INSTALLATION, MAINTENANCE AND USER'S GUIDE
FAN WITH ELECTRONICALLY COMMUTATED EXTERNAL-ROTOR MOTOR
&
Note :
Be sure to familiarize yourself with these instructions before working on this unit. Not paying attention to these warnings
and instructions may lead to malfunctions and failures or may seriously endanger human life.

Table of Contents :

01
02
TYPICAL FEATURES AND PROPER USE
03
04
05
06
07
08
09
10
11
12
Fan Code:
0314-4-0166
Fan type : R14R-63APS-ET80B-10C17
Symbols :
WARNING - to indicate warning situation
NOTE - indicate valuable information
