- Page 1 TVS4091 4” LCD Color TV OWNER’S MANUAL...
- Page 2 INTRODUCTION The Clarion TVS4091 is a full-featured 4" LCD Color TV. It can be used as a stand-alone unit or integrated into a mobile multimedia system. This unit was specially designed for marine use and is water-resistant. ABOUT THE MANUAL AND W ARRANTY To start enjoying your new Clarion TVS4091, please read the instructions listed in this manual.
- Page 3 Do not disassemble or modify the set. Doing so may damage it. • Small black and shiny dots inside the liquid crystal panel are normal for liquid crystal products. PACKAGE CONTENTS The Clarion TVS4091 comes with the following items: • Plastic mounting base Available Options: •...
- Page 4 Handle Rod Antenna Earphone Jack A/V Input Jack DC Power Input Jack INSTALLATION One of the following power sources can be used: • Batteries (4 "D" size) • DC Power For Use with Batteries: 1. Move the Rod Antenna. 2. Lift the Battery Cover Latch up to open the Battery Compartment. 3.
- Page 5 TV OPERATION 1. Press the POWER ON/OFF button to turn on the power. The LCD screen will light up. To turn the power OFF press the POWER button again. 2. Press the VHF/UHF Button to select VHF or UHF band. 3.
- Page 6 1. Choose a flat surface to install the TVS4091 stand. 2. Use the two supplied 1” screws to securely attach the stand to the mounting surface. 3. Fold the handle of the TVS4091 to the downward position. Slide the unit into the mounted stand. TROUBLESHOOTING Problem: No Picture.
- Page 7 Problem: Blurry picture and noise. Solution: • You may need to adjust the TV reception. Extend or adjust the Rod Antenna. • The unit may not be properly tuned. Check the VHF/UHF band setting and retune. • The batteries may be low. Check the batteries. •...
- Page 8 661 W. Redondo Beach Blvd. Gardena, CA 90247 1-800-GO-CLARION www.clarion-usa.com TVS4091-10 Rev.1 (04/00)
