SPECIFICATIONS
Part Number: 116847
Set Up Size: L 89 x W 36 x H 66
Packed Size: L 44 x W 36 x H 24 folded seat
W e i g h t: 48 lbs.
Fishable Area: 10 sq.ft
Instructions: 106970
Please contact customer service directly at the E-mail or phone number listed below for any
quality issues. ONCE USED THIS PRODUCT CANNOT BE RETURNED TO STORE.
** Warranty cannot be honored without an original, dated receipt **
IMPORTANT-PLEASE READ:
This product is warranted to the original retail purchaser (from an authorized dealer) and is non-transferable.
Clam Outdoors has a one year manufacturer's defect warranty from the date of original purchase. Warranty
does not cover cracked or worn bases (if runner kits have not been installed as recommended), cracked
windows, tent tears or cuts, or broken or bent hoops due to high wind weather conditions or unattended use.
Defective parts will be replaced or repaired (at the manufacturer's option) if found to be defective within one
year from the date of original purchase. Warranty will be void if product has been subject to neglect, misuse,
improper installation, misapplication, alteration, accident including but not limited to improper maintenance, or
use of unauthorized parts or attachments. Please read the entire owner's manual to ensure proper installation,
use, storage and care of your Clam Shelter.
To submit a warranty claim request, please use one of the following methods:
https://clamoutdoors.com/pages/warranty-form
▪ Email:
customerservice@clamcorp.com
In your request, please include your full name, address, phone number, a copy of your receipt, a brief description
of the problem, and pictures to clearly show the area(s) of concern. Our Warranty Department will review your
request, and a Clam representative will contact you regarding your claim status. All returns must be shipped to
us postage pre-prepaid.
It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of
warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is
not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss
of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to
use, or the repair or replacement of Clam products. Clam reserves the right to make alterations or
modifications in its products at any time, which in its opinion, may improve the performance and efficiency of
the product. Clam shall not be obligated to make such alterations or modifications to products already in service
Clam contact information
Customer Service Hrs: 9am to 4pm, Monday – Friday Central Standard Time
Clam Outdoors
Attn: Customer Service
12135 Brockton Lane
Rogers, MN 55369
Phone: 763-231-4120
CLAMOUTDOORS.COM
WARRANTY INFORMATION
** REGISTER YOUR PURCHASE ONLINE AT CLAMOUTDOORS.COM **
LIMITATION OF LIABILITY
MODEL 16847

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dave Genz SCOUT XT THERMAL and is the answer not in the manual?

Questions and answers

Summary of Contents for Clam Dave Genz SCOUT XT THERMAL

  • Page 1 It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or replacement of Clam products.
  • Page 2: Parts List

