUTOMATIQUE
Costruttore - Manufacturer - Manufacturer
Hersteller - Fabricante
WERTHER INTERNATIONAL Inc.
8614 Veterans Memorial Drive
Houston, TX 77088 - USA
Phone
832-327-9378
E-MAIL info@werther.com
WEB
www.werther.com
GTEK AUTOMATION
26212 Dimension Drive, Suite 150
Compressore silenzioso automatico
AUTOMATIC SILENT COMPRESSOR
AUTOMATISCHE LEISELAUFKOMPRESSOR
COMPRESSORE SILENCIOSO AUTOMATICO
PC120-4C
Lake Forest, CA 92630
Centro di assistenza autorizzato
Authorized service center
Centre technique agréé
Zugelassenes Kundendienstzentrum
Centro de asistencia autorizado
Ph. 949-680-4242
www.gtek-automation.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC120-4C and is the answer not in the manual?

Questions and answers

Related Manuals for WERTHER INTERNATIONAL PC120-4C

Summary of Contents for WERTHER INTERNATIONAL PC120-4C

  • Page 1 COMPRESSORE SILENCIOSO AUTOMATICO PC120-4C Costruttore - Manufacturer - Manufacturer Centro di assistenza autorizzato Authorized service center Hersteller - Fabricante Centre technique agréé WERTHER INTERNATIONAL Inc. Zugelassenes Kundendienstzentrum 8614 Veterans Memorial Drive Centro de asistencia autorizado Houston, TX 77088 - USA Phone 832-327-9378 E-MAIL info@werther.com...
  • Page 2 INDICE ....... . 2 CONTENTS ......9 TABLE DES MATIERES .

  • Page 3: Table Of Contents

    CONTENTS 1 General information................10 1.1 Importance and use of the manual.................10 1.2 Content ........................10 1.3 Storage..........................10 1.4 Weights and dimensions ....................10 1.5 Packing disposal......................10 1.6 Lifting ..........................10 1.7 Safety .........................11 2 Operation....................12 2.1 Machine set up ......................12 2.2 Operating instructions....................12 2.3 Filling up........................13 2.4 Check of filling time ......................13 3 Troubleshooting...................14...

  • Page 4: General Information

    General information 1.1 IMPORTANCE AND USE OF THE MANUAL This manual is an integral part of the compressor and must always accompany it, even in the event of sale. The compressor owner and/or user must know the operating in- structions and recommendations before using the compressor. If the operator does not fully understand the language of this manual, the retailer must supply a correct and de- tailed translation into his or her native language.

  • Page 5: Safety

    1.7 SAFETY Do not use the compressor for purposes other than those for which it has been de- signed. To be kept in a covered place and protected from rain and humidity. When using the compressor, keep it out of reach of children, never leave it unattended and not direct air stream towards persons.

  • Page 6: Operation

    Operation 2.1 MACHINE SET UP Install the compressor on a flat surface, in a suitably sized room, well ventilated and not wet, where the temperature is not likely to rise above 35°C. If there is not enought air ventilation, install a suitably sized exhauster or fan. The power supply voltage must be the same indicated on the data label: 230V/50Hz (115V/60Hz) and the socket must be 2 pole+ground type.

  • Page 7: Filling Up

    WARNING! Compressor must be connected to a power supply socket protected by a suitable magneto-thermic switch. The tabs show the absorption data for each type of compressor: Motor type 230 V 230 V 115 V 50 Hz 60 Hz 60 Hz 3.1 A 4.2 A 8.5A...

  • Page 8: Troubleshooting

    Troubleshooting WARNING · Before any operation on the compressor, disconnect the plug from the socket. · Empty air tank of air before dismantling any part of compressor unit’s pressure sys- tem. · Following operations must be done by a specialist. 3.1 The compressor does not start ·...
  • Page 9 3.5 The compressor stops while working · The motor has an automatic resetting thermal protection, that stops the compressor when the temperature is too high. The compressor will start again automatically after 15/20 minutes. · 3.6 Air leaks · Can be due to bad seal of any connection, check all connections wetting with suds ·...

  • Page 10: Special Informations

    Special informations 4.1 COMPRESSOR DEMOLITION During the compressor demolition all possible safety regulations must be ob- served in order to avoid any damage to people or things. All the metal parts can be recycled; rubber and plastic parts have to be disposed of in the compliance with the laws in force in the country where the compressor is installed.
  • Page 11 C.F.M. Gal. " 230 50 0.69 - 3.1 120 - 4.3 7 - 101 3.5 - 0.83 PC120-4C 230 60 0.92 - 4.2 145 - 5.2 7 - 101 3.5 - 0.83 115 60 0.9 - 8.5 145 - 5.2 7 - 101 3.5 - 0.83...
  • Page 12 Figure / Drawing / Figures / Abbildungen / Dibujo Fig.1 Fig.2 Fig.3 Fig.4 GTEK AUTOMATION 26212 Dimension Drive, Suite 150 Lake Forest, CA 92630 Ph. 949-680-4242 www.gtek-automation.com...
  • Page 13 MANUTENZIONE PERIODICA / PERIODIC MAINTENANCE volta ogni volta giorno all’ann mese every day once a once a year month Fig. 6 Fig. 7 Fig. 8 Fig.9 Scaricare l’acqua accumulata nel Drain the water collected in the air riduttore/filtro uscita aria procedendo outlet filter proceeding as Fig.
