Service
Manual
• For purposes of improvement, specifications and design are subject to change without notice.
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
S1019-V02DM/DG1506
AV7701
Copyright 2015 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
AV7701 /
U1B,K1B
N1B
AV Pre Tuner
Ver. 2
Please refer to the
MODIFICATION NOTICE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV7701 and is the answer not in the manual?

Questions and answers

Related Manuals for Marantz AV7701

Summary of Contents for Marantz AV7701

  • Page 1 Service AV7701 / U1B,K1B Manual AV Pre Tuner • For purposes of improvement, specifications and design are subject to change without notice. • Please use this service manual with referring to the operating instructions without fail. • Some illustrations using in this service manual are slightly different from the actual set.

  • Page 2: Table Of Contents

    CONTENTS ABOUT THIS MANUAL .............3 GUIDE R ................129 What you can do with this manual ..........3 FRONT HDMI FFC ...............129 Using Adobe Reader (Windows version) ........4 PREOUT ................130 SIDE CNT ................131 SAFETY PRECAUTIONS ............7 FRONT CNT .................132 NOTE FOR SCHEMATIC DIAGRAM .........8 VIDEO ..................134 TECHNICAL SPECIFICATIONS ..........9 HDMI ..................136...

  • Page 3: About This Manual

    ABOUT THIS MANUAL Read the following information before using the service manual. What you can do with this manual Search for a Ref. No. (phrase) Jump to the target of a schematic diagram (Ctrl+Shift+F) connector You can use the search function in Acrobat Reader to Click the Ref.

  • Page 4: Using Adobe Reader (Windows Version)

    Using Adobe Reader (Windows version) Add notes to this data (Sign) Magnify schematic / printed wiring board The Sign function lets you add notes to the data in this diagrams - 1 manual. (Ctrl+Space, mouse operation) Save the file once you have finished adding notes. Press Ctrl+Space on the keyboard and drag the mouse to select the area you want to view.
  • Page 5 Magnify schematic / printed wiring board Magnify schematic / printed wiring board diagrams - 2 diagrams - 3 (Pan & Zoom function) (Loupe Tool function) The Pan & Zoom function lets you see which part of a The Loupe Tool function lets you magnify a specific magnified diagram is being shown in a separate window.
  • Page 6 Parts for your equipment are generally available to our National Marantz Subsidiary or agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified. The following information must be supplied to eliminate delays in processing your order : 1. Complete address 2.

  • Page 7: Safety Precautions

    SAFETY PRECAUTIONS The following items should be checked for continued protection of the customer and the service technician. LEAKAGE CURRENT CHECK Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check.

  • Page 8: Note For Schematic Diagram

    NOTE FOR SCHEMATIC DIAGRAM WARNING: Parts indicated by the z mark have critical characteristics. Use ONLY replacement parts recommended by the manufacturer. CAUTION: Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set is defective.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS n Audio Section n Tuner section • Analog (ANTENNA input – MEDIA PLAYER OUT) [FM](Note: μV at 75 Ω, 0 dBf = 1 x 10 Input sensitivity/Input impedance : 200 mV/47 kΩ –15 Receiving Range : Frequency response: 10 Hz – 100 kHz — +1, –3 dB (DIRECT mode) S/N : 105 dB (IHF–A weighted, DIRECT mode) [FM] 87.5 MHz –...

  • Page 10: Caution In Servicing

    So make sure to note down your setting beforehand for restoring after the initialization. MOVIE MUSIC ON / STANDBY (X) Service Jig When you repair the printing board, you can use the following JIG (Extension cable kit). Please order it from marantz Official Service Distributor in your region if necessary. 8U-110084S EXTENSION UNIT KIT 2 Set When you update the firmware by DFW, you can use the following JIG (RS232C to internal connector conversion adapter with 4P FFC cable kit ).

  • Page 11: Disassembly

    DISASSEMBLY • Disassemble in order of the arrow in the following figure. • In the case of the re-assembling, assemble it in order of the reverse of the following flow. • In the case of the reassembling, observe "Caution concerning disassembly and assembly!". • If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as they were originally bundled or placed afterward.

  • Page 12: Front Panel Assy

    About the photos used for "descriptions of the DISASSEMBLY" section • The shooting direction of each photograph used herein is indicated on the left side of the respective photograph as "Shooting direction: ***". • Refer to the diagram below about the shooting direction of each photograph. •...
  • Page 13 (2) Cut the wire clamp band, then disconnect the connector wires and FFC. STYLE PIN : Loosen CN602 CN321 (3) Remove the screws. Shooting direction: C Shooting direction: D...
  • Page 14 (4) Disconnect the connector wire and FFC. STYLE PIN : Loosen Shooting of photograph: A BN321 (5) Remove the screws, then detach the FRONT BRACKET. Shooting of photograph: A FRONT BRACKET (6) Remove the screws. FRONT BRACKET Shooting of photograph: A EARTH DOOR FRONT BRACKET...
  • Page 15 (7) Remove the screws. Shooting of photograph: A GEAR , DAMPER...

  • Page 16: Heat Sink Assy

    2. HEAT SINK ASSY Proceeding : CABINET TOP HEAT SINK ASSY → (1) Remove the screws. View from the bottom (2) Cut the wire clamp band, then remove the screws. Disconnect the connector wires. Shooting direction: C Shooting direction: D...
  • Page 17 (3) Cut the wire clamp band, then disconnect the connector wire and FFC. CN602 STYLE PIN : Loosen HEAT SINK Assy CN321 (4) Cut the wire clamp bands, then disconnect the connector wires. CN461P CN601 CN701 CN704 CN705 CN461 CN7010 CN492...

  • Page 18: Hdmi Unit Assy

    3. HDMI UNIT ASSY Proceeding : CABINET TOP HEAT SINK ASSY HDMI UNIT ASSY → → (1) Remove the screws. View from the bottom (2) Remove the screws, then remove the BACK PANEL and the HDMI BRACKET. Shooting of photograph: A...
  • Page 19 (3) Cut the wire clamp band, then disconnect the connector wires and the FFC. Remove the PCB HDMI from the PCB FRONT CNT and PCB SIDE CNT (Board to board). STYLE PIN : Loosen CN321 (4) Disconnect the connector wire. Remove the screws. Shooting direction: C...
  • Page 20 (5) Remove the screws. Shooting direction: A (6) Remove the screws, then disconnect the connector wires. Shooting direction: A CN940, CN941...

  • Page 21: Trans Main

    (7) Cut the wire clamp bands, then disconnect the connector wires, and remove the screws. Shooting direction: A CN902 Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in HDMI UNIT ASSY. 4. TRANS MAIN Proceeding : CABINET TOP HEAT SINK ASSY HDMI UNIT ASSY...

  • Page 22: Special Mode

    SPECIAL MODE Special mode setting button b No.1 - 5, 6, 7 : Press the "ON/STANDBY ( X )" button to turn on the power while pressing both the buttons A and the button B at the same time. b No.8 - 10: Turn on the power, then press and hold down the A and B buttons for over 3 seconds.

  • Page 23: Μcom/Dsp Version Display Mode

    1. µcom/DSP Version display mode 1.1. Operation specifications µcom/DSP version display mode: When the set is started up in this mode, the version information is displayed. Starting up: Press the "ON/STANDBY ( X )" button to turn on the power while pressing the "STATUS" and "DISPLAY" buttons. Now, press the "STATUS"...
  • Page 24 i Ethernet(DM860A) 1st Boot Loader, Hardware ID : Upper E t h e r n e t F B L Lower * * * * * * - A A o Ethernet(DM860A) 2nd Boot Loader : Upper E t h e r n e t S B L Lower * * * * * * * * * * * * * - B B...
  • Page 25 1.3. Error display See the following table for each "Error information" display and its explanation (status). Display order is q , w , e , r , t , y , u , i . Condition Status FL Display Trouble shooting •...
  • Page 26 1.4. Version display on the Setup Menu Use the following procedure to display the firmware version. (1) Press the "SETUP" button on the remote control. (2) Select "General-Information-Firmware". A version with 20 digits is displayed as shown in the following image. General/Firmware Version 1490-0186-0000-7020-8975 General/Firmware 1490-0186-0000-7020-8975 Version Displays system information GUI Image Displays system information GUI Image...

  • Page 27: Panel/Remote Lock Selection Mode

    2. PANEL/REMOTE LOCK Selection mode 2.1. Behavior specifications In this mode, you can switch between the PANEL LOCK MODE and the Mode for preventing remote control acceptance. 2.2. Starting up Press the "ON/STANDBY ( X )" button to turn on power while pressing the "BACK" and "ENTER" buttons. Press the "Cursor d / f " button to select the mode and the "ENTER" button to confirm the selection.

  • Page 28: Service Related Selection Mode

    3. Service Related Selection mode 3.1. Behavior specifications In this mode, you can switch between the Diagnostic mode (SERVICE CHECK), the Displaying the protection mode (PROTECTION) and the 232C clear mode (RS232C RESET). 3.2. Starting up Press the "ON/STANDBY ( X )" button to turn on power while pressing the "ZONE SELECT" and "BACK" buttons. Press the "Cursor d / f "...

  • Page 29: Dual Backup Memory

    4. DUAL BACKUP MEMORY This product has a Dual Backup Memory function. The conventional Backup functions to memorize, in the EEPROM (IC202) in the circuit, a current setting of the moment the main power is turned off so that it can be restored when it is turned ON again.
  • Page 30 Personal notes:...

  • Page 31: Diagnostic Mode (Video/Audio (Signal) Path Confirmation Mode)

    5. DIAGNOSTIC MODE (Video/Audio (signal) path confirmation mode) This mode is used for confirming the Video and Audio (signal) paths. (Troubleshooting) Confirming the operation of unit can be easily done after repair. Backup data will not be lost. 5.1. Starting diagnostic mode Press the "ZONE SELECT" and "BACK" button while simultaneously pressing those two buttons of this unit. TUNED, STEREO and RDS are lit in FL display. 5.2.
  • Page 32 Details of how to operate remote controller Output sequence of remote control codes Confirmation item Setting and display Contents of confirmation Remarks ※ It is useful to form a macro program. *b) OSD FUNCTION Video Convert(IP Scaler) : ON, All Sources 1.Press [AMP] qZONE2 POWER OFF ·OSD Display / Output : HDMI...
  • Page 33 Details of how to operate remote controller Output sequence of remote control codes Confirmation item Setting and display Contents of confirmation Remarks ※ It is useful to form a macro program. *b) HDMI (signal) Path Video Convert(IP Scaler) : OFF, All Sources 1.Press [AMP] qZONE2 POWER OFF ·Input : HDMI (ZONE2 Function) / Output : HDMI (ZONE2)
  • Page 34 Output sequence of remote control codes Confirmation item Setting and display Details of how to operate remote controller Contents of confirmation Remarks ※ It is useful to form a macro program. Amp Assign (signal) Path Amp assign : ZONE2 1.Press [AMP] qZONE2 POWER OFF ·Input : Analog / Output : Pre OUT (ZONE2 L/R) 2.Press [Z2]...
  • Page 35 Personal notes: Personal notes:...

