FAN WITH ELECTRONICALLY COMMUTATED EXTERNAL-ROTOR MOTOR
&
Note :
This document contains instructions and information for the operation, installation, connection, use and maintenance of
the product. Be sure to familiarize yourself with these instructions before working on this unit. Not paying attention to
these warnings and instructions may lead to malfunctions and failures or may seriously endanger human life. More
detailed information and instructions are available from the manufacturer on request.
Table of Contents :
01
SAFETY
02
TYPICAL FEATURES AND PROPER USE
03
04
05
06
07
08
PROTECTIVE FEATURES
09
10
11
12
Fan Code:
0318-4-1005
Fan type : R18R-080MPS-ET120B-01A01
Symbols :
WARNING - to indicate warning situation
WARNING - to indicate hot surfaces
DANGER due to electric shock
NOTE - indicate valuable information
Advertisement
Table of Contents
Related Manuals for HIDRIA R18R-080MPS-ET120B-01A01
Summary of Contents for HIDRIA R18R-080MPS-ET120B-01A01
-
Page 1: Table Of Contents
INSTALLATION, MAINTENANCE AND USER'S GUIDE FAN WITH ELECTRONICALLY COMMUTATED EXTERNAL-ROTOR MOTOR Fan Code: 0318-4-1005 Fan type : R18R-080MPS-ET120B-01A01 & Note : This document contains instructions and information for the operation, installation, connection, use and maintenance of the product. Be sure to familiarize yourself with these instructions before working on this unit. Not paying attention to these warnings and instructions may lead to malfunctions and failures or may seriously endanger human life. - Page 2 The electronics housing can get hot. In case the external metal enclosure is accessible to user, maximum operating ambient temperature is reduced to max.amb. 55°C. 2 / 10 © Copyright HIDRIA d.o.o., All rights reserved. Document is subject to change without prior notification.
- Page 3 Maintenance free ball-bearings and dynamically balanced rotating parts. Control circuit is SELV isolated from main power supply (including an external power supply for sensors). 3 / 10 © Copyright HIDRIA d.o.o., All rights reserved. Document is subject to change without prior notification.
-
Page 4: Installation, Maintenance And User's Guide
- IEC 60034-1 - Data on the nameplate established at a point of nominal Airflow volume max., qV: 27336 m³/h load according to standard for Rotational electrical machines. Pressure Increase max., ps: 610 Pa 4 / 10 © Copyright HIDRIA d.o.o., All rights reserved. Document is subject to change without prior notification. -
Page 5: Installation And Connection
(RCM) device is used for protection in case of direct or indirect contact, only an RCD or RCM of Type B+ is allowed on the supply side of this product and recommended sensitivity is 300mA with short time delayed intervention. The electrical connection must correspond to the enclosed connection diagram. 5 / 10 © Copyright HIDRIA d.o.o., All rights reserved. Document is subject to change without prior notification. - Page 6 Slave control : OUT - GND Alarm relay: COM - NC (SELV) The device is compatible with Modbus protocol RTU. Please read additional instructions about Hidria EC Modbus parameters. WARNING : Leakage current exceeds 3.5mA. Short circuit rating: <10kA .
-
Page 7: Speed Control
Linear voltage input (0-10V DC) can be used as 0 (4)-20mA current input with an additional resistor of 500 Ohms between GND and 0-10V connection. 7 / 10 © Copyright HIDRIA d.o.o., All rights reserved. Document is subject to change without prior notification. -
Page 8: Putting Into Operation
Fan has integrated NFC/RFID tag, based on ISO/IEC 15693, that can be used for advanced custom fan functionality configuration. NFC/RFID tag is located as shown in the figure below. Before using NFC/RFID, the aluminium cover must be removed. Please see Hidria Fan App manual for more information. -
Page 9: Diagnostics & Troubleshooting
- Break active. RED STATUS: - Rotor locked. - Motor overheating. - Power module overheating. - DC link undervoltage error. - Internal communication error. 9 / 10 © Copyright HIDRIA d.o.o., All rights reserved. Document is subject to change without prior notification. -
Page 10: Maintenance, Service And Cleaning
Ensure that the fan is switched off from the supply mains before removing the guard. Fan has integrated NFC/RFID tag, based on ISO/IEC 15693, that can be used for fan functionality configuration. Please see Hidria Fan App manual for more information.
