Daikin FTK09P5VL Service Manual

Hide thumbs

Table Of Contents

Quick Links

Si041417EA

REMOVAL

PROCEDURE

S E R V I C E

M A N U A L

9000/12000/18000 Btu/h Class

Indoor Unit

Inverter

Wall Mounted Type

Table of Contents

Need help?

Do you have a question about the FTK09P5VL and is the answer not in the manual?

Questions and answers

Summary of Contents for Daikin FTK09P5VL

Page 1 Si041417EA REMOVAL PROCEDURE S E R V I C E M A N U A L 9000/12000/18000 Btu/h Class Indoor Unit Inverter Wall Mounted Type...
Page 2 Service Manual Removal Procedure Indoor Unit Cooling Only FTK09P5VL FTK12P5VL FTK18P5VL Heat Pump FTH09P5VL FTH12P5VL FTH18P5VL FTX09N5VL FTX12N5VL FTX18N5VL...
Page 3: Table Of Contents
Si041417EA Table of Contents 1. Air Filters / Front Panel ................2 2. Front Grille ....................3 3. Horizontal Blade..................4 4. Electrical Box ..................5 5. PCBs / Swing Motor ................9 6. Indoor Heat Exchanger .................12 7. Fan Rotor / Fan Motor................14 8. Fan Guards / Vertical Blade ASSYs............16 Note: The illustrations may be slightly different depending on the model.
Page 4: Air Filters / Front Panel
Air Filters / Front Panel Si041417EA 1. Air Filters / Front Panel Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the air filters. The air filter is not marked Front panel for difference between the Open the front panel.
Page 5: Front Grille
Si041417EA Front Grille 2. Front Grille Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the 2 screws Front grille of the front grille. (R21004) Unfasten the 3 hooks at The convex marks (…) on Hook the top.
Page 6: Horizontal Blade
Horizontal Blade Si041417EA 3. Horizontal Blade Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Release the center shaft while bending the horizontal blade slightly. Horizontal blade (R21006) Installation procedure 1.
Page 7: Electrical Box
Si041417EA Electrical Box 4. Electrical Box Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Disconnect the Service cover can be connecting wire. removed without removing the front grille.
Page 8 Electrical Box Si041417EA Step Procedure Points Pull out the indoor heat Be careful not to lose the clip Indoor heat exchanger thermistor exchanger thermistor. of the thermistor. Clip (R11268) The position of the indoor heat exchanger thermistor varies depending on the (R21015) model.
Page 9 Si041417EA Electrical Box Step Procedure Points Disconnect the [S200]: fan motor connector [S200]. Release the harnesses from the 4 hooks. [S200] Hook Hook (R21019) Disconnect the [S6]: swing motor connector [S6]. Release the harnesses from the 4 hooks. [S6] Hook Hook (R21020) 10 Remove the screw of...
Page 10 Electrical Box Si041417EA Step Procedure Points 11 Slightly lift the electrical When reassembling, make box upward and sure the hook is securely remove it. fastened. Hook (R21022) When reassembling, make Bottom frame Right view sure that the 2 hooks are securely fastened to the Hook bottom frame.
Page 11: Pcbs / Swing Motor
Si041417EA PCBs / Swing Motor 5. PCBs / Swing Motor Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the control PCB. Black White Earth/ground Earth/ground Disconnect all the 4 terminals.
Page 12 PCBs / Swing Motor Si041417EA Step Procedure Points When reassembling, be sure to fit the control PCB to the 4 projections. Projection (R24261) 2. Remove the display PCB. Left side Front side Unfasten the 3 hooks of the display PCB ASSY. Hook Hook Display PCB ASSY...
Page 13 Si041417EA PCBs / Swing Motor Step Procedure Points Turn over the display Back view PCB ASSY. Unfasten the 3 hooks Hook and remove the display PCB. Display PCB Hook (R24263) 3. Remove the swing motor. Remove the screw, and then the swing motor. Swing motor (R21032) Removal Procedure...
Page 14: Indoor Heat Exchanger
Indoor Heat Exchanger Si041417EA 6. Indoor Heat Exchanger Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. In pump-down work, be sure to stop the compressor before disconnecting the refrigerant pipe. If the refrigerant pipe is disconnected with the compressor operating and the stop valve open, air may be sucked in and may generate an over-pressure in refrigeration cycle, thus resulting in pipe rupture or accidental injury.
Page 15 Si041417EA Indoor Heat Exchanger Step Procedure Points Detach the indoor unit from the installation plate. (R21034) 2. Remove the indoor heat Back view exchanger. Piping fixture Unfasten the 2 hooks and remove the piping fixture on the back of the indoor unit. Hook (R24350) Slightly pull out the...
Page 16: Fan Rotor / Fan Motor
Fan Rotor / Fan Motor Si041417EA 7. Fan Rotor / Fan Motor Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the screw of Right side plate the right side plate.
Page 17 Si041417EA Fan Rotor / Fan Motor Step Procedure Points Pull out and remove the Fan motor stator ASSY fan motor stator ASSY. Unfasten the 2 hooks and disassemble the fan motor stator ASSY. Hook (R24351) Fan motor cover (body) Bearing rubber cushion Fan motor stator...
Page 18: Fan Guards / Vertical Blade Assys
Fan Guards / Vertical Blade ASSYs Si041417EA 8. Fan Guards / Vertical Blade ASSYs Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the fan guards. The fan guards are not Fan guard marked for difference...
Page 19 Revision History Month / Year Version Revised contents 01 / 2015 Si041417E First edition 12 / 2016 Si041417EA Model addition: FTK09/12/18P5VL, FTH09/12/18P5VL...
Page 20 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