  • Page 36: Block Diagram

    BLOCK DIAGRAM fig.1 ANALOG VIDEO BLOCK AVDM-2000 MONITOR MONITOR CBL/SAT VOUT5 CBL/SAT_V MEDIA OUT DVD_V Z2 MONITOR CVBS IN Z2 MONITOR MEDIA MEDIA_V VOUT4 DEC_CVBS_IN V.AUX(FRONT) V.AUX_V DVD_V CBL/SAT_V MEDIA_V VOUT3 Z2 MONITOR V.AUX_V DM860A CVBS COMPONENT OUT Y COMPONENT OUT PB VOUT2 MONITOR COMPONENT OUT...
  • Page 37 fig.2 HDMI VIDEO BLOCK HDMI IN WAFER WAFER ADV7850 ADV8003-2 Port D AD8195 HDMI FRT IN Buffer Port C VIDEO Port B HDMI OUT1 PROCESSING HDMI TX with TMDS HDMI OUT2 SiI9575 Port A HDMI IN1 ZONE2 HDMI OUT HDMI IN2 DEC_Y_IN TX_1 DEC_PB_IN...
  • Page 38 fig.3a ANALOG VIDEO BLOCK AVDM-2000 MONITOR MONITOR CBL/SAT VOUT5 CBL/SAT_V MEDIA OUT DVD_V Z2 MONITOR CVBS IN Z2 MONITOR MEDIA MEDIA_V VOUT4 DEC_CVBS_IN V.AUX(FRONT) V.AUX_V DVD_V CBL/SAT_V MEDIA_V VOUT3 Z2 MONITOR V.AUX_V DM860A CVBS COMPONENT OUT Y COMPONENT OUT PB VOUT2 MONITOR COMPONENT OUT...
  • Page 39 fig.3b HDMI VIDEO BLOCK HDMI IN WAFER WAFER ADV7850 ADV8003-2 Port D AD8195 HDMI FRT IN Buffer Port C VIDEO Port B HDMI OUT1 PROCESSING HDMI TX with TMDS HDMI OUT2 SiI9575 Port A HDMI IN1 ZONE2 HDMI OUT HDMI IN2 DEC_Y_IN TX_1 DEC_PB_IN...
  • Page 40 fig.4 HDMI VIDEO BLOCK HDMI IN WAFER WAFER ADV7850 ADV8003-2 Port D AD8195 HDMI FRT IN Buffer Port C VIDEO Port B HDMI OUT1 PROCESSING HDMI TX with TMDS HDMI OUT2 SiI9575 Port A HDMI IN1 ZONE2 HDMI OUT HDMI IN2 DEC_Y_IN TX_1 DEC_PB_IN...
  • Page 41 fig.5 HDMI VIDEO BLOCK HDMI IN WAFER WAFER ADV7850 ADV8003-2 Port D AD8195 HDMI FRT IN Buffer μ Port C VIDEO Port B HDMI OUT1 PROCESSING HDMI TX with TMDS HDMI OUT2 SiI9575 Port A HDMI IN1 ZONE2 HDMI OUT HDMI IN2 DEC_Y_IN TX_1...
  • Page 42 fig.6 HDMI VIDEO BLOCK HDMI IN WAFER WAFER ADV7850 ADV8003-2 Port D AD8195 HDMI FRT IN Buffer Port C μ VIDEO Port B HDMI OUT1 PROCESSING HDMI TX with TMDS HDMI OUT2 SiI9575 Port A HDMI IN1 ZONE2 HDMI OUT HDMI IN2 DEC_Y_IN TX_1...
  • Page 43 fig.7a ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 44 fig.7b DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) 256FSDIR1 AK5358BET ADINR OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR DATAF FL/FR LC89057WVF4AE DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 45 fig.8 DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) AK5358BET ADINR 256FSDIR1 OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR LC89057WVF4AE DATAF FL/FR DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 46 fig.9 HDMI VIDEO BLOCK HDMI IN WAFER WAFER ADV7850 ADV8003-2 Port D AD8195 HDMI FRT IN Buffer μ Port C VIDEO Port B HDMI OUT1 PROCESSING HDMI TX with TMDS HDMI OUT2 SiI9575 Port A HDMI IN1 ZONE2 HDMI OUT HDMI IN2 DEC_Y_IN TX_1...
  • Page 47 fig.10 ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 48 fig.11a ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 49 fig.11b DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) AK5358BET ADINR 256FSDIR1 OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR LC89057WVF4AE DATAF FL/FR DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 50 fig.12a ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 51 fig.12b DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) AK5358BET ADINR 256FSDIR1 OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR LC89057WVF4AE DATAF FL/FR DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 52 fig.13a ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 53 fig.13b DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) AK5358BET ADINR 256FSDIR1 OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR LC89057WVF4AE DATAF FL/FR DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 54 fig.14a ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 55 fig.14b DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) AK5358BET ADINR 256FSDIR1 OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR LC89057WVF4AE DATAF FL/FR DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 56 fig.15a ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 57 fig.15b DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) AK5358BET ADINR 256FSDIR1 OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR LC89057WVF4AE DATAF FL/FR DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 58 fig.19a ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 59 fig.19b DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) AK5358BET ADINR 256FSDIR1 OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR LC89057WVF4AE DATAF FL/FR DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 60 fig.20a ANALOG AUDIO BLOCK H/P OUT CURRENT FEEDBACK AMP(+6dB) EXTFL EXTFR ANA_FL DAFL TONE EXTC EXTFL EXTSW V.AUX ANAFR ADINL/R EXTSL DAFR DM860 AUDIO TONE EXTFR EXTSR Pull down EXTSBL EXTSBR EXTC Pull down Pull down DASW TUNER EXTSW CBL/SAT Pull down DASL CBL/SAT...
  • Page 61 fig.20b DIGITAL AUDIO BLOCK DIGTAL IN DATAAD. FSDIR1 ADINL 64FSDIR1 OPT1(TV) AK5358BET ADINR 256FSDIR1 OPT2(CD) DAFL COAX1(CBL/SAT) DAFR COAX2(DVD) DASW 20 17 16 DAC input DATA DASL DIR1 PCM DATA only D-LINK DASR LC89057WVF4AE DATAF FL/FR DATAC C/SW DASBL DATAS SL/SR AK4358VQ COAXOUT...
  • Page 62 AV7701 POWER BLOCK DIAGRAM 133mA +12V KTD998 S1(+12V,-12V) 133mA -12V KTB778 200mA RELAY NJM7812 (MAX RELAY ON STATE-13EA=200mA) IC700 171mA KIA7808API DA+8V (ANALOG AUDIO PART) S2 + 404mA IC936 183mA DA+5V (ANALOG AUDIO PART) KIA7805BPI S2(+8V,-8V) S2 - 171mA 50mA IC931 +3.3V (ETHERNET DAC)

  • Page 63: Jig For Servicing

    JIG FOR SERVICING When you repair the printing board, you can use the following JIG (Extension cable kit). Please order it from Marantz Official Service. Distributor in your region if necessary. NOTE: The incorrect connection with in the JIG (EXTENSION UNIT KIT) may cause damage. 8U-110084S : EXTENSION UNIT KIT : 2 Set •...
  • Page 64 (2) Disconnect the connector board. Board to board Board to board PCB HDMI Board to board Board to board PCB VIDEO SUPPORT PCB Board to board Board to board PCB INPUT...
  • Page 65 (3) Detach PCB HDMI from the chassis, and turn it over. Please put an insulation sheet that is larger than PCB HDMI under PCB. b Connect the ground point of PCB to the chassis with a ground lead or the like. VIDEO PCB HDMI PCB SPK_PREOUT PCB...
  • Page 66 Insulation sheet PCB INPUT Connection table of Board to Board Ref. No. Ref. No. 19pin CN27A SIDE CNT CN27B HDMI 11pin CN28A SIDE CNT CN28B HDMI 27pin CN24A FRONT CNT CN24B HDMI 11pin CN26A FRONT CNT CN26B HDMI 17pin CN25A FRONT CNT CN25B HDMI...

  • Page 67: When The Microprocessor Is Replaced With Anew One

    WHEN THE MICROPROCESSOR IS REPLACED WITH A NEW ONE When the U-PRO (Microprocessor) or the Flash ROM is replaced, confirm the following. After PWB Name Ref. No. Description Remark replaced HDMI IC201 R5F56108VNFP SOFTWARE: Main HDMI IC231 R5F3650KNFB SOFTWARE: Sub HDMI IC410 MX29LV160DBTI-70G SOFTWARE: DSP ROM HDMI IC406 EPM240T100C5N SOFTWARE: Audio PLD HDMI IC155 MX25L6406EM2I-12G...
  • Page 68 1.4. Run the DFW Run the "DFW_0017_AV7701_(Rev.X.X.X).exe" on desktop of PC. 1.5. Communication check (1) Select the serial port number of RS-232C in PC. (2) Click the "Check Comm." button. (3) When connection is good, then you can see the "Communication check OK." message. (4) If connection is not good, then you can see the "Communication check NG"...
  • Page 69 1.6. Download the firmware (1) Click the "Load" button. (2) Download the firmware from the specified download source to PC. XXX-XXXX XXX-XXXX_WWWXXXXYYYY-ZZZZ.bin XXX-XXXX_WWWXXXXYYYY-ZZZZ.bin...
  • Page 70 1.7. Complete the firmware updating (1) Click the "Update" button. XXXXXXXX XXXXXXX (2) W hen writing of the firmware is completed, the power of AV receiver turns on automatically and you can see the "Update completed" message. (3) I f you can’t complete the firmware update, please retry the firmware update from "1.3. Turn on the AV receiver". 1.8. Notice: Please keep the following notice for firmware update. (a) Keep the PC environment (b) Avoid the communication cable from the electrical noise source. (e.g. telephone cable, AC line, a fluorescent light) (c) Don’t remove cable during update.

  • Page 71: How To Update By Dpms

    Even with a broadband connection to the Internet, approximately 1 hour is required for the updating procedure to be completed. Once updating starts, normal operations on the AV7701 cannot be performed until updating is completed. Also, setting items of the GUI menu of AV7701 or setting items of the image adjustment may be initialized.
  • Page 72 2.3. About the error code See the table below for error codes, details of faults, and coping strategies when the firmware is updated through DPMS (Marantz Product Management Server). Error Details of Error code Display Coping strategies Code Reset and update again. L o g i n f a i l e d Log-in to DPMS has failed. Carry out the update in an environment that has little network load.
  • Page 73 Error Details of Error code Display Coping strategies Code Main CPU failed to receive firmware Turn off and on the power. Updating M a i n * * * m i n for rewriting sent from DM860A starts automatically. (when an error occurred) U p d a t i n g f a i l There was invalid data in the firmware for rewriting sent from...
  • Page 74 Error Details of Error code Display Coping strategies Code Connection to DPMS timed out Check the network connection. C o n n e c t i o n f a i l when firmware such as Sub CPU, Carry out the update in an environment DSP, FPGA, and PLD was rewritten.
  • Page 75 Error Details of Error code Display Coping strategies Code NACK was received when "L" S u b * * * m i n Turn off and on the power. Updating command sent to Sub CPU, DSP, starts automatically. U p d a t i n g f a i l PLD etc.
  • Page 76 Error Details of Error code Display Coping strategies Code Acquisition of (Application Mode) Check the network connection. E t h e r I M G * * * m i n IP address failed before rewriting Carry out the update in an environment DM860A was rewritten (when timed C o n n e c t i o n F a i l A 1 that has little network load.
  • Page 77 Device display during firmware update Target of device when firmware updated. Target of device Display Error cpde 08~0C M a i n * * * m i n 10~15 Main 22~24 U p d a t i n g * * % 36~3E 50~52 S u b * * * m i n 54~58 U p d a t i n g...

  • Page 78: How To Update By Usb Memory

    Place the USB update File in an appropriate folder. The folder name should be the Product ID based on the Model name/area. Model Name Model Area Product ID North America (U) 100100170100 AV7701 Europe (N) 100100170200 China (K) 100100170500 (2) Setting Download firmware onto USB memory.
  • Page 79 3.3. About the error code See the table below for error codes and details of faults when the firmware is updated through USB memory. Error Details of Error code Display Coping strategies Code Disconnect and connect the USB Unable to detect USB. C o n n e c t i o n F a i l 0 1 memory.
  • Page 80 Error Details of Error code Display Coping strategies Code No FirmwareFile in USB after Disconnect and connect the USB F i l e s N o t F o u n d SBLMode. memory. FirmwareFile in USB after SBLMode Check the supported Model name/area N o t M a t c h F i r m for unsupported Model name/area for the FirmwareFile.
  • Page 81 Error Details of Error code Display Coping strategies Code This unit automatically retries several times. Wait until the FL display stops. No FirmwareFile in USB. If the FL display stops at the Error F i l e s N o t F o u n d display, press and hold the "ON/ STANDBY ( X )" button for five seconds.
  • Page 82 Error Details of Error code Display Coping strategies Code This unit automatically retries several Mismatched CheckSum in response times. Wait until the FL display stops. or no response from Sub for I If the FL display stops at the Error U p d a t e C h e c k N G command.
  • Page 83 Error Details of Error code Display Coping strategies Code This unit automatically retries several times. Wait until the FL display stops. Error notification received while If the FL display stops at the Error U p d a t i n g f a i l requesting FirmwareInfo.
  • Page 84 3.4. Device display during firmware update Display of target device during firmware update. Target of device Display Error cpde 08~0C M a i n * * * m i n 10~15 Main 22~24 U p d a t i n g * * % 36~3E 50~52 S u b * * * m i n 54~58...

  • Page 85: Surround Modes And Parameters

    SURROUND MODES AND PARAMETERS...

  • Page 91: Trouble Shooting

    TROUBLE SHOOTING 1. POWER 1.1. Power not turn on Power not turn on. Is the fuse blown? Refer to 1.2.Fuse is blown. To troubleshooting Is a DC 5V voltage output 6. SMPS. Is a DC 5V voltage being when the cord supplying the (Refer to 110 supplied from the SMPS B'D power from the SMPS B'D...

