JVC VU-V63KITU Instructions

VU-V63KITU
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
The AC Charger Station should be used with AC 120V`
60 Hz only in the USA and Canada. In other countries,
this unit should be used with AC 110 – 240 V`
only.
CAUTION:
To prevent electric shocks and fire hazards, do NOT use
any other power source.
Warning on lithium cell battery
(for remote control unit)
The battery used in this device may present a fire or
chemical burn hazard if mistreated. Do not recharge,
disassemble, heat above 100°C (212°F) or incinerate.
Replace battery with Maxell, Panasonic (Matsushita
Electronic), Sanyo or Sony CR2025; use of another battery
may present a risk of fire or explosion.
Dispose of used battery properly.
Keep away from children.
Do not disassemble and do not dispose of in fire.
CAUTION (applies to the AC Charger Station):
TO REDUCE THE RISK OF FIRE, DO NOT
REMOVE COVER (OR BACK). NO USER–
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION (applies to the AC Charger Station):
TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
CAUTIONS:
•If used near a radio, this unit may interfere with
reception.
•Prevent inflammables, water and metallic objects from
entering the unit.
•Do not disassemble or modify the unit.
•Do not apply shocks to the unit.
•Do not subject the unit to direct sunlight.
•Avoid using the unit in extremely hot or humid places.
•Avoid using the unit in places subject to vibrations.
USING HOUSEHOLD AC PLUG ADAPTER
In case of connecting the unit's power cord to an AC wall
outlet other than American National Standard C73 series
type use an AC plug adapter, called a "Siemens Plug", as
shown.
For this AC plug adapter, consult your nearest JVC dealer.
Plug adapter (optional)
This Class B digital apparatus complies with Canadian
ICES-003
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
NOTE:
The rating plate (Serial number plate) of the AC Charger
Station is on the bottom of the unit.
Thank you for purchasing the JVC Station Kit.
•This product should be used with JVC Digital Video Cameras only.
•Before using, be sure to read these instructions as well as your Digital Video Camera's
Instruction manual carefully.
Provided accessories
` ` , ` `
AC Charger Station
AA-V60U
` ` ` ` , 50/60 Hz
Lithium battery CR2025
(for remote control unit)

Specifications

AA-V60U AC Charger Station
Power
Power consumption
Power output
Operating
temperature
Dimensions
Weight
Charging time for
BN-V607U Battery
pack (based on
room temperature
of 10˚C to 35˚C)
Cautions
Do not incinerate or disassemble; may explode or release toxic chemicals.
Do not short circuit; may cause burns.
When charging a brand new Battery Pack, or one that's been in storage for an extended period, the
Charging Indicator may not come on. In this case, remove the Battery Pack, then reattach and try
charging again.
Vibration noise can sometimes be heard coming from the inside of the AC Power Adapter/Charger.
This is normal.
The AC Charger Station processes electricity internally, and will become warm during use. This is
normal. Make sure to use the AC Charger Station in well-ventilated areas only.
STATION KIT INSTRUCTIONS
DC cord
VIDEO/AUDIO cable
(AC Charger Station
to TV or VCR,
RCA plug 4 RCA plug)
U.S.A. and Canada:
AC 120 V`, 60 Hz
Other countries:
AC 110 to 240 V`, 50/60 Hz
20 W
DC 7.2 V , 0.77 A (charge)
DV 6.3 V , 1.8 A (VTR)
0˚C to 40˚C (32˚F to 104˚F) (10˚C to
35˚C (50˚F to 95˚F) when charging)
80 mm (W) x 39 mm (H) x 146 mm (D)
(3-3/16" x 1-9/16" x 5-3/4")
Approx. 360 g (0.8 lbs)
Approx. 90 min.
T
Remote control unit
RM-V712U
S-VIDEO cable Editing cable
(ø3.5 mini-plug, 2 poles)
RM-V712U Remote Control Unit
Power DC 3 V
(CR2025 Lithium battery x 1)
Operating 0˚C to 40˚C (32˚F to 104˚F)
temperature
Transmission range Approx. 5 m
Dimensions 54 mm (W) x 86 mm (H) x 12 mm (D)
(2-3/16" x 3-7/16" x 1/2")
Weight Approx. 26 g (0.06 lbs)
NOTE:
Perform charging where the temperature is
between 10˚ and 30˚C (50˚F and 86˚F). 20˚ to 25˚C
(68˚F to 77˚F) is the ideal temperature range for
charging. If the environment is too cold, charging
may be incomplete.
E. O. E. Design and specifications subject to change without
notice.
U
ENGLISH
W
0598HOV * UN * SW
LYT0215-001A
