Content 1、Important statement-----------------------------01 2、Working principle--------------------------------02 3、Product list----------------------------------------02 4、Installation instructions-------------------------03 5、Working mode------------------------------------06 6、Parameter setting-------------------------------09 7、Technical parameter----------------------------14 8、FAQ------------------------------------------------14... -
Page 3: 1、Important Statement
1. Important statement 1.1 Welcome to use Carxpert tire pressure monitoring system. The installation proposal of this product is operated by professionals and equipment. Please read this manual carefully before installing this product to ensure correct installation and use. 1.2 This product is suitable for radial tires and aluminum alloy rim with a standard pressure of ≤3.0 bar, not for steel rim. -
Page 4: 2、Working Principle
1.8 Specifications and technical parameters may be changed due to upgrades and other reasons, resulting in inconsistence with the instruction manual. Please prevail in kind and manufacturers reserve the right to explain. 2. Working principle The tire pressure monitoring system, referred to as TPMS, works by monitoring the internal pressure and temperature of the tire through a sensor mounted on the tire, and transmitting the collected data information to the display installed in the cab by using radio frequency technology. -
Page 5: 4、Installation Instructions
4. Installation instruction 4.1 Display installation Long press the "-" key for 3 seconds to turn on/off, use anti-slip mat to securely place on the dashboard for easy observation and sunlight. The monitor is turned on in advance. The tire data will be displayed in turn when the sensor is installed. - Page 6 4.2 Sensor installation(take D sensor as a sample) Each sensor is labeled with a corresponding position, such as left front wheel A, right front wheel B, right rear wheel C, and left rear wheel D, which must be accurately installed on the corresponding hub. After installation, attach a warning label near the rim of the sensor.
- Page 7 ⑤ Use M11 socket to lock nut ⑥ Sample of installation with torque 5 N.M E R 6 0 C E M B ⑧ Replace the tire ⑦ Check tire dynamic balance Precautions: a. The installation angle of the sensor electronic module must be parallel to the rim, which is more conducive to ensuring continuous work and accuracy.
-
Page 8: 5、Working Mode
b. After the sensor installation is complete, check the tires for air leaks and spray the valve nozzle with foam water to confirm. If the air leaks, please adjust the valve angle or clean the rim hole. Tips: If there is no data displayed after installation, please inflate or deflate the corresponding tire or drive a certain distance at a speed of more than 30 kilometers per hour for normal display. - Page 9 Tips: After the display goes to sleep or is turned off, the solar panel will continue to work. When the temperature inside the car exceeds 55 °C, the display will automatically stop charging to protect the battery and safety. 5.3 Display backlight mode The light adjustment can be automatic or manual, subject to actual product model.
- Page 10 Icon & Description Abnormal High temper- ature alarm When the monitor detects a tire temperature exceeding the alarm value, the tire temperature alarm is triggered. The alarm icon“ ” flashes at the same time and emits alarm sound “di…di…di…”. The picture shows high temperature alarm for the left front wheel.
-
Page 11: 6、Parameter Setting
6. Parameter settings Please follow the tire pressure value in the vehicle manual to inflate the tire. High pressure alarm value = tire pressure value X 125%; low pressure alarm value = tire pressure value X 75%; High temperature alarm value=80℃. - Page 12 6.2 High temperature alarm setting Icon& Description 1. Long press the "+" key, release it after sound “di...” to enter the setting mode. 2. Short press the "-" key 4 times to enter the "HI" option, as shown below: 3. Short press the "+" button once, the number will flash at this time. 4.
- Page 13 6.3 Pressure unit setting Icon& Description 1.Long press the "+" button, release it after sound “di...” to enter the pressure unit interface, as shown below: 2. Short press the "+" key once, the pressure unit flashes at this time. 3. Short press "-" key to adjust to the required pressure unit, short press "+" key to save.
- Page 14 6.5 Tire switch setting If the user needs to change the tire, there is no need to re-assemble and disassemble the sensor, only the tire change operation can be performed on the display. The specific operation of tire rotation is as follows (take the front left and the front right wheels as an example): Icon&...
- Page 15 Icon& Description 1.Short press "+" key 5 times to enter the matching interface, as shown below: 2.Short press the "-" key to select the tire position of the sensor to be replaced, when “---“ flashes, inflate and deflate the tires, and the tire pressure data will be displayed after sound “di...”...
-
Page 16: 7、Technical Parameter
7. Technical parameter Display Sensor Working Storage temperature -30℃～85℃ 2.0～3.6V voltage Emission Working frequency 433 MHz 1～6.6mA current -20℃～80 ℃ Air pressure Working temperature 0～3.5Bar range ±0.1Bar Air pressure Working current accuracy (-20℃～85℃) Temperature Charging current 500mA/5V ±3℃(-20℃～70℃) accuracy Working humidity Temperature MAX95% -40℃～125℃... - Page 17 3. Why the tire data of a certain monitor is not updated for a long time? Possible causes: (1) Electromagnetic interference exists in the location or environment. For example, some recorders and navigators have electromagnetic interference. Please change the location (far away from the interference source) to solve the problem.
- Page 18 8.Where can I find the standard inflation pressure of a tire? Answer: Generally you can find it in the doorpost, fuel tank cover, glove box, and vehicle manual. 9.Is the tire imbalance large after installing the sensor? Answer: The sensor uses a miniature module, and the weight (including the valve) is only about 22 grams.