  • Page 92: Analog Video

    2. Analog video Perform the operation below beforehand. b Check that the connection cable and the Monitor are normal. b Set VIDEO CONVERT ON. b Set COMPONENT signal to 480i. b Set Function to the following. V : SAT COMPONENT : SAT MONITOR OUT (CVBS/Cmponent/HDMI) output NG Input Input...
  • Page 93 Input CVBS,COMPONENT Is the power supply voltage REGULATOR B'D flaw. correctly output? VIDEO B'D and REGULATOR V+5V : CN52B-6pin B'D and connection of the wire V-5V : CN52B-8pin are defective. (SIDE_CNT B'D) Check on set value of each IC. Is they the following voltage values? VSDA : T10 HDMI B'D flaw.
  • Page 94 VIDEO B'D flaw. Extend HDMI B'D using a jig. Is the signal input to IC511(AVDM-2000)? : J5004 The parts between IC511 is COMPONENT(Y) : J5010 defective. COMPONENT(Cb) : J5007 COMPONENT(Cr) : J5040 (VIDEO B'D) Is the signal output from IC511(AVDM-2000)? To Moitor To HDMI out J5003 CN51B 11pin...
  • Page 95 HDMI test point D5002 R5082 R5081 DATA D5003 JK401 JK402 JK403 T192 JK152 R4043 T193 D5001 JK505 JK504 JK503 JK502 JK501 J3200 R4042 D4001 JK151 JK507 R5083 JK506 C4030 R4040 JK404 D5015 R4044 D1615 D1616 D1619 D1620 T501 R4007 R5004 D1603 D1604 D1607 D1608...
  • Page 96 VIDEO test point BK502 BK501 JK521 JK532 JK531 JK522 JK523 JK513 JK511 J5141 JK512 J5140 C5236 J5112 J5139 J5124 C5334 C5336 J5114 J5113 J5131 R5359 J5116 J5132 J5118 J5003 C5333 C5335 J5115 J5119 J5002 J5106 J5126 CN53B J5004 J5016 J5117 J5005 J5107 J5103...

  • Page 97: Hdmi/Dvi

    (6) Is the BD/DVD player's HDMI output setting correct? the BD/DVD player operating instructions. (7) W hen you use a marantz BD/DVD player, is the fluorescent display tube's "HDMI" indicator lit? If you use a non-marantz BD/ DVD player, proceed to "YES". (8) Are the picture and sound output...
  • Page 98 Check TV Use an HDCP-compatible TV. PC TVs cannot (11) Is the TV HDCP-compatible? be used. If the TV is not compatible with resolutions of (12) Is the TV compatible with resolutions of 1080P? 1080P, no picture will be output, even if the BD/DVD player resolution is set to 1080P.
  • Page 99 The BD/DVD player does not recognize the connection with the (18) set. When using a (19) The pattern and marantz BD/DVD Is the "H"(3V-5V) signal outputted of HDMI connector (JK101/JK501- circuit from the player, is the FL JK506 : TP[HPD])? HDMI connector display's "HDMI"...
  • Page 100 (27) Check xtal oscillator. The X1201 or IC121 is defective. Is oscillation of X1201(27MHz) transmitted? (28) Check RESET. The RESET circuitry or IC121 is defective. Is RESET waveform confirmed in TP[7850_RESET], when power is turned on? (If not reference waveform, proceed to "NO".) Check operation of IC151(ADV8003). (29) Check power supply.
  • Page 101 3.2. HDMI test point and waveforms D5002 R5082 R5081 DATA D5003 JK401 JK402 JK403 T192 JK152 R4043 T193 D5001 JK505 JK504 JK503 JK502 JK501 J3200 R4042 JK151 JK507 R5083 JK506 D4001 C4030 R4040 JK404 D5015 R4044 T501 R4007 D1615 D1616 D1619 D1620 R5004...
  • Page 102 Detail C 9575_RESET D5083 D5081 D5079 D5077 D5071 D5069 D5067 D5065 IC501 9575_RST L5008 R5084 R5085 Q5012 R5117 R5118 A: 5V 101 pin B: 3.3V 19,38,56,112,123,173 pin C: 1.3V 18,36,37,55,65,111,116,139,140,141,150,151,160 pin RN507 :TMDS_OUTPUT 142,143,144,145,146,147,148,149,152,153, TMDS_OUTPUT 154,155,156,157,158,159 pin RN506 RN505 RN502 RN504 RN503 X5001...
  • Page 103 DDC_CLK/DDC_DATA/TMDS : Check items HDMI to HDMI (17)/(19)/(25)/(33)/(34) 0.9V 2.48V DDC_CLK DDC_DATA Timing waveform illustration from the start of CEC3.3V to when reset is released : Check items (23) CEC3.3V 338ms Sil9575_RESET...
  • Page 104 Controlled waveform (I2C), when power is turned on : Check items (24)/(32) Zoom Power ON Timing waveform illustration from the start of CEC3.3V to when reset is released : Check items (28) CEC3.3V 338ms 7850_RESET Timing waveform illustration from the start of CEC3.3V to when reset is released : Check items (31) DV3.3V 314ms 10ms...

  • Page 105: Audio

    4. AUDIO 4.1. AUDIO CHECK Audio output NG. Refer to "Audio Check PATH" (117 page). CHECK1 INPUT SURROND MODE SOURCE Check ANALOG audio BLOCK. Audio output OK? ANALOG 2CH DIRECT ANALOG CHECK2 INPUT SURROND MODE SOURCE Check Digital audio BLOCK. Legacy Audio output OK? COAX or OPT...
  • Page 106 4.2. Analog audio No sound is output Is the voltage of ±8V supplied to The power supply of ±8V is repaired. SIDE CNT B'D CN41A 4-7pin? Is the audio signal transmitted to The HDAM amplifier is repaired. INPUT B'D CN461? Connect the connectors properly. Is the serial data for electronic volume Is the connector correctly connected transmitted to FRONT CNT B'D...

  • Page 107: Network/Usb

    5. Network/USB 5.1. Cannot connect to network Checking the environment Check the LAN cable properly then turn the Is the LAN cable properly connected? power back on. Checking the settings Set the IP address and other parameters properly. For a fixed IP setting, check Are the AV RECEIVER's network settings correct? whether the IP address is redundant with that of other devices, and check whether the subnet mask setting is correct.
  • Page 108 5.2. USB device is not recognized Checking the USB device Are you using a USB hub? Don't use the USB hub. Only mass storage devices in FAT16 or FAT32 formats or MTPcompatible devices Is the USB device compatible with the set? and iPod (Remove some models) are supported.
  • Page 109 HDMI test point D5002 R5082 R5081 DATA D5003 JK401 JK402 JK403 T192 JK152 R4043 T193 D5001 JK505 JK504 JK503 JK502 JK501 J3200 JK151 JK506 R4042 D4001 JK507 R5083 C4030 R4040 D5015 JK404 R4044 T501 R4007 D1615 D1616 D1619 D1620 R5004 R1639 D1603 D1604 D1607...

  • Page 110: Smps

    6. SMPS DC 5V is not output. Is there damage in IC901 Replace the IC901(TOP258MG) and (TOP258MG)? D9001/D9002/D9003/D9004. Is there the damage in D9001/D9002/ Is the fuse (F9001) blown? Replace the parts of damage. D9003/D9004/C9004? Is there solder short circuit in the PWB The solder short part of the PWB board board? is repaired.
  • Page 111 Operation waveform for each part After primary side rectification (Caution: High voltage, electric shock) Primary drain (Caution: High voltage, electric shock) C9002 0.01uF 250V 1N4007 D9001 D9002 1N4007 D9003 1N4007 After secondary rectifications LF902 1N4007 D9004 LF-4ZB-E273H 1N4007 D9005 D9006 1N4007 R9002 R9003...
  • Page 112 Personal notes:...
  • Page 113 Refer to troubleshooting "4.1. AUDIO CHECK"(00 page). HDMI CHECK6 TRANSMITTER ADV8003 CHECK5 with scaler video encoder etc... Sil9575 ADV7850 FRONT TMDS BUFFER AD8195 CHECK4 EPM240T100C5N CHECK2 SPDIF/I2S SELECTOR LAN8720A SPDIF LC89057W-VF4A-E DIGITAL AUDIO INTERFACE RECEIVER for AV7701 CHECK3 PREOUT +6dB CHECK1 R2A15220FP 7.1ch IN...

  • Page 114: Clock Flow & Wave Form In Digital Block

    CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK WAVE FORM MSLK_OUT RXMCK Audio PLD input SCLK_OUT RX64FS IC121 AP5_OUT RXFS ADV7850 AP1_OUT RXI2S0 HDMI Receiver AP2_OUT RXI2S1 AP3_OUT RXI2S2 CH1:C1 AP4_OUT RXI2S3 AP0_OUT RXSPDIF IC406 RXSPDIF MCLK DAC256FS EPM240T100C5N DAC64F BICK Audio PLD COAXIAL1...

  • Page 115: Level Diagram

    LEVEL DIAGRAM LEVEL DIAGRAM FRONT ch RCA PREOUT ･ ･ ･ ･ ① ③ ④ ⑤ ① ③ ④ ⑤...
  • Page 116 LEVEL DIAGRAM CENTER ch RCA PREOUT ･ ･ ① ② ③ ① ② ③...
  • Page 117 LEVEL DIAGRAM SUBWOOFER ch ･ ･ ① ② ③ ④ ① ② ③ ④...
  • Page 118 LEVEL DIAGRAM SURROUND ch RCA PREOUT ･ ･ ① ② ① ② ③...
  • Page 119 LEVEL DIAGRAM SURR.BACK ch RCA PREOUT ･ ･ ① ② ③ ① ② ③ ④...

  • Page 120: Wiring Diagram

    WIRING DIAGRAM CN321 DIGITAL B'D (CJP05GA208ZY) 20022WS-05C CUP12440Z BLANCE OUT B'D INLET CUP12486Z-3 CN902 CN903 (CJP02GA89ZY) (CJP05GI289ZY) AC IN WAFER/SMW250-05P WAFER/YW396-03B,7.92mm pitch BN705 BN704 FRONT CNT. B'D VIDEO B'D (CJP15GJ288ZY) (CJP13GJ288ZY) WAFER/SMW250-15P WAFER/SMW250-13P CUP12439Z CUP12444Z-2 BN903 BN461 (CWB7D0054003D001) (CWB1B013300HC) BN492 WIRE, 13P,2.0mm, 300MM WIRE,5P,2.5mm UL1007#26...

  • Page 121: Printed Wiring Boards

    PRINTED WIRING BOARDS HDAM_AMP _1 (COMPONENT SIDE) CUP12486-1 C7127 BAR CODE LABEL BK706 C7144 C7129 C7133 C7119 IC718 R7016 R7011 R7305 C7139 R7167 C7124 Q7002 R7382 RY711 CN701 1.SW C7128 Q7003 Q7029 Q7004 R7372 2.AGND IC701 C7130 C7132 C7120 Q7039 3.AGND Q7038 Q7040...

  • Page 122: Smps

    SMPS (COMPONENT SIDE) 2.2 X 1.2 C M D 1A 629 2.2 X 1.2 BK 903 5600uF/ 6. 3V 5600uF/ 6. 3V I C 903 C 9023 C 9021 D 9012 1.2 X 3.1 R 9019 SMPS B'D ADJ 1 ADJ 2 R 9018 R Y 901...

  • Page 123: Hdam_Amp _2

    HDAM_AMP _2 HDAM_AMP _3 (COMPONENT SIDE) (COMPONENT SIDE) BK704 C7125 BK705 C7121 JW704 CN702 RG735 RG734 C7123 C7103 C7190 JW703 1.HP_L R7379 2.HP_GND 3.HP_R 4.RELAY_H 5.HP_RL 6.RELAY_FB 7.RELAY_SB 8.RELAY_S 9.RELAY_C_SW 10.RELAY_F BAR CODE LABEL 11.RELAY_W JW705 1.FHL JW702 2.AGND JW707 3.FHR 4.AGND ADJ1...

  • Page 124: Fuse

    FUSE FUSE (COMPONENT SIDE) (FOIL SIDE) CUP12442Z-3 D9319 D9321 D9320 D9322 J7117 J7118 D9326 D9330 D9325 D9329 D9317 D9328 D9331 D9318 D9314 D9327 D9332 D9312 C9318 C9319 J7103 J7104 C9317 J7101 J7102 BK931 C9322 C9323 J7115 J7116 CN940 CN941 鉛フリー半田 半田付けには、鉛フリー半田...

