COMPACT COMPONENT SYSTEM
SISTEMAS DE COMPONENTES COMPACTOS
SISTEMA DE COMPONENTE COMPACTO
MX-J30
Consists of CA-MXJ30 and SP-MXJ33
Consta del CA-MXJ30 el SP-MXJ33
Consta do CA-MXJ30 e SP-MXJ33
CA-MXJ30
SP-MXJ33
SP-MXJ33
CA-MXJ30
SOUND
ACTIVE
ECHO
SLEEP
MODE
BASS EX.
A
TAPE-
B
TAPE-
REC PAUSE
FM MODE
+
FADE
MUTING
–
RM–SMXJ30U REMOTE CONTROL
SP-MXJ33
CA-MXJ30
STANDBY
COMPACT
DIGITAL AUDIO
1 BIT
DUAL D/A CONVERTER
PHONES
PANEL
OPEN / CLOSE
MIC LEVEL
TAPE
MIN
MAX
1
AUX
MIC
2
PLAY
AUTO REVERSE
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
INSTRUÇÕES
SP-MXJ33
3
CD
2
CD
3
CD
2
CD
1
CD
CD
1
PLAY & EXCHANGER
VOLUME
+
–
C D
/
FM AM
REC/PLAY
AUTO REVERSE
EJECT
EJECT
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
COMPACT
DIGITAL AUDIO
GVT0011-003A
[ U, US, UT, UX, UY ]
Advertisement
Table of Contents
Related Manuals for JVC SP-MXJ33U
Summary of Contents for JVC SP-MXJ33U
- Page 1 COMPACT COMPONENT SYSTEM SISTEMAS DE COMPONENTES COMPACTOS SISTEMA DE COMPONENTE COMPACTO MX-J30 Consists of CA-MXJ30 and SP-MXJ33 Consta del CA-MXJ30 el SP-MXJ33 Consta do CA-MXJ30 e SP-MXJ33 CA-MXJ30 SP-MXJ33 SP-MXJ33 CA-MXJ30 SP-MXJ33 SOUND ACTIVE ECHO SLEEP MODE BASS EX. TAPE- TAPE- REC PAUSE FM MODE...
- Page 2 Warnings, Cautions and Others Avisos, precauciones y otras notas Advertências, precauções e outras notas Caution –– switch! Disconnect the mains plug to shut the power off com- pletely. The switch in any position does not discon- nect the mains line. The power can be remote controlled. Precaución ––...
- Page 3 CAUTION To reduce the risk of electrical shocks, fire, etc.: 1. Do not remove screws, covers or cabinet. 2. Do not expose this appliance to rain or moisture. PRECAUCIÓN Para reducir riesgos de choques eléctricos, incendio, etc.: 1. No extraiga los tornillos, los cubiertas ni la caja. 2.
- Page 4 Caution: Proper Ventilation To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows: 1 Front: No obstructions and open spacing. 2 Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below. 3 Bottom: Place on the level surface.
- Page 5 IMPORTANT FOR LASER PRODUCTS / IMPORTANTE PARA PRODUCTOS LÁSER / IMPOTANTE PARA PRODUTOS LASER / REPRODUCTION OF LABELS / REPRODUCCIÓN DE ETIQUETAS / REPRODUÇÃO DE ETIQUETAS 1 CLASSIFICATION LABEL, PLACED ON REAR ENCLO- SURE 1 ETIQUETA DE CLASIFICACIÓN, PEGADA EN LA PARTE POSTERIOR DE LA CAJA 1 ETIQUETA DE CLASSIFICAÇÃO LOCALIZADA NA PARTE POSTERIOR DA CAIXA DO APARELHO.
- Page 6 Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual About This Manual This manual is organized as follows: •...
-
Page 7: Table Of Contents
Contents Location of the Buttons and Controls ... 3 Front Panel ... 4 Remote Control ... 5 Getting Started ... 6 Unpacking ... 6 Putting the Batteries into the Remote Control ... 6 Connecting Antennas ... 6 Connecting Speakers ... 7 Connecting Other Equipment ... -
Page 8: Location Of The Buttons And Controls
Location of the Buttons and Controls Become familiar with the buttons and controls on your unit. Powered Rolling Panel PANEL OPEN / CLOSE Press PANEL OPEN/ CLOSE to open the panel. To close the panel, press the button again. STANDBY 1 BIT DUAL D/A CONVERTER PHONES... -
Page 9: Front Panel
Display Window A.BASS EX SLEEP REC DAILY MONO See pages in the parentheses for details. Front Panel 1 Disc trays (standby/on) button and STANDBY lamp (9) 3 Display window 4 Remote sensor 5 PANEL OPEN/CLOSE button (9) Pressing this button also turns on the unit. 6 PHONES jack (10) 7 TAPE 2 3 button and lamp (15) Pressing this button also turns on the unit. -
Page 10: Remote Control
Remote Control SOUND ACTIVE ECHO SLEEP MODE BASS EX. TAPE TAPE REC PAUSE FM MODE FADE MUTING – RM–SMXJ30U REMOTE CONTROL STANDBY COMPACT PLAY & EXCHANGER DIGITAL AUDIO VOLUME 1 BIT DUAL D/A CONVERTER PHONES PANEL OPEN / CLOSE MIC LEVEL TAPE PLAY REC/PLAY... -
Page 11: Getting Started
Getting Started Unpacking After unpacking, check to be sure that you have all the following items. The number in the parentheses indicates the quantity of the pieces supplied. • AM loop antenna (1) • FM antenna (1) • Remote control (1) •... -
Page 12: Connecting Speakers
Insert the end of the speaker cord into the terminal. Match the polarity of the speaker terminals: Red (+) to red (+) and black (–) to black (–). Release the finger from the clamp. -
Page 13: Connecting Other Equipment
Connecting Other Equipment You can connect an audio equipment — used only as a playback device. When you connect and use this equipment, refer also to its manual. Be sure that the plugs of the audio cords are color-coded: White plugs and jacks are for left audio signals, and red ones for right audio signals. -
Page 14: Common Operations
Common Operations Setting the Clock Before operating the unit any further, first set the clock built in this unit. Press PANEL OPEN/CLOSE. The unit is turned on and the Powered Rolling Panel opens automatically. Press TIMER/CLOCK. A.BASS EX S.MODE The hour digits start flashing on the display. Press 4 or ¢... -