    PARTS LIST QTY. PART NO. DESCRIPTION 106949 BASE, SCOUT XT 106874 HOOP, EXTENSION, SCOUT XT 106873 HOOP, SCOUT XT 106745 ASSY, HOOP EXTENTION, HINGED, 31.00 LG 106735 TENT SCOUT XT 106950 TUBE, SEAT STAND, SCOUT XT 103614 ASSY, FOLDING SEAT 101074 ASSY, ADJUSTABLE SPRDR 101095...
  • Page 3 HARDWARE FASTENERS REFERENCE...
  • Page 4 *IT IS BEST TO USE THE AID OF ANOTHER PERSON DURING Visit Clam’s website (www.clamoutdoors.com) and or our YouTube ASSEMBLY. channel (Clam Outdoors) for shelter build how to videos INSTALL ANY RUNNER KIT OPTIONS BEFORE ASSEMBLING SHELTER. REFER TO RUNNER KIT INSTRUCTIONS STEP-1 1.INSTALL BOTH BRACKETS TO EACH SIDE OF BASE AS SHOWN.
  • Page 5 STEP-2 DO NOT CUT ANY OF YOUR POLES 1.INSTALL PLASTIC CAPS INTO HOOP POLES AS SHOWN. ALIGN CAP AND POLE HOLES...
  • Page 6 STEP-3 1. LAY TWO OF THE HOOP POLES TOGETHER ON FLOOR AND ASSEMBLE TO SWIVEL PLATES WITH FASTENERS AS SHOWN 2. SCREW IN THE PROPER SCREWS INTO PLATE DO NOT OVERTIGHTEN. 3. WHILE HOLDING THE SCREW IN PLACE START TO THREAD THE NYLOCK NUT ONTO THE SCREW AND TIGHTEN BY HAND UNTIL RESISTANCE IS FELT.
  • Page 7 STEP-4 1. LAY ASSEMBLED HOOP POLES ON TOP OF BASE AND ATTACH BOTH SIDES AS SHOWN. 1. FASTEN NUT TO SCREW WHILE NEED TO HAVE A SPACE BETWEEN HOLDING SCREW IN PLACE SO BRACKET AND NUTS. THAT IT DOES NOT ROTATE POLES AND PLATES SHOULD MOVE EASILY, DO NOT OVERTIGHTEN...
  • Page 8 STEP-5 1. ATTACH THE HINGED EXTENSION POLES TO CLIP WITH SUPPLIED FASTENERS AS SHOWN TO BOTH SIDES. SLOT MUST FACE INWARD POLE MUST ROTATE FREELY AFTER TIGHTENING FASTENERS. STEP-6 1. INSTALL COLLARS TO SHORTEST HOOP POLE AS SHOWN ALIGN COLLAR WITH THE HOLES IN HOOP AS SHOWN...
  • Page 9 STEP-7 1. SLIDE HOOP POLE INTO PLACE AS SHOWN. COMPLETED HOOP POLE ASSEMBLY AT THIS POINT SHOULD MOVE FREELY AND LOOK LIKE THE FOLLOWING PICTURE. INSTALL ROPE AND TIE OFF ENDS INSIDE OF BASE.
  • Page 10 STEP-8 1. ATTACH SEAT BRACKETS TO BOTTOM OF SEAT AS SHOWN AND SECURELY TIGHTEN. 2. ATTACH SEAT BRACKETS TO BOTH SIDE OF TUB BASE AS SHOWN. DO NOT TIGHTEN. WHEN ALL FASTENERS HAVE BEEN INSTALLED SECURELY TIGHTEN BRACKETS TO BASE AS SHOWN ABOVE.
  • Page 11 STEP-9 1. DRAPE THE TENT OVER THE HOOP POLES. ATTACH THE TENT TO THE POLES ON THE INSIDE WITH THE VELCRO STRAPS. 2. SLIDE THE REMAINING HOOP POLE THROUGH THE SLEEVE IN THE FRONT OF THE TENT. 3. ATTACH THE LAST HOOP POLE TO THE FRONT BRACKET AS SHOWN, DO NOT TIGHTEN MUST MOVE FREELY SLIDE HOOP POLE THU SLEEVE IN...
  • Page 12 STEP-10 Visit Clam’s website (www.clamoutdoors.com) and or our YouTube channel (ClamOutdoors) for shelter build how to videos HEAT THE MOLDING (102814) WITH A BLOW DRYER, HEAT GUN OR SOAK IN HOT WATER MAKING IT PLIABLE DETAIL-B 8” Approx. REMOVE HOOP...
  • Page 13: Tips For Use

    (NOTE: Pulling behind an ATV or snowmobile may result in premature wear of the base). ▪ In windy conditions it is advised to secure your shelter to the ice using Clam’s Ice Anchor Kit 108064) and Ice Anchor Installation Tool (PN 108348).
  • Page 14: Safety Instructions

    SAFETY INSTRUCTIONS Please fully understand and follow all safety instructions as outlined. Failure to do so could result in severe injury or death. ▪ DO NOT USE OPEN FLAME HEATERS IN YOUR ICE SHELTER. INJURY OR DEATH MAY RESULT FROM FIRE IF TENT FABRIC IS EXPOSED TO OPEN FLAME. THE TENT IS NOT FIREPROOF, BUT THE FABRIC IS TREATED WITH A FIRE RETARDANT THAT MEETS CPAI-84 SPECIFICATIONS.
  • Page 15: Frequently Ask Questions

    FREQUENTLY ASK QUESTIONS Fish Trap FAQ’s Q: Should I install a runner kit/hyfax to the base of my shelter? A: The warranty on our shelters does not cover cracked or worn bases if a runner kit has not been installed. Additionally, bases will wear much quicker without a runner kit installed. Q: The zipper on my shelter freezes up and/or sticks.
  • Page 16 Q: There are cracks on the inside finish of the fabric of my shelter. Is this normal? Can anything be done to fix this? A: It is normal for some of the dark colored coating to come off the inside of the tent, particularity on a non-thermal tent.