  • Page 125: Input

    INPUT (COMPONENT SIDE) JK463 JK465 C4647 C4648 C4643 C4644 JK464 C4627 C4628 C4617 C4618 JK462 C4613 C4614 JK461 C4637 C4638 C4607 C4608 C4603 C4604 C4634 C4633 R4643 R4644 R4647 R4648 R4637 R4638 R4627 R4628 R4617 R4618 R4607 R4608 R4603 R4604 R4613 R4614 R4633...
  • Page 126 INPUT (FOIL SIDE) C4661 R4665 R4666 CN45B REC_L R4751 1.REC_L R4757 2.AGND 3.REC_R REC_R C4665 C4666 4.AGND R4752 CN44B 5.ZONE2L R4758 6.AGND R4756 1.FL 7.ZONE2_R Z2_L 2.AGND 8.AGND 3.FR 9.ZONE3_L 4.AGND 10.AGND R4737 11.ZONE3_R 6.AGND R4731 7.SW1 R4738 8.AGND Z3_L 9.SL 10.AGND Z3_R...

  • Page 127: Front

    FRONT (COMPONENT SIDE) D6029 J6004 J6143 J6015 CN602 FL5V 1.FLAC(6.1V) LUG61 CN69A J6003 2.NC J6016 BK601 3.FLAC(6.1V) J6006 4.NC J6017 C6008 5.D/M GND J6018 6.NC BK604 J6036 J6002 7.VKKAC D6026 D6027 J6021 J6147 J6098 J6001 J6137 J6099 J6136 J6037 J6005 J6135 D6033 J6100...
  • Page 128 FRONT (FOIL SIDE) 1.FLAC(6.1V) 2.NC FL5V 3.FLAC(6.1V) 4.NC 5.D/M GND IC603 6.NC 7.VKKAC C6099 FIL_CTRL M3.3V FL_CE2 FLRST Q6081 KEY3 R6718 FL_CE1 FL_CLK CUP12433-1 FL_DATA H/PDET MICDET GRNLED REDLED 1.DGND 2.H/PDET 3.H/PR 4.H/PGND 5.H/PL DA+8V DA-8V M.DAX PURE DOWN BACK SETUP ZONE SEL.

  • Page 129: Door Det

    GUIDE L GUIDE L (COMPONENT SIDE) (FOIL SIDE) (COMPONENT SIDE) (FOIL SIDE) 5.H/PL 4.H/PGND 3.H/PR 2.H/PDET 1.DGND J6145 CUP12433-2 JK605 C6514 C6511 LUG65 CUP12433-6 CUP12433-6 DOOR DET DOOR DET (COMPONENT SIDE) (FOIL SIDE) GUIDE R GUIDE R (COMPONENT SIDE) (FOIL SIDE) BN608B S6024 CUP12433-3...

  • Page 130: Preout

    PREOUT PREOUT (COMPONENT SIDE) (FOIL SIDE) C6820 C6877 C6745 C6782 C6096 C6904 D6731 D6896 D6895 D6838 D6837 D6868 D6867 D6712 D6711 D6732 D6762 D6761 D6782 D6781 C6903 D6807 C6902 C6901 R6750 Q6767 Q6768 Q6737 Q6738 Q6717 Q6718 Q6873 Q6874 Q6843 Q6844 Q6812 Q6787...

  • Page 131: Side Cnt

    SIDE CNT SIDE CNT (COMPONENT SIDE) (FOIL SIDE) CN28A CN27A CNT_CUP12444Z_A_2(MP) DIP IN 1.REMOTE3.3V J9611 2.232I_MO 1.REMOTE3.3V 3.232O_MI J9612 2.232I_MO 4.DGND R9608 3.232O_MI C9610 4.DGND J9613 IC961 J9605 C9616 CN962 J9607 J9606 J9608 C9615 J9609 C9609 R9607 CN53A CN52A J9610 R9644 CN961 J9614...

  • Page 132: Front Cnt

    FRONT CNT (COMPONENT SIDE) CN29A CN21A CN24A CN26A CN25A J9603 BAR CODE LABEL CNT_CUP12444Z_A_1(MP) CN54A CN51A DIP OUT ADJ1 ADJ2 JW902 CN42A CN43A CN63B 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 133 FRONT CNT (FOIL SIDE) 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).

  • Page 134: Video

    VIDEO (COMPONENT SIDE) BK502 BK501 JK521 JK532 JK531 JK523 JK511 JK522 JK513 JK512 J5141 J5140 C5236 J5139 J5112 J5124 C5334 C5336 J5114 J5113 J5131 R5359 J5116 J5132 J5118 J5003 C5333 C5335 J5115 J5119 J5002 J5106 J5126 CN53B J5004 J5016 J5117 J5005 J5103 J5107...
  • Page 135 VIDEO (FOIL SIDE) D5252 D5253 C5252 C5253 C5214 C5224 D5251 D5232 D5231 R5253 C5238 C5239 Q5252 C5126 C5136 C5125 C5124 C5134 C5143 C5135 C5155 C5141 C5154 R5254 R5136 R5124 R5126 R5122 R5132 R5143 IC521 R5134 R5141 R5152 R5154 C5321 C5142 Q5251 C5102 C5101...

  • Page 136: Hdmi

    HDMI (COMPONENT SIDE) D5002 R5082 R5081 D5003 DATA JK401 JK402 JK403 T192 JK152 R4043 T193 D5001 JK505 JK504 JK503 JK502 JK501 J3200 R4042 D4001 JK151 JK507 R5083 JK506 C4030 R4040 JK404 D5015 R4044 D1615 D1616 D1619 D1620 T501 R4007 R5004 R1639 D1603 D1604 D1607...
  • Page 137 HDMI (FOIL SIDE) R5057 C5012 R1621 R1620 R5017 R5028 R5035 R5048 R5058 R1696 IC157 L1518 D1501 R1695 Q1508 C5013 R1629 C1694 R5009 R1631 L1519 C1704 R5061 C5066 R1630 R1623 R5064 L1520 C1696 R1617 C5043 R1625 C5031 C5042 C5065 R1632 R5091 R1626 R1633 R1624...

  • Page 138: Schematic Diagrams (1/31)

    TO CN69B PAGE 13_B1 AV7701 TO DIGITAL CON. CN69A FRONT B'D VOLUME & REMOTE PART CN69A C6918 OPEN C6917 OPEN C6916 LUG61 OPEN IC603 C6915 OPEN FL602 CHASSIS NJM2887 C6914 OPEN GP1261AI C6913 OPEN C6912 OPEN R6354 R6353 C6911 OPEN 4.7K...

  • Page 139: Spk/Preout/Reg Unit (1/3)

    PREOUT PART 1N4007ST D6845 D6846 1N4007ST R6846 R6849 D6847 1N4007ST C6849 10/50V R6791 R6854 OPEN R6829 R6831 R6837 OPEN R6813 C6829 C6833 P_PREZ2L Q6841 22/50V 22/50V R6841 R6843 OPEN C6813 Q6843 JK681 OPEN R6840 R6845 470K Q6844 R6842 Q6842 OPEN R6844 Q6846 CN62A...

  • Page 140: Spk/Preout/Reg Unit (2/3)

    R6925 • • • • • • • • • • •• • • • • • • •• • • • • •• • •• • • • • • • TUNER PART • • • • • • • •• • •• •...

  • Page 141: Spk/Preout/Reg Unit (3/3)

    CURRENT FB PART R5646 R5645 R5643 R5746 R5745 R5743 R5644 R5744 R5641 R5741 Q5729 Q5629 OPEN R5721 R5621 Q5721 Q5621 R5703 2SC3324BL OPEN R5603 2SC3324BL 2SC3324BL 2SC3324BL C5701 C5601 Q5723 R5740 Q5623 R5640 2SA1312BL 2SA1312BL 10/50V 10/50V R5720 R5727 R5620 R5627 R5728 R5628...

  • Page 142: Cnt/Rs232C Unit (1/2)

    SIDE CNT_CUP12444Z(CONNECT A) TO CN27B FROM DIGITAL CON.PART (PAGE 13_C1) FROM DIGITAL CON.PART (PAGE 13_D1) CN28A CN27A CN27A CN28A C125Z1-21 C125Z1-11 AV7701 USA VER. ONLY IC961 PQ033DNA1ZPH Specific IC R9601 R9607 C9615 10/50V C9602 C9609 10/50V TO HD RADIO KRMAVR2011...

  • Page 143: Cnt/Rs232C Unit (2/2)

    FRT CNT_CUP12444Z(CONNECT B) FROM/TO DIGITAL CON. PART (PAGE 13) (PAGE 13_B5) (PAGE 13_C3) (PAGE 13_B3) (PAGE 13_D3) TO CN21B TO CN25B TO CN26B TO CN24B C125Z1-27 CN25A C125Z1-11 CN21A CN24A CN29A CN25A CN21A CN26A CN24A CN26A C125Z1-11 C125Z1-17 C125Z1-15 CN54A CN51A C125Z1-11 C125Z1-15...

  • Page 144: Input Unit

    MEDIA_REC_L C4629 220/16V 0.022u 6800P OPEN PREGND ELNA/RA3 MEDIA_REC_R REC_R PREGND R4629 OPTION "A" AV7701 N/K = 4.7kohm ZONE2_L ZONE2_L R4630 AV7701 U/F = 0ohm PREGND ZONE2_R ZONE2_R OPTION "B" AV7701 N/K = USE R4807 R4809 AV7701 U/F = OPEN...

  • Page 145: Video Unit (1/3)

    VIDEO+5V VGND VIDEO-5V ANALOG VDIEO PART IC513 NJM2845DL133 +3.3V CVBS IN/ O UT C5107 CBL/SAT SAT_CVBS_IN 10/50V C5108 DVD_CVBS_IN 10/50V R5183 DEC_CVBS_IN C5109 R5184 MEDIA PLAYER DEC_Y_IN MEDIA_CVBS_IN 10/50V R5185 DEC_PB_IN R5186 MONITOR DEC_PR_IN R5187 75(1%) MON_COMP_CR_OUT R5111 75(1%) R5188 75(1%) R5112 4.7K...

  • Page 146: Video Unit (2/3)

    RC-5 / MX-PORT R5311 R5312 Q5313 RT1P141C SWM5V Q5312 M3.3V RT1N141C DGND D5311 DA+8V OPEN DA-8V RC_IN R5313 KILLIR_MZ RC_OUT_MZ BTLINK_MZ FRONT_IRIN JK531 RCA-207AE-07 REMOTE3.3V 232O_MI R5314 232I_MO TRIGGER_1 TRIGGER_2 Q5315 B/P_IRIN_DE 2SC3052 TRIGGER_3 TRIGGER_4 TRIGGER_4 TRIGGER_3 B/P_IRIN_DE +5VL TRG+15V TGR_GND Q5316 RT1N141C...

  • Page 147: Video Unit (3/3)

    IR / FLASHER RS232C/TRIGGER BK501 OPEN IC521 ILX3232D C5237 C5236 0.1uF 10/50V C5231 C5235 0.1uF 0.1uF OPEN DGND D5231 OPEN T1_O R5234 Q5251 RT1P141C RS-232C R1_I R5233 PJ-308-02 C5233 R1_O D5232 OPEN Q5252 0.1uF JK521 2SC3052 C5234 T1_I D227FD009S100BY/YUQIU DGND 0.1uF T2_I R5232...

  • Page 148: Digital Unit (1/15)

    TO N PAGE 14_B1 TO DIGITAL SUPPLY L2903 DA+5V DA+8V CN24B DA-8V CN24B CJP27HJ282Z C125Z2-27 CN27B DAGND CN27B ADINL ADINL CJP19HJ282Z DAGND C125Z2-19 ADINR ADINR DAGND DAFL SWM5V DAFL DAGND DAFR M3.3V DAFR DAGND DGND DA+8V DAGND DA-8V DASW RC_IN DASW DAGND KILLIR_MZ...

  • Page 149: Digital Unit (2/15)

    L3019 DGND BLM21PG221SN1 L3020 BLM21PG221SN1 D5.2V L3021 C3003 C3004 22/10V BLM21PG221SN1 D5.2V 10/6.3 DGND DV1.8V DGND 2.6A MAINPOWER VOUT L3022 L3001 PVIN L3003 DC/DC CONVERTER VOUT BLM21AG121SN1 PVIN CN903 IC301 CN903 C3058 L3002 L3004 C3065 22/10V CJP05GI289ZY EX3AV SMW250-05 NC(SW) 10/6.3V NC(SW) DV3.3V...

