TABLE OF CONTENTS About Vitess™ ................. 4 Terminology and Formats of Delivery ............ 5 Rim Cylinders .................. 6 Mortise Cylinders ................7 Key-N-Knob/Lever Cylinders ..............8 Deadbolts ..................8 83 Series Cylinder ................9 Key Bitting Specification ..............10 Calculation Rules ................11 Master Key System Management ............ - Page 3 A locking system is a decisive element in ensuring a building has the highest levels of security, comfort and flexibility. It regulates who has access to a building, and specifies each person‘s access rights. ABUS doesn‘t offer an off-the-peg solution, but rather a complete, well-designed modular system. This means you can select the exact equipment you need.
-
Page 4: About Vitess
20 years after the creation of the grand master key system. Of course, the 0.55˝ system can also be extended - mechanically or electronically - at any time. For this ABUS plans 20% extension reserve in advance. -
Page 5: Terminology And Formats Of Delivery
TERMINOLOGY Vitess™ Terms Throughout this manual, we use specific terms to define the components of the Vitess™ program. Images and descriptions of these terms are provided below. As a sample we have chosen a KnK/KiL cylinder, but the concept of formats is similar for Rim, Mortise etc. -
Page 6: Rim Cylinders
CONVENTIONAL RIM CYLINDERS Specifications HD: Head Diameter HT: Head Thickness BL: Body Length BD: Body Diameter Item HD - Head Diameter HT - Head Thickness BL - Body Length w/cam BD - Body Diameter Rim Cylinder 1.337” (33.95mm) 0.118” (3mm) 1.075”... -
Page 7: Mortise Cylinders
CONVENTIONAL MORTISE CYLINDERS Specifications HD: Head Diameter HT: Head Thickness BL: Body Length BD: Body Diameter Item HD - Head Diameter HT - Head Thickness BL - Body Length w/cam BD - Body Diameter 1-1/8” Mortise Cylinder 1.370” (34.8mm) 0.138” (3.5mm) 1.042”... -
Page 8: Key-N-Knob/Lever Cylinders
KEY-IN-KNOB/LEVER, DEADBOLT CYLINDERS Specifications BL: Bible Length CD: Cylinder Diameter CH: Cylinder Height CL: Cylinder Length EL: Effective Length FL: Front Length PD: Plug Face Diameter Item BL - Bible CD - Cylinder CH - Cylinder CL - Cylinder EL - Effective FL - Front PD - Plug Face Length... -
Page 9: Series Cylinder
83 SERIES™ CYLINDER INSERT Tailpiece Tailpiece Specifications BL: Bible Length CD: Cylinder Diameter CH: Cylinder Height CL: Cylinder Length EL: Effective Length FL: Front Length PD: Plug Face Diameter Item BL - Bible CD - Cylinder CH - Cylinder CL - Cylinder EL - Effective FL - Front PD - Plug Face... -
Page 10: Key Bitting Specification
KEY BITTING SPECIFICATION Root inch inch Master inch inch Depths Pins Wafer Distance 4.55 0.1791 9.23 0.3634 4.55 0.179 3.75 0.148 4.90 0.1929 8.88 0.3496 4.20 0.165 7.55 0.297 5.25 0.2067 8.53 0.3358 3.85 0.152 11.30 0.445 5.60 0.2205 8.18 0.3220 3.50 0.138... -
Page 11: Calculation Rules
CALCULATION RULES Recommended according to German standards. • When using one key-way for KD/KA and MKS calculate with 2-step-progression (code groups, even, odd) • Maximum repeated depths/cuts per key: 3 525226 525525 • Maximum consecutive repeated depths/cuts per key: 2 535226 533342 •... -
Page 12: Assembly Instructions - Rim
ASSEMBLY INSTRUCTIONS - RIM Delivery of the pre-loaded housing • Our pre-loaded housing includes all parts that are necessary to assemble a functional cylinder • Inside the cylinder there is a black plastic plug which has to be exchanged by a pinned core •... -
Page 13: Assembly Instructions - Mortise
ASSEMBLY INSTRUCTIONS - MORTISE Delivery of the pre-loaded housing • Our pre-loaded housing includes all parts that are necessary to assemble a functional cylinder • Inside the cylinder there is a black plastic plug which has to be exchanged by a pinned core •... -
Page 14: Assembly Instructions - Knk/Kil
ASSEMBLY INSTRUCTIONS - KNK/KIL Delivery of the pre-loaded housing • Our pre-loaded housing includes all parts that are necessary to assemble a functional cylinder. Inside the cylinder there is a black plastic plug which has to be exchanged by a pinned core. •... -
Page 15: Assembly Instructions - 83 Insert
ASSEMBLY INSTRUCTIONS - 83 INSERT Delivery of the pre-loaded housing • Our pre-loaded housing includes all parts that are necessary to assemble a functional cylinder. Inside the cylinder there is a black plastic plug which has to be exchanged by a pinned core. •... -
Page 16: Special Pin Instructions - Knk/Kil And 83 Insert
ASSEMBLY INSTRUCTIONS - KNK/KIL Attention: If your pin Pin/Cut 1 (intop) <- Pin Chamber cut is a 9 in the 3rd, 5th or 6th chamber the top pins need to be changed according to Standard the following table: Top Pins 10609 10610 10610... -
Page 17: Refill Of Housings
REFILL OF HOUSINGS • Insert the top pins • 1st and 3rd chamber: hardened steel; • 2nd and 4th chamber: anti-pick mushroom pins • 5th and 6th chamber: stainless steel “centering” pins Top-Pin: Hardened Mushroom: Brass Top-Pin: Hardened Mushroom: Brass Top-Pin: Nickel Silver Top-Pin: Nickel Silver Step 1... -
Page 18: Notes