Page 15: Adjusting The Volume
Adjusting the Volume You can adjust the volume level only while the unit is turned Turn VOLUME clockwise to increase the volume or counterclockwise to decrease it. A.BASS EX S.MODE When using the remote control, press VOLUME + to increase the volume or press VOLUME –... -
Page 16: Listening To Fm And Am Broadcasts
Listening to FM and AM Broadcasts Tuning in a Station On the unit ONLY: Press FM/AM. The unit automatically turns on and tunes in the previously tuned station (either FM or AM). The Powered Rolling Panel automatically opens. • Each time you press the button, the band alternates between FM and AM. -
Page 17: Playing Back Cds
Playing Back CDs Loading CDs Press 0 for the disc tray (CD 1 to 3) you want to load a CD onto. The unit automatically turns on and the disc tray comes out. The Powered Rolling Panel also opens automatically. Place a disc correctly on the circle of the disc tray, with its label side up. -
Page 18: Programming The Playing Order Of The Tracks - Program Play
To locate a particular point in a track During play, press and hold 1 or ¡. • 1: Fast reverses the disc. • ¡: Fast forwards the disc. When using the remote control, press and hold 1 / 4 or ¢ / ¡. To go to another track Press 4 or ¢... -
Page 19: Playing At Random - Random Play
To check the program contents Before playing, you can check the program contents by pressing 1 / 4 or ¢ / ¡ on the remote control. • ¢ / ¡: Shows the programed tracks in the programed order. • 1 / 4: Shows them in the reverse order. To modify the program Before play, you can erase the programed tracks shown on the display by pressing CANCEL. -
Page 20: Playing Back Tapes
Playing Back Tapes You can play back type I, type II and type IV tapes without changing any settings. Playing Back a Tape Press EJECT (0) for the deck you want to use. For Deck A Put a cassette in, with the exposed part of the tape down. -
Page 21: Recording
Recording IMPORTANT: • It may be unlawful to record or play back copyrighted material without the consent of the copyright owner. • The recording level is automatically set correctly, so it is not affected by the VOLUME control. Thus, during recording you can adjust the sound you are actually listening to without affecting the recording level. -
Page 22: Dubbing Tapes
To record on both sides — Reverse Mode Press REVERSE MODE so that the Reverse Mode indicator lights up as — • When using the Reverse Mode for recording, start recording in the forward (3) direction first. Otherwise, recording will stop when recording is done only on one side (reverse) of the tape. -
Page 23: Using The Microphones
Using the Microphones You can enjoy singing along (Karaoke) and microphone mixing by using two microphones. • The MIC LEVEL control adjustment is valid for both microphones connected to the MIC 1 and MIC 2 jacks. IMPORTANT: • Always set MIC LEVEL to MIN when connecting or disconnecting the microphone. -
Page 24: Using The Timers
Using the Timers There are three timers available — Recording Timer, Daily Timer, and Sleep Timer. Before using the timers, you need to set the clock built in the unit. (See page 9.) Using Daily Timer With Daily Timer, you can wake to your favorite music or radio program. -
Page 25: Using Recording Timer
When selecting “– CD – – –” 1) Press 4 or ¢ to select the disc number, then press SET. 2) Press 4 or ¢ to set the track number, then press SET. The unit enters volume setting mode. When selecting “TUNER FM” or “TUNER AM”... -
Page 26: Using Sleep Timer
Set the on-time you want the unit to turn on. 1) Press 4 or ¢ to set the hour, then press SET. 2) Press 4 or ¢ to set the minute, then press SET. “OFF TIME” appears for 2 seconds, then the unit enters off-time setting mode. -
Page 27: Maintenance
Maintenance To get the best performance of the unit, keep your discs, tapes, and mechanism clean. Handling discs • Remove the disc from its case by holding it at the edge while pressing the center hole lightly. • Do not touch the shiny surface of the disc, or bend the disc. -
Page 28: Troubleshooting
Troubleshooting If you are having a problem with your unit, check this list for a possible solution before calling for service. If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person, such as your dealer, for service. -
Page 29: Specifications
Maximum power consumption (for Taiwan only): 300 watts Dimensions (approx.): 265 x 315 x 341 mm (W/H/D) x 12 Mass (approx.): 8.4 kg (18.5 lbs) Supplied accessories See page 6. Speaker section — SP-MXJ33 ype: 3-way bass-reflex type Speaker units: Woofer: Midrange: Tweeter:... - Page 30 Mains (AC) Line Instruction (not applicable for Europe, U.S.A., Canada, Australia, and U.K.) Instrucción sobre la línea de la red (CA) (no aplicable para Europa, EE.UU., Canadá, Australia, ni el Grã-Bretanha) Instrução sobre a tensão da rede eléctrica (CA) (não aplicável para a Europa, os E.U.A., o Canadá, a Austrália e o Reino Unido) IMPORTANT for mains (AC) line BEFORE PLUGGING IN, do check that your mains (AC)