  • Page 150: Digital Unit (3/15)

    PLDAERR R2136 PLDAERR CPUPOWER P56/NC E_SPIMOEI R2018 OPEN R2135 OPEN P57/NC C2012 R2134 OPEN R2133 OPEN EEPROM PART AV7701 VERSION OPTION 4.7K R2132 EEPROM SCL R2155 R2060 R2061 R2131 EEPROM SDA R2156 4.7K MICDET VER. k§Ù k§Ù R2130 H/PDET ADV8003_SPI_CS...

  • Page 151: Digital Unit (4/15)

    PAGE 27 PAGE 24 PAGE 25 HDMI_TX(ADV8003) HDMI_RX+VIDEO_DEC HDMI SWITCH SCPU5V DGND R2335 OPEN SCPU3.3V R2337 OPEN SUBBDOWN R2336 OPEN SUBBDOWN CEC_POWER R2340 4.7K CEC_POWER R2341 4.7K DV_POWER2 DV_POWER2 R2342 4.7K DV_POWER1 DV_POWER1 DA_POWER DA_POWER T242 T241 T240 PLDAERR MPLDCLK MPLDCLK MPLDDATA MPLDDATA...

  • Page 152: Digital Unit (5/15)

    TO AA PAGE 13_A4 TO DIGITAL CONNECT TO AI PAGE 14_B1 TO DIGITAL SUPPLY POWER DETECT TO BN203 CN203 CN203 CJP03GA208ZY 20022WS-03C R2402 4.7K DGND T186 T185 T187 Q2403 Q2406 Q2401 2SC3052 2SC3052 RT1N141C Q2402 Q2415 Q2418 Q2407 Q2408 Q2411 Q2414 T188 T189...

  • Page 153: Digital Unit (6/15)

    DIRRST1 DIRCLK DIRCE DIRDIN DIRDOUT DL5_SPDIF 24.576MHz DL5_FS X4001 DL5_64FS DL5_256FS ZONE1 DIR1PERR AUDIO1 R4034 R4033 256_1 R4036 3.3K SDIN DATAAD R4037 SLRCK RN403 SLRCK1 SBCK 33 X 2 OPEN SBCK1 RDATA DATADIR1 R4042 R4038 XMODE RLRCK RN402 IC403 FSDIR1 DGND DVDD 33 X 2...

  • Page 154: Digital Unit (7/15)

    FROM DM860 TO SUB CPU PAGE 23_E2 PAGE 17_B1 TO BV ADV7850_INT2 ADV7850_INT2 RXMCK RXMCK RX64FS RX64FS RXFS RXFS RXI2S0 RXI2S0 RXI2S1 BD401 RXI2S1 HCB2012KF-221T25 RXI2S2 RXI2S2 RXI2S3 RXI2S3 C4061 open RXSPDIF RXSPDIF C4062 5 6 7 8 5 6 7 8 IC407 CS210010-CZZR TXMCK...

  • Page 155: Digital Unit (8/15)

    PAGE 20_E3 PAGE 20_E3 PAGE 20_E4 FROM PLD PART TO BI TO PLD PART FROM PLD PART PAGE 17_C1 FROM SCPU PART DSP_CONT 5 6 7 8 5 6 7 8 1 2 3 4 1 2 3 4 R4153 OPEN R4152 DSP_FLAG0...

  • Page 156: Digital Unit (9/15)

    TO CA TO BM PAGE 20_E5 PAGE 17_E1 TO SUB CPU TO AUDIO PLD R4517 open open R4518 DA+5V DA-8V DA+8V D_AUDIO ADINL ADINR DAGND C4491 C4492 C4493 1000P C4494 1000P C4495 OPEN R4417 OPEN C4496 OPEN C4497 1000P R4421 4.7K C4498 1000P...

  • Page 157: Digital Unit (10/15)

    MP:open CN390 CJP07GA193ZY 10022H-07C R3900 open DGND DEBUG_RX DEBUG_RX R3902 33X4 DEBUG_TX DEBUG_TX ETDO NET3.3V 3.3V ETDI ETCK R3961 ETMS DM_D0 33X4 DM_D1 DEBUG_TX DM_D2 DGND DEBUG_RX DM_D3 ETMS E_TXDMOEI ETMS R3962 E4 NC_01 F4 NC_02 DM_D4 E_RXDMIEO G4 NC_03 33X4 ETCK ETCK...

  • Page 158: Digital Unit (11/15)

    VDDD1 VDDA2 SAA7121H/V2.518 R3239 TO HDMI_RX+VIDEO_DEC C3222 RCV1 RCV2 PAGE 24_A6 C3245 VDDA1 L3214 R3240 ETHER_SC TO CH R3284 AV7701 L3213,L3214 C3253,C3255 R3285 R3286 E3/U (USA) 0ohm 1000pF R3289 E2/N (EUR) 1.5uH 330pF E1C/K (CHINA) 1.5uH 330pF K/FB (JAPAN) 0ohm...

  • Page 159: Digital Unit (12/15)

    TO CY PAGE 16_D5 FROM SCPU TO AQ PAGE 14_B3 FROM DIGITAL SUPPLY POWER CN121 CN121 LAND1 CJP23GA193ZY 10022H-23C R1260 CEC_COM1 DDCD_SDA DDCD_SDA DDCD_SCL DDCD_SCL TXEN HPA_D HPA_D CEC_COM1 RXD_5V R1207 R1208 RXD_5V CEC5V CEC3.3V CEC3.3V CEC3.3V L1208 L1209 L1205 DGND T239 BLM21PG221SN1...

  • Page 160: Digital Unit (13/15)

    R5111 Q5001 OPEN Q5002 OPEN R5007 R5002 JK501 19.HP DET CJJ9H014Z OPEN 18.+5V AD3PBI19G0 C5001 R5003 17.GND 16.DDC DATA HPD0 OPEN OPEN CEC3.3V 15.DDC CLK R0PWR5V L5009 14.NC L5010 L5001 13.CEC DSCL0 CEC1.3V DSDA0 12.CK- HCB1608KF-600T30 HCB1608KF-600T30 HCB1608KF-600T30 11.D1 SHIELD R0XC- 10.CK+ 9.D0-...

  • Page 161: Digital Unit (14/15)

    R1002 Q1001 OPEN Q1002 OPEN R1003 JK101 OPEN AD3PBJI19G0 C1001 R1004 19.HP DET OPEN OPEN 18.+5V 17.GND 16.DDC DATA 15.DDC CLK CEC5V 14.NC L1001 13.CEC CN101 12.CK- 11.D1 SHIELD CN101 CJP23GA193ZY 10.CK+ 9.D0- 10022H-23C 8.D1 SHIELD 7.D0+ 6.D1- CEC3.3V 5.D2 SHIELD L1002 DDCD_SDA 4.D1+...

  • Page 162: Digital Unit (15/15)

    TO AO TO CU TO CM TO CS HCB1608KF-600T30 L1521 R1696 FROM DIGITAL POWER SUPPLY L1522 HCB1608KF-600T30 TO SUB MCU TO HDMI RX TO SiI9575 PAGE 14_B3 PAGE_16_D4 PAGE_24_C1 PAGE_25_C1 L1501 L1506 L1510 HCB1608KF-600T30 HCB1608KF-600T30 HCB1608KF-600T30 L1519 OPEN L1502 HCB1608KF-600T30 L1507 IC156 L1514...

  • Page 163: Smps Unit

    D9002 1N4007 AC IN 2.2M LF901 1N4007 D9003 OPEN LF902 BK902 D9004 1N4007 LF-4ZB-E273H OPEN J9003 JUMPER D9005 1N4007 AV7701 D9006 1N4007 LF901 JUMPER JUMPER R9002 R9003 LF902 1M(0.2W) 1M(0.2W) C9003 0.01uF 250V CN901 T9001 SRL3060P ZD901 D9012 OPEN ST-4430A...

  • Page 164: Hdam/Amp Unit (1/3)

    HDAM_AMP_UNIT #1 R7134 R7166 R7118 R7129 R7130 R7123 R7133 R7128 Q7004 Q7018 Q7022 R7054 Q7002 R7015 2SC3324BL 2SC3324BL 2SC3324BL 2SC3324BL C7117 C7139 R7042 R7029 Q7021 22/50V R7127 22/50V R7125 Q7029 2SA1312BL 22/50V 22/50V 2SA1312BL C7111 C7144 R7037 R7021 R7009 R7022 R7018 R7023 IC709...

  • Page 165: Hdam/Amp Unit (2/3)

    HDAM_AMP_UNIT #2 A+12V AGND A-12V R7272 R7271 R7285 C7158 R7292 C7160 47/50V R7264 47/50V CN_RELD_F R7263 R7305 R7288 R7252 C7129 C7089 R7273 OPEN AN_HP_L R7259 C7133 OPEN R7294 C7127 C7136 R7257 AGND OPEN 5.6K 10/50V 100/16V R7281 22/50V R7308 AN_HP_R R7287 DI-2 R7282...

  • Page 166: Hdam/Amp Unit (3/3)

    DL-2 HDAM_AMP_UNIT #3 RELAY TO_HDAM_AMP_2 (RL_GND) AGND CN_RELD_F CN_RELD_F TO DM-2 CN_RELD_C_SW2 CN_RELD_C_SW2 CN_RELD_C_SW1 CN_RELD_C_SW1 TO DG-2 CN_RELD_S CN_RELD_S CN_RELD_HP CN_RELD_HP TO_HDAM_AMP_2 A+12V AGND AN_REL_SBL A-12V AN_REL_SBR DH-2 C7153 R7346 C7151 47/50V 47/50V R7333 C7168 22/50V AN_PRESBL R7359 CN_RELD_SB C7152 AN_PRESBR R7348 R7345...

  • Page 167: Balance Connctor & Balance Out Unit

    BALANCE OUT BALANCE CONNCTOR R7064 R7067 C7051 JK700 BN700 JK701 BN700 1000P R7330 C7121 R7047 XLR-301P-A(Q24) SW1+ 22/50V R7068 R7070 AGND SW1- AGND R7071 R7074 AGND SW2+ SW2- R7329 C7125 R7048 C7052 AGND AGND 22/50V JK702 1000P XLR-301P-A(Q24) R7075 R7078 R7328 C7103 R7050...

  • Page 168: To Regulator Part Unit

    FUSE PART A-8V_IN A_GND A+8V_IN AC_IN R9317 D9332 1N4007ST D9331 OPEN OPEN D9330 1N4007ST D9329 OPEN F9305 AC_IN A_GND T1.6AL 250V A_GND BN933A BN933A F9304 CJP11HJ282Z AC_IN D9328 OPEN T1.6AL 250V D9327 1N4007ST A2008WR0-3P D9326 OPEN CN941 AC_IN R9316 D9325 1N4007ST OPEN D9313...

  • Page 169: Exploded View

    EXPLODED VIEW WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.  印の部分は安全を維持するために重要 な部品です。従って交換時は必ず指定の 部品を使用してください。...
  • Page 170 Personal notes: Personal notes:...

  • Page 171: Parts List Of Exploded View

    PARTS LIST OF EXPLODED VIEW z Parts indicated by "nsp" on this table cannot be supplied. z PCB ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the PCB ASS'Y, check the board parts list and order replacement parts. z Parts indicated by the "...
  • Page 172 Ref. No. Part No. Part Name Remarks Q'ty New 18301001910AS MODULE , HD RADIO CNVKRMAVR2011 M1 421410006004M BADGE , MARANTZ CGB1A206 M2 943402103100M AL PANEL CKM1A249WC23 943402103110M AL PANEL CKM1A249VC23 M3 943424100350M RING CGK1A163C23 BRACKET , BODY CMD2A668 415410001011M DOOR , AL FRONT AV8003...
  • Page 173 Ref. No. Part No. Part Name Remarks Q'ty New RUBBER CHG1A113 SUPPORT , PCB CMH1A328 SPACER , PCB CRE1A107 SUPPORT , PCB 31 CRE1A073 SUPPORT, PCB CRE1A102 SPACER, PCB CRE1A113 SUPPORT , EVA CHG1A536 CUSHION , SUPPORT CHG1A305 SCREW CTB3+10JR SCREW CTB26+8JFZR SCREW...

  • Page 174: Packing View

    PACKING VIEW...

