DOUBLE GLIDER RECLINING LOVE SEAT WITH CONSOLE
NOTE: Do not use power tools for assembly. Power tools increase the risk
of over tightening which lead to splitting or cracking the wood.
PARTS LIST
NO.
A
B
C
D
E
F
G
Assembly Instruction
ITEM NO. 9928BLK/DBR-2
DRAWING
QTY
1
1
1
1
1
1
2
- 1 -
DESCRIPTION
LSF BACK REST
RSF BACK REST
CONSOLE BACK REST
LSF EAR
RSF EAR
SEAT
BOLT