  • Page 175: Parts List Of Packing & Accessories

    PARTS LIST OF PACKING & ACCESSORIES z Parts indicated by "nsp" on this table cannot be supplied. z Parts indicated by the " ★ " mark are not illustrated in the packing view. z The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions. NOTE: The symbols in the column "Remarks"...

  • Page 176: Semiconductors

    SEMICONDUCTORS Only major semiconductors are shown. General semiconductors etc. are omitted from list. The semiconductors which have a detailed drawing in a schematic diagram are omitted from list. 1. IC's R5F56108VNFP (HDMI : IC201) PE0/D8 PC4/A20 PD7/D7 PC5/A21/SCK5/CS5#-D PD6/D6 PC6/A22/RxD5/CS6#-D PD5/D5 PC7/A23/TxD5/CS4#-D/CS7#-D PD4/D4...
  • Page 177 Pull up/ Pin Name Symbol LvCnv STBY STOP Function down STBY Data received from the external P01/IRQ9-A/TMCI2/ RXD MI232O M3VPu pin(AMX)/Use for firmware upgrading RxD6 by DFW.:FFC Connect Data transfer to external pin(AMX)/Use P00/IRQ8-A/TMRI2/ TXD MO232I for firmware upgrading by DFW.:FFC TxD6 Connect POWER KEY (Waiting Mode cancel, P65/IRQ15-A POWER KEY M3VPu...
  • Page 178 Pull up/ Pin Name Symbol LvCnv STBY STOP Function down STBY ADV8003 SPI 46 P11/IRQ1-B/SCK2 OSD control pin (ADV8003) 47 P10/IRQ0-B ADV8003 SPI CS OSD control pin (ADV8003) P37/PO15/TIOCA2/ EEPROM SDA M3VPu EEPROM control pin TIOCB2/TCLKD-A 49 P36/PO14/TIOCA2 EEPROM SCL M3VPu EEPROM control pin P35/PO13/TIOCA1/...
  • Page 179 Pull up/ Pin Name Symbol LvCnv STBY STOP Function down STBY P70/CS3#-B/ ADTRG2# 91 VCC +3.3V PB0/A8/PO24/ TIOCA9 93 VSS PA7/A7/PO23/ TIOCA8/TIOCB8/ TCLKH PA6/A6/PO22/ Master Volume rotation detection VSEL A TIOCA8 pin(Rotary encoder) PA5/A5/PO21/ Master Volume rotation detection TIOCA7/TIOCB7/ VSEL B pin(Rotary encoder) TCLKG PA4/A4/PO20/...
  • Page 180 Pull up/ Pin Name Symbol LvCnv STBY STOP Function down STBY 135 P45/IRQ13-B/AN5 KEY3 SW3VPu Button input 3 136 P44/IRQ12-B/AN4 KEY2 SW3VPu Button input 2 137 P43/IRQ11-B/AN3 KEY1 SW3VPu Button input 1 ETHERNET communication control 138 P42/IRQ10-B/AN2 E SPI REQ pin(DM860) 139 P41/IRQ9-B/AN1 140 AVSS...
  • Page 181 R5F3650KNFB (HDMI : IC231)
  • Page 182 R5F3650KNFB Terminal Functions Pu/Pd Pin Name Synbol I/O Type P.OFF Function (Ext.) STBY 1 P94 2 P93 DIR CE DIR control pin 3 P92/SOUT3 DIR DIN DIR control pin 4 P91/SIN3 DIR DOUT DA3.3Pu DIR control pin 5 P90/CLK3 DIR CLK DIR control pin 6 BYTE BYTE...
  • Page 183 Pu/Pd Pin Name Synbol I/O Type P.OFF Function (Ext.) STBY 60 VCC +3.3V 61 P30 DAC MS DAC control pin(ASK4358) 62 VSS 63 P27 DAC RST DAC control pin(ASK4358) MODE1=O/H 64 P26 DV POWER DIGITAL VIDEO power control pin (DV5V,DV3.3V) MODE2=O/L 65 P25/INT7 ADV7850 INT1...
  • Page 184 Sil9575 (HDMI : IC501) 176 175 174 173 172 171 170 169 168 167 166 165 164 163 162 161 160 159 158 157 156 155 154 153 152 151 150 149 148 147 146 145 144 143 142 141 140 139 138 137 136 135 134 133 SCK0_IN/GPIO10 WS0_IN/GPIO11 SPDIF0_OUT/DL2...
  • Page 185 AD8195ACPZ (HDMI : IC101) AD8195 30 AVCC PIN CONFIGURATION AND FUNCTION DESCRIPTIONS PIN 1 29 PE_EN INDICATOR 28 TX_EN 27 AVEE VTTI 26 AVCC AD8195 TOP VIEW 25 AVCC (Not to Scale) 30 AVCC 24 AVEE PIN 1 29 PE_EN INDICATOR 23 AVCC 28 TX_EN...
  • Page 186 AD8195ACPZ Block diagram PARALLEL AVCC AD8195 AMUXVCC VTTI AVEE CONTROL LOGIC VTTO IP[3:0] OP[3:0] BUFFER – – IN[3:0] ON[3:0] HIGH SPEED BUFFERED VREF_IN VREF_OUT SCL_IN SCL_OUT SDA_IN SDA_OUT CEC_IN CEC_OUT LOW SPEED BUFFERED BIDIRECTIONAL...
  • Page 187 LC89057W-VF4A (DI: IC101) LC89057W-VF4A (DI: IC101) LC89057W-VF4A (HDMI : IC403) EMPHA/UO AUDIO/VO XMODE EMPHA/UO AUDIO/VO XMODE RX OUT Microcontroller RX OUT C bit, U bit Microcontroller 37 DO C bit, U bit 37 DO 36 RERR 36 RERR 24 SDIN 24 SDIN 23 SLRCK Input...
  • Page 188 Pin Name Function XOUT X tal osc. connecting output ter minal X tal osc. connection, e xternal cloc k input ter minal (24.576MHz or 12.288MHz) DVDD Digital power DGND Digital GND EMPHA/UO Emphasis inf ormation/U-data output/Chip address setting ter minal AUDIO/V O Non-PCM detect/V - ag output/ Chip address setting ter minal CKST...
  • Page 189 ADSP21487KSWZ-4B (HDMI : IC408) PIN 1 GND PAD (PIN 177) at BOTTOM Preliminary Technical Data ADSP-21483/21486/21487/21488/21489 TOP VIEW (PINS DOWN) 176-LEAD LQFP_EP LEAD ASSIGNMENT ADSP21487KSWZ Terminal Function Table 53. 176-Lead LQFP_EP Lead Assignment Pin Name Pin No. Pin Name Pin No. Pin Name Pin No.
  • Page 190 W9864G2IH W9864G6JH-6 (HDMI : IC409) 4. PIN CONFIGURATION                                 ...
  • Page 191 W9864G6JH-6 Block diagram CLOCK BUFFER CONTROL SIGNAL GENERATOR COMMAND DECODER COLUMN DECODER COLUMN DECODER CELL ARRAY CELL ARRAY BANK #0 BANK #1 MODE REGISTER SENSE AMPLIFIER SENSE AMPLIFIER ADDRESS BUFFER DATA CONTROL CIRCUIT BUFFER DQ31 COLUMN REFRESH COUNTER COUNTER DQM0~3 COLUMN DECODER COLUMN DECODER CELL ARRAY...
  • Page 192 W9864G2IH W9864G6JH-6 Pin description 5. PIN DESCRIPTION PIN NUMBER PIN NAME FUNCTION DESCRIPTION Multiplexed pins for row and column address. Row address: A0−A10. Column address: A0−A7. 24, 25, 26, 27, 60, 61, 62, A0−A10 Address A10 is sampled during a precharge command to 63, 64, 65, 66 determine if all banks are to be precharged or bank selected by BS0, BS1.
  • Page 193 MX29LV160DBTI-70G (HDMI : IC410) MX29LV160DBTI-70G Block Diagram...
  • Page 194 SLAS764 – MAY 2011 www.ti.com DEVICE INFORMATION TERMINAL FUNCTIONS, PCM510x PCM5100 (HDMI:IC321) PCM510X (top view) Table 2. TERMINAL FUNCTIONS, PCM510x TERMINAL DESCRIPTION NAME CPVDD Charge pump power supply, 3.3V CAPP Charge pump flying capacitor terminal for positive rail CPGND Charge pump ground CAPM Charge pump flying capacitor terminal for negative rail VNEG...
  • Page 195 AK5358BET (HDMI : IC451) AK5358BET Pin Function...
  • Page 196 AK4358VQ -40∼+85°C 48pin LQFP AKD4358 評価ボード ピン配置 AK4358VQ (HDMI : IC441) AVSS LOUT1- AVDD LOUT1+ DZF3 VREFH DZF2 ROUT4+ AK4358VQ DZF1 ROUT4- DIF0 CAD0 ACKSN DSDR3 Top View DSDL3 BICK DSDR2 MCLK DSDL2 DSDR1 DVDD DVSS DSDL1 ASAHI KASEI [AK4358] PIN/FUNCTION AK4358VQ Pin Function Pin Name...
  • Page 197 DSDL4 DAC4 DSD Lch Data Input Pin DSDR4 DAC4 DSD Rch Data Input Pin DSDL1 DAC1 DSD Lch Data Input Pin DSDR1 DAC1 DSD Rch Data Input Pin DSDL2 DAC2DSD Lch Data Input Pin DSDR2 DAC2 DSD Rch Data Input Pin H27U1G8F2B Series DSDL3 DAC3 DSD Lch Data Input Pin...
  • Page 198 1.2 PIN DESCRIPTION H27U1G8F2BTR-BC Pin Function Pin Name Description DATA INPUTS/OUTPUTS The IO pins allow to input command, address and data and to output data during read / program IO0 ~ IO7 operations. The inputs are latched on the rising edge of Write Enable (WE). The I/O buffer float to High-Z when the device is deselected or the outputs are disabled.
  • Page 199 PIN CONFIGURATION A3V56S30FTP-G6 (HDMI:IC392,393) (TOP VIEW) D Q 7 DQ15 VddQ VddQ VssQ VssQ VddQ V s s Q DQ14 DQ13 D Q 6 VssQ VssQ VddQ VddQ VssQ V d d Q DQ12 DQ11 D Q 5 VddQ VddQ VssQ VssQ VddQ...
  • Page 200 A3V56S30FTP A3V56S40FTP 256M Single Data Rate Synchronous DRAM A3V56S30FTP-G6 Pin Function Pin Descriptions SYMBOL TYPE DESCRIPTION Clock: CLK is driven by the system clock. All SDRAM input signals are sampled on the positive edge of CLK. CLK also increments the internal burst counter and controls the output registers. Input Clock Enable: CKE activates (HIGH) and deactivates (LOW) the CLK signal.
  • Page 201 A3V56S30FTP A3V56S40FTP 256M Single Data Rate Synchronous DRAM A3V56S30FTP-G6 Block Diagram Note:This figure shows the A3V56S30FTP The A3V56S40FTP configuration is 8192x512x16 of cell array and DQ0-15 Type Designation Code A 3Ｖ 56 Ｓ４０F ＴＰ－G6 Speed Grade 75： 133MHz@CL=3 7： 143MHz@CL=3 6：...
  • Page 202 Chapter 2 Pin Description and Configuration LAN8720A (HDMI:IC322) VDD1A MDIO SMSC LAN8720A/LAN8720Ai CRS_DV/MODE2 24 PIN QFN (TOP VIEW) RXER/PHYAD0 VDDIO RXD0/MODE0 RBIAS RXD1/MODE1 NOTE: Exposed pad (VSS) on bottom of package must be connected to ground Figure 2.1 24-QFN Pin Assignments (TOP VIEW) Note: When a lower case “n”...
  • Page 203 Small Footprint RMII 10/100 Ethernet Transceiver with HP Auto-MDIX Support Datasheet Pin Assignments LAN8720A Pin Function Table 2.8 24-QFN Package Pin Assignments PIN NUM PIN NAME PIN NUM PIN NAME VDD2A LED2/nINTSEL nINT/REFCLKO Small Footprint RMII 10/100 Ethernet Transceiver with HP Auto-MDIX Support Datasheet LED1/REGOFF nRST...
  • Page 204 SAA7121 (HDMI : IC323) 33 V SSA2 res. V SSA1 V DDA3 CVBS V SSD1 res. SAA7120 V DDD1 V DDA2 SAA7121 RCV1 res. RCV2 V DDA1 res. MBH790 SAA7121 Block Diagram V DDA1, handbook, full pagewidth RCV1 TTXRQ XTALO V DDA2 , V DDA4 V DDA3...
  • Page 205 Digital Video Encoder (ConDENC) SAA7120; SAA7121 SAA7121 Pin Description PINNING SYMBOL DESCRIPTION res. − reserved test pin; connected to digital ground for normal operation test pin; connected to digital ground for normal operation line-locked clock; this is the 27 MHz master clock for the encoder digital ground 1 SSD1 digital supply voltage 1...
  • Page 206 CONFIDENTIAL 8-CHANNEL ELECTRONIC VOLUME With 14-Input selector And Tone control BLOCK DIAGRAM AND PIN CONFIGURATION (TOP VIEW) R2A15220FP (AUDIO : IC471) TRER MUTE AVEE AVCC BASSR2 AVEE BASSR1 ADCL 0/-6/-12/-18dB ADCR TREL SUB2 AGND BASSL2 MAIN INR1 BASSL1 Bass/ Treble 0~-95dB, +42~0dB -14~+14dB...
  • Page 207 R2A15220FP R2A15220FP CONFIDENTIAL 8-CHANNEL ELECTRONIC VOLUME With 14-Input selector And Tone control PIN DESCRIPTION R2A15220FP Pin Function PIN No. Function Name FROUT,FLOUT, 22,20, COUT,SWOUT, 16,14, Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel SROUT, SLOUT, 10, 8, SBROUT,SBLOUT 2, 100 23,19, FR Pre-out,FL Pre-out, Pre-output pin of FL/FR/SL/SR/SBL/SBR channel 11, 7, SR Pre-out, SL Pre-out,...
  • Page 208 G   G    I I I I BLOCK DIAGRAM NJW1194A (AUDIO : IC484,IC489)                        ...

  • Page 209: Fl Display

    2. FL DISPLAY FLD (17-BT-40GINK) (FRONT : FL601) PIN CONNECTION GRID ASSIGNMENT...
  • Page 210 ANODE CONNECTION...

  • Page 211: Parts List Of Pcb Unit

    PARTS LIST OF PCB UNIT z Parts indicated by "nsp" on this table cannot be supplied. z The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions. NOTE: The symbols in the column "Remarks"...
  • Page 212 Ref. No. Part No. Part Name Remarks Q'ty New C6083 CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC C6091-6093 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C6094 CAP, ELECT(50V/10uF) CCEA1HH100T C6095 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C6096-6098 CAP, CHIP(1608, 50V/100pF) CCUS1H101JA C6099 CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC C6113 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C6114 CAP, ELECT(50V/10uF)
  • Page 213 Ref. No. Part No. Part Name Remarks Q'ty New R6046 00MNN05124610 RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T R6049-6051 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R6058-6060 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R6066-6068 RES, CHIP(1608/5%/150ohm) CRJ10DJ151T R6071-6073 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R6079-6081 RES, CHIP(1608/5%/180ohm) CRJ10DJ181T R6082 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R6084,6085 00MNN05221610 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T...
  • Page 214 Ref. No. Part No. Part Name Remarks Q'ty New OTHERS PARTS GROUP BK601 BRACKET , PCB CMD1A569 BK604 BRACKET , VFD CMD1A793 BK605 BRACKET , FLT CMD1A209-V1 BK605 BRACKET , FLT CMD1A209 BK606 BRACKET , FLT CMD1A209-V1 BK606 BRACKET , FLT CMD1A209 WIRE ASS'Y (5P,2.0MM,550MM,UL2725# BN321...

  • Page 215: Front Hdmi Pcb Unit Ass'y

    FRONT HDMI PCB UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP IC101 I.C, HDMI BUFFER CVIAD8195ACPZ CAPACITORS GROUP C1007 CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC C1013 CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC C1014 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C1015 CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC C1016...

  • Page 216: Smps Pcb Unit Ass'y

    SMPS PCB UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP D9001-9006 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST D9008,9009 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST D9010 00D9430182609 DIODE , SWITCHING, 1SS133 CVD1SS133MT DIODE, LOW FORWARD SCHOTTKY D9012 943209500030S CVDSRL3060P RECTIFIER D9013...
  • Page 217 Ref. No. Part No. Part Name Remarks Q'ty New CAP, CHIP(1608, 6.3V/4.7uF, MURATA C9019 CCUS0J475KC GRM18) C9020-9022 963134010220S CAP, ELECT(6.3V/5600uF) CCEA0JNXA562ES C9024 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC z C9028 963132011930S CAP, CERAMIC(X1/Y1,2200P,AC250V) CCKDKX222MEM C9029 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC RESISTORS GROUP R4609,4610 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R4619,4620...
  • Page 218 Ref. No. Part No. Part Name Remarks Q'ty New R4871-4874 RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T R4875,4876 00MNN05470610 RES, CHIP(1608/5%/47ohm) CRJ10DJ470T R4877,4878 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R4881,4882 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R4883-4886 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R4891,4892 RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T R4899 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R9002,9003 RES, CARBON(1/5W,1Mohm,J)

  • Page 219: Input Pcb Unit Ass'y

    INPUT PCB UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP D4779,4780 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT I.C , OPAMP(DUAL/LOW NOISE)_Copper IC466 00D2631289900 CVIAZ4580MTR-E1-CU Z4580MTR-E1-CU IC471 235810045600S I.C , 8CH VOLUME CVIR2A15220FP I.C , OPAMP(DUAL/LOW NOISE)_Copper IC481-483 00D2631289900 CVIAZ4580MTR-E1-CU...
  • Page 220 Ref. No. Part No. Part Name Remarks Q'ty New C4843 943134501580S CAP, ELECT(25V/33uF) CCEA1EH330T C4844 CAP, ELECT(50V/10uF) CCEA1HH100T C4845 943134501580S CAP, ELECT(25V/33uF) CCEA1EH330T C4851,4852 CAP, ELECT(50V/10uF) CCEA1HH100T C4861,4862 CAP, ELECT(50V/10uF) CCEA1HH100T C4875-4878 CAP, ELECT(50V/10uF) CCEA1HH100T C4881,4882 CAP, ELECT(50V/10uF) CCEA1HH100T C4891,4892 CAP, ELECT(50V/4.7uF) CCEA1HH4R7T C4893...
  • Page 221 Ref. No. Part No. Part Name Remarks Q'ty New PIN SOCKET CN41B CJP15HJ282Z (15P,1.25mm,ANGLE,B-TO-B) PIN SOCKET CN42B CJP27HJ282Z (27P,1.25mm,ANGLE, B-TO-B) CN43B PINSOCKET(11P,1.25mm,ANGLE,B-TO-B) CJP11HJ282Z CN45B PINSOCKET(11P,1.25mm,ANGLE,B-TO-B) CJP11HJ282Z JK461-463 943643102130S JACK, 4P(W/R,W/R),SEPA-GND, GOLD CJJ4P079Z JK464 943643102140S JACK, 4P(W/R,W/B),SEPA-GND, GOLD CJJ4P080Z JK465 943643102130S JACK, 4P(W/R,W/R),SEPA-GND, GOLD CJJ4P079Z L4661,4662...

  • Page 222: Video Pcb Unit Ass'y

    VIDEO PCB UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP ESD SUPPRESSOR D1202-1204 CLZ9Z120Z (ASQS 12U 02 0R2, 0.2pF/12V 1005) D1501 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP D2301 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP D3002 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP D3301,3302 943209001080S...
  • Page 223 Ref. No. Part No. Part Name Remarks Q'ty New Q5312 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C Q5313,5314 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C Q5315 943214500020S T.R,2SC3052 CVT2SC3052 Q5316 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C CAPACITORS GROUP C1203-1205 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C1207 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C1209 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C1211...
  • Page 224 Ref. No. Part No. Part Name Remarks Q'ty New C1276 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1277 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1278 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1280 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1281 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1282 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1283 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1284...
  • Page 225 Ref. No. Part No. Part Name Remarks Q'ty New C1387 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1388 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1392 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1395 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1396 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1397 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1398 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1399...
  • Page 226 Ref. No. Part No. Part Name Remarks Q'ty New C1450 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1451 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1452 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1453 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1454 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1455 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1456 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1460...
  • Page 227 Ref. No. Part No. Part Name Remarks Q'ty New C1562 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1564 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1565 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1566 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1567,1568 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1571 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1572 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1573...
  • Page 228 Ref. No. Part No. Part Name Remarks Q'ty New CAP, CHIP C1704 CCUS0J475KC (1608, 6.3V/4.7uF, MURATA GRM18) C2012 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C2015,2016 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C2019-2022 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C2025 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C2303 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C2304 CAP, CHIP(1608, 10V/0.47uF)
  • Page 229 Ref. No. Part No. Part Name Remarks Q'ty New CAP, CHIP(1608, 6.3V/4.7uF, MURATA C3923 CCUS0J475KC GRM18) CAP, CHIP(1608, 6.3V/4.7uF, MURATA C3928,3929 CCUS0J475KC GRM18) C3930-3935 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C3937-3939 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC CAP, CHIP(1608, 6.3V/4.7uF, MURATA C3944 CCUS0J475KC GRM18) CAP, CHIP(1608, 6.3V/4.7uF, MURATA C3947 CCUS0J475KC...
  • Page 230 Ref. No. Part No. Part Name Remarks Q'ty New C4471,4472 CAP, CHIP(1608, 50V/3900pF) CCUS1H392KC C4483-4486 CAP, CHIP(1608, 50V/680pF) CCUS1H681JA C4492 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C4493,4494 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C4497 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C4511,4512 CAP, CHIP(1608, 10V/1uF) CCUS1A105KC CAP, CHIP(1608, 6.3V/4.7uF, MURATA C4513,4514 CCUS0J475KC GRM18)
  • Page 231 Ref. No. Part No. Part Name Remarks Q'ty New C5131-5133 CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC C5151-5153 CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC C5161 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C5162 CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC C5163 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C5164 963134010980S CAP, ELECT(16V/47uF) CCEA1CH470T C5165,5166 CAP, CHIP(1608, 50V/0.1uF)
  • Page 232 Ref. No. Part No. Part Name Remarks Q'ty New R1242 RES, CHIP(1608/5%/470ohm) CRJ10DJ471T R1247 943129007280M RES, CHIP(1608/5%/24ohm) CRJ10DJ240T R1249 943129007280M RES, CHIP(1608/5%/24ohm) CRJ10DJ240T R1251 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R1255,1256 RES, CHIP(1005/5%/10ohm) CRJ06IJ100T R1258,1259 RES, CHIP(1005/5%/2.2Kohm) CRJ06IJ222T R1260 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R1261-1264 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R1275-1277...
  • Page 233 Ref. No. Part No. Part Name Remarks Q'ty New R2155,2156 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2308 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2312,2313 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2316,2317 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2321 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2322 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2324 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2325,2326 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2330-2334 RES, CHIP(1005/5%/4.7Kohm)
  • Page 234 Ref. No. Part No. Part Name Remarks Q'ty New R3909 RES, CHIP(1005/5%/10Kohm*4) CRJ064IJ103T R3910,3911 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R3915 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R3917 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R3946 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R3961-3964 RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T R3971 RES, CHIP(1005/5%/1.8Kohm) CRJ06IJ182T R3972 RES, CHIP(1005/5%/1.2Kohm) CRJ06IJ122T R3992 RES, CHIP(1005/5%/0ohm)
  • Page 235 Ref. No. Part No. Part Name Remarks Q'ty New R5057 00MNN05100610 RES, CHIP(1608/5%/10ohm) CRJ10DJ100T R5058 RES, CHIP(1005/5%/5.1Kohm) CRJ06IJ512T R5063 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R5065 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R5091 00MNN05100610 RES, CHIP(1608/5%/10ohm) CRJ10DJ100T R5101-5103 RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T R5107 RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T R5108 RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T R5109...
  • Page 236 Ref. No. Part No. Part Name Remarks Q'ty New R5353,5354 00MNN05221610 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T R5355 00MNN05470610 RES, CHIP(1608/5%/47ohm) CRJ10DJ470T R5356-5358 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R5371,5372 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R5373,5374 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T RN141 RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T RN152 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN154 RES, CHIP(1005/5%/47ohm*4)

  • Page 237: Digital Pcb Unit Ass'y

    (8CH ANALOG,TSSOP-16P) I.C ADV8003KBCZ-8C IC151 963236101310S CVIADV8003KBCZ8C_K (WITH HDMI TX) I.C , DDR2 SDRAM IC152,153 23981007960AS CVIK4T51163QJ-BCE7 (512M,FBGA-84P) AV7701 OSD FLASH, U/N , IC155 943248101490S CVIANAM1725AV CVIANAM1725AV AV7701 OSD FLASH,K1B , IC155 943248101500S CVIANAM1726AV CVIANAM1726AV AV7701 MAIN CPU, U/N ,...
  • Page 238 Ref. No. Part No. Part Name Remarks Q'ty New Q1201-1203 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C Q1502 90M-HY200050R F.E.T (NEC) CVTUPA672T Q2301 943215500020S T.R , RT1P141C(10K-10K) CVTRT1P141C Q2302,2303 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C Q3001,3002 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 Q3004 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 Q3005 00D2710326904 T.R,2SA1954 CVT2SA1954 Q3006 943216500050S T.R,RT1N441C(47K-47K)
  • Page 239 Ref. No. Part No. Part Name Remarks Q'ty New C1457 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1458 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1459 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1463 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1464 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1502 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C1508 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C1510...
  • Page 240 Ref. No. Part No. Part Name Remarks Q'ty New C3043 CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC C3044 CAP, CHIP(2012, 10V/22uF) CCUC1A226KC C3047 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C3048 CAP, CHIP(1608, 50V/15pF) CCUS1H150JA C3051,3052 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C3053 CAP, CHIP(2012, 6.3V/10uF, X5R) CCUC0J106KC C3054 CAP, CHIP(2012, 10V/22uF)
  • Page 241 Ref. No. Part No. Part Name Remarks Q'ty New C3914 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC CAP, CHIP(1608, 6.3V/4.7uF, C3926,3927 CCUS0J475KC MURATA GRM18) C3936 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C3971,3972 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C4003,4004 CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC C4005-4008 CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC C4009,4010 CAP, CHIP(1005, 25V/0.01uF)
  • Page 242 Ref. No. Part No. Part Name Remarks Q'ty New C4537,4538 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C4541 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C4544 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C4581 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C4585-4588 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C4593 CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC C5002 CAP, CHIP(1608, 10V/1uF) CCUS1A105KC C5004...
  • Page 243 Ref. No. Part No. Part Name Remarks Q'ty New R1506 00MNN05105610 RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T R1521 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R1541 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R1544 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R1546 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R1547 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R1548-1551 RES, CHIP(1005/5%/1.8Kohm) CRJ06IJ182T R1552 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R1553 RES, CHIP(1005/5%/10Kohm)
  • Page 244 Ref. No. Part No. Part Name Remarks Q'ty New R2305 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2306,2307 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2309-2311 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2314 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2318-2320 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2327 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2328 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R2329 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R2338,2339 RES, CHIP(1005/5%/4.7Kohm)
  • Page 245 Ref. No. Part No. Part Name Remarks Q'ty New R3064 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R3065 RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T R3070 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R3071 RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T R3072 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R3073 RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T R3074 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R3075 RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T R3076 RES, CHIP(1608/5%/0ohm)
  • Page 246 Ref. No. Part No. Part Name Remarks Q'ty New R3973 RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T R3974 RES, CHIP(1005/5%/1.5Kohm) CRJ06IJ152T R3975 RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T R3976 RES, CHIP(1005/5%/12Kohm) CRJ06IJ123T R3984-3988 RES, CHIP(1005/5%/33ohm) CRJ06IJ330T R3991 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R4001-4004 RES, CHIP(1005/5%/150ohm) CRJ06IJ151T R4005,4006 RES, CHIP(1005/5%/470ohm) CRJ06IJ471T R4012,4013 RES, CHIP(1005/5%/47Kohm)
  • Page 247 Ref. No. Part No. Part Name Remarks Q'ty New R5004,5005 RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T R5007 00MNN05100610 RES, CHIP(1608/5%/10ohm) CRJ10DJ100T R5008 RES, CHIP(1005/5%/5.1Kohm) CRJ06IJ512T R5013,5014 RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T R5016 00MNN05100610 RES, CHIP(1608/5%/10ohm) CRJ10DJ100T R5024,5025 RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T R5027 00MNN05100610 RES, CHIP(1608/5%/10ohm) CRJ10DJ100T R5034 00MNN05100610 RES, CHIP(1608/5%/10ohm) CRJ10DJ100T...
  • Page 248 Ref. No. Part No. Part Name Remarks Q'ty New RN140 RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T RN142-145 RES, CHIP(1005/5%/4.7Kohm*4) CRJ064IJ472T RN151 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN153 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN155,156 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN158-166 RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T RN201 RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T RN401-403 RES, CHIP(1005/5%/33ohm*2) CRJ062IJ330T RN411-414 RES, CHIP(1005/5%/100ohm*4)
  • Page 249 Ref. No. Part No. Part Name Remarks Q'ty New L1508 FERRITE CHIP BEAD(1608/60R) CLZ9R005Z L1510 FERRITE CHIP BEAD(1608/60R) CLZ9R005Z L1512 FERRITE CHIP BEAD(1608/60R) CLZ9R005Z L1514 FERRITE CHIP BEAD(1608/60R) CLZ9R005Z L1521,1522 FERRITE CHIP BEAD(1608/60R) CLZ9R005Z L2902-2934 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T L2936 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T L3001-3008 RES, CHIP(3216/5%/0ohm)

  • Page 250: Preout Pcb Unit Ass'y

    PREOUT PCB UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP D6845-6847 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST D6848 90M-HD302380R DIODE , ZENER ,1/2W, 3.6V CVDZJ3.6BT D9308,9309 943209001080S DIODE , CHIP , SWITCHING 1SS355 CVD1SS355T IC931,932 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI IC934 943231010390S I.C,REGULATOR(+5V,T0220IS)
  • Page 251 Ref. No. Part No. Part Name Remarks Q'ty New R6731,6732 00MNN05221610 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T R6753-6756 RES, CHIP(1608/5%/470ohm) CRJ10DJ471T R6759,6760 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R6761,6762 00MNN05221610 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T R6773-6776 RES, CHIP(1608/5%/470ohm) CRJ10DJ471T R6779,6780 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R6781,6782 00MNN05221610 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T R6802,6803 RES, CHIP(1608/5%/470ohm)

  • Page 252: Cnt Pcb Unit Ass'y

    CNT PCB UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP D7022 00D2760683969 DIODE , ZENER(CHIP,12V) VDUDZS15BSR HVDUDZS12BSR D7023-7038 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP D7039 00D2760683969 DIODE , ZENER(CHIP,12V) VDUDZS15BSR HVDUDZS12BSR D7040,7041 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP D7042 00D2760798948...
  • Page 253 Ref. No. Part No. Part Name Remarks Q'ty New C7041 CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC C7042 CAP, CHIP(1608, 50V/0.022uF) CCUS1H223KC C7043 CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC C7044-7046 CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC C7047,7048 CAP, CHIP(1608, 50V/100pF) CCUS1H101JA C7051,7052 CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC C7053-7058 CAP,CHIP(1608,50V/220pF) CCUS1H221JA C7059...
  • Page 254 Ref. No. Part No. Part Name Remarks Q'ty New R7012 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T R7013 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T R7015 00MNN05220610 RES, CHIP(1608/5%/22ohm) CRJ10DJ220T R7017 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T R7018 00MNN05220610 RES, CHIP(1608/5%/22ohm) CRJ10DJ220T R7020 00MNN05221610 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T R7021 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R7022,7023...
  • Page 255 Ref. No. Part No. Part Name Remarks Q'ty New R7087,7088 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R7089 RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T R7091 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R7092 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R7093 RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T R7094 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R7095 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R7096 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T...
  • Page 256 Ref. No. Part No. Part Name Remarks Q'ty New R7156 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R7157 00MNN05101610 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R7158 RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T R7159 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T R7160 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R7162,7163 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T R7165 RES, CHIP(1608/5%/470ohm) CRJ10DJ471T R7166 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T...
  • Page 257 Ref. No. Part No. Part Name Remarks Q'ty New R7251 RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T R7252 00MNN05047610 RESISTOR CRJ10DJ4R7T R7253 RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T R7254 00MNN05047610 RESISTOR CRJ10DJ4R7T R7255 RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T R7256 00MNN05047610 RESISTOR CRJ10DJ4R7T R7257 00MNN05102610 RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T R7258 00MNN05047610 RESISTOR CRJ10DJ4R7T R7260-7264 00MNN05102610 RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T...
  • Page 258 Ref. No. Part No. Part Name Remarks Q'ty New R7361,7362 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R7367 00MNN05102610 RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T R7368 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T R7369,7370 00MNN05224610 RES, CHIP(1608/5%/220Kohm) CRJ10DJ224T R7373-7378 00MNN05102610 RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T R9601 RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T R9602,9603 00MNN05104610 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R9604 RES,CHIP(1608/5%/15Kohm)

  • Page 259: H-Dam Amp Pcb Unit Ass'y

    H-DAM AMP PCB UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP D7043-7047 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT D7068 943203003170S DIODE,BRIDGE HVDGBJ606 IC700 HEAT SINK ASS'Y(HVINJM7812FA+CMY4A025) CVINJM7812FACA I.C , OPAMP(DUAL/LOW NOISE)_Copper CVIAZ4580MTR- IC702-717 00D2631289900 Z4580MTR-E1-CU E1-CU IC718 00D2630995004...
  • Page 260 Ref. No. Part No. Part Name Remarks Q'ty New T.R , 2SC3324 Q7035,7036 00MHX800081AY CVT2SC3324BL (NPN, TO-236, LOW NOISE, TOSHIBA) T.R , 2SA1312 Q7037 00MHX600081AY CVT2SA1312BL (PNP, TO-236, LOW NOISE, TOSHIBA) T.R , 2SC3324 Q7038 00MHX800081AY CVT2SC3324BL (NPN, TO-236, LOW NOISE, TOSHIBA) T.R , 2SA1312 Q7039 00MHX600081AY...
  • Page 261 Ref. No. Part No. Part Name Remarks Q'ty New CAP, ELECT(16V/47uF,ELNA/RA2, 5X11) C7134 00MOA47601621 CCEA1ERA470T 6V/47UF, 5X11, ELNA/RA-2 C7135-7147 00D2544573994 ELECT CAP RA3-50V 220ME3 CCEA1HRA38P220T CAP, ELECT(47UF/50V, RA3, ELNA ) A3- C7148-7166 00D2544574919 CCEA1HRA3470T 50V470MF3#8P-T2 C7167,7168 00D2544573994 ELECT CAP RA3-50V 220ME3 CCEA1HRA38P220T C7169,7170 00D2544569937...
  • Page 262 Ref. No. Part No. Part Name Remarks Q'ty New R7151 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T R7161 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T R7164 RES, CHIP(1608/5%/470ohm) CRJ10DJ471T R7167 00MNN05331610 RES, CHIP(1608/5%/330ohm) CRJ10DJ331T R7170 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T R7173 00MNN05105610 RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T R7181 00MNN05220610 RES, CHIP(1608/5%/22ohm) CRJ10DJ220T R7186 00MNN05331610 RES, CHIP(1608/5%/330ohm)
  • Page 263 Ref. No. Part No. Part Name Remarks Q'ty New OTHERS PARTS GROUP BK700-702 BRACKET , XLR CMD1A825 BK703 BRACKET , PCB CMD1A569-V1 BK704,705 PLATE, MAIN PCB CMC2A424 BK706 BRACKET , PCB CMD1A569-V1 BK707 PCB BRACKET CMD1A629 BN700 WIRE ASS'Y Locking (YH) (7P,2MM,180MM,#26) CWB1B007180HC BN701 WIRE ASS'Y (11P,2.0MM,180MM,UL1007#26)

  • Page 264: Fuse Pcb Unit Ass'y

    FUSE PCB UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty New SEMICONDUCTORS GROUP D9311,9312 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST D9315 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST D9318,9319 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST D9322 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST D9325 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST...
  • Page 265 Ref. No. Part No. Part Name Remarks Q'ty New z F9302 963652010500S FUSE(S506Series,250V,1.6A) CBA2C1600TLEC z F9303 HOLDER , FUSE KJCFC5S z F9303 963652010500S FUSE(S506Series,250V,1.6A) CBA2C1600TLEC z F9304 HOLDER , FUSE KJCFC5S z F9304 963652010500S FUSE(S506Series,250V,1.6A) CBA2C1600TLEC z F9305 HOLDER , FUSE KJCFC5S z F9305 963652010500S...
  • Page 266 Personal notes:...

This manual is also suitable for:

Av7701/u1bAv7701/k1bAv7701/n1b

Table of Contents
